Presentation Transcript
outline
Outline
  • Introduction
  • Strategies
  • Exercise
testing
Testing
  • To demonstrate to the developer and the customer that software meets its requirement (是否合乎需求)
  • Testing is a fault detection technique that tries to create failures or erroneous states in a planned way.(Testing就是試著弄壞系統找出Bug)
test stubs test driver
Test Stubs & Test Driver
  • Test Stubs: If the function A you are testing calls another function B,then use a simplified version of function B, called a stub.(虛構的程式方法)
  • Test driver – allows you to call a function and display its return values.(可以啟動你的程式,並驗證回傳結果)

Test Driver

YourFunction

Test Stub

  • int main() {
    • //呼叫被測試程式
    • //驗證結果
  • }
  • int YourOtherFunction()
  • {
    • return 1;
  • }
  • int YourFunction(){
      • //呼叫其他程式
  • }

YourOtherFunction

YourFunction

software lift cycle
Software Lift Cycle

Software Life Cycle

Development cycle

Unit Testing

Integration Testing

System Testing

Requirements

Engineering

Design

Implementation

Testing

Requirements

Elicitation

System Design

Analysis

Object Design

Testing Plan (Test case)

Testing Report

Maintenance

slide6
Bug
  • Fault –又稱作bug或defect (缺陷),是design或coding錯誤導致反常的結果
  • Erroneous state –有fault在系統執行中發生
  • Failure –系統實際的行為與預計不同,通常由1個以上的erroneous state導致

System view

User View

Design/Implement Time

Runtime Time

Software

Software

Software

Failure

Erroneous state

Fault(Bug, Defect)

testing strategies
Testing Strategies
  • Testing Plan –包含測試相關資訊、測試種類、test case與測試進度(IEEE 829)
  • Testing Report –測試報告

Testing

Software developer

( 程式開發者 )

Testing Report

(測試結果報告)

Testing Plan

(測試計劃)

Unit Testing

(單元測試)

Integration Testing

(整合測試)

Test Case Result

(試案案例的結果)

Test Case

(試案案例)

Independent testing team

( 獨立測試小組 )

Bug Report

(問題報告)

System Testing(系統測試)

test case
Test Case
  • 設計一個情況(Condition),然而軟體程式在這種情況下,必須能夠正常運作並且達到程式所設計的執行結果(Expect Result)。
  • 如果程式在這種情況下並不能正常運作,而且這種問題是能夠被重複產生的(Reproducible),那表示軟體程式人員已經測出軟體有瑕疵(Bug),這時候就必須將這個問題標示出來,並且輸入至問題追蹤系統(Bug Tracking System)內,通知軟體開發人員。
test case design
Test Case Design
  • 原則
    • Involves designing the test cases (inputs and outputs) used to test the system.

(設計測試案例要有輸入輸出)

    • Design inputs that cause buffers to overflow.

(設計會產生overflow的資料)

    • Force computation results to be too large or too small.

(選擇很大與很小的資料去測試)

  • 方針
    • Equivalence Testing
    • Path Testing
equivalence testing
Equivalence Testing
  • The program behaves in an equivalent way for equivalence partition.

(同區塊的資料效力視為等價)

  • Test cases should be chosen from each partition.

(所有部份需要被選取)

  • Requirement:臨時帳號密碼的長度限定為2-6碼

Boundary

Boundary

7

2

6

1

4

path testing
Path Testing
  • Execute each possible path
  • Not practical with many nested conditionals
  • Impossible for most loops
path testing1
Path Testing
  • 測試活動圖每一個可能路徑
  • 修改學生資料正確路徑

學生點選修改資料

錯誤

正確

顯示修改學生資料表單

輸入修改資料後送出

更新學生資料

寄發確認電子郵件

驗證學生資料

顯示修改完成訊息

path testing2
Path Testing
  • 測試活動圖每一個可能路徑
  • 修改學生資料例外路徑

學生點選修改資料

錯誤

正確

顯示修改學生資料表單

輸入修改資料後送出

更新學生資料

寄發確認電子郵件

驗證學生資料

顯示修改完成訊息

unit testing component testing
Unit Testing (Component Testing)
  • Testing individual subsystems (collection of classes)
  • Goal: Confirm that subsystem is correctly coded and carries out the intended functionality

System Design

Document

Subsystem

Code

Unit Test

unit testing
Unit Testing
  • /* 帳號的長度限定為 1 到 6 個字元*/
  • class system{
    • bool ValidateUserID(const char* userID){
    • int num = strlen(userID);
      • return (num >= 1 )&& (num <=5 );
    • }
  • }

寫好一個物件的功能

決定決定測試資料

開始測試

測試結果第四項目不符合表示程式有錯

integration testing
Integration Testing
  • Testing groups of subsystems and eventually the entire system
  • Goal: Test interfaces between subsystems

System Design

Document

Subsystem

Code

Subsystem

Code

Integration Test

Subsystem

Code

integration testing1
Integration Testing
  • Integration testing detects faults that have not been detected during unit testing by focusing on small groups of components.

(integration testing測試的單位為一群components)

  • Two or more components are integrated and tested, and when no new faults are revealed, additional components are added to the group.

(先從兩個以上有關聯的component當作一個群組開始測試,該群組沒發現新bug後才增加其他有關聯的component進入該群組)

  • Strategies
    • Bottom-Up Strategy
    • Top-Down Strategy
    • Sandwich Strategy
bottom up strategy
Bottom-Up Strategy
  • Strategy
    • Start with subsystems in lowest layer of call hierarchy
    • Test subsystems that call the previously tested subsystems
    • Repeat until all subsystems are included
  • Advantage
    • Interface faults can be more easily found.

(開發者可控制一個component,掌握該component與相關底層component的inputs、outputs,故容易從component的interface找出faults)

  • Disadvantage
    • Faults found in the top layer may often lead to changes in the subsystem interfaces of lower layers.

(越往頂層發現的錯誤牽連越廣,要修正的地方越多)

bottom u p strategy
Bottom-Up Strategy

MSSQL

Database Server

DML

Interface

Test

ODBC/ADO

DML

Application

Test

Server-U

FTP Service

Server-U

FTP Service

ODBC/ADO

ASPUpload

ASPUpload

Test

IIS

Web Server

MSSQL

Database Server

IIS

Web Server

Test

DML

Application

DML

Interface

Test

top down strategy
Top-Down Strategy
  • Strategy
    • Start with subsystems in top layer of call hierarchy
    • Include subsystems that are called by the previously tested subsystems
    • Repeat until all subsystems are included Advantage
  • Advantage
    • It starts with user interface components. Supports test cases for the functionality of the system.

(由使用者觀點進行測試)

  • Disadvantage
    • The development of test stubs is time-consuming and prone to error.

(製作一堆test stub,費時又容易發生錯誤)

top down strategy1
Top-Down Strategy

DML

Application

DML

Interface

Test

DML

Interface

DML

Application

Test

ASPUpload

Server-U

FTP Service

ODBC/ADO

ASPUpload

Test

ODBC/ADO

IIS

Web Server

MSSQL

Database Server

Server-U

FTP Service

Test

MSSQL

Database Server

IIS

Web Server

sandwich strategy
SandwichStrategy
  • Combines top-down with bottom-up strategy
  • Advantage
    • Many testing activities can be performed in parallel.

(Top-down與Bottom-up可同時進行)

    • It lead to a significantly shorter overall testing time than top-down or bottom-up testing.

(Sandwich strategy花費的測試時間比Top-down或是Bottom-up都短)

  • Disadvantage
    • It is the need for additional test stubs.

(依然會有製作test stub所產生的缺點)

sandwich strategy1
Sandwichstrategy

DML

Application

DML

Interface

Test

DML

Interface

DML

Application

ASPUpload

Server-U

FTP Service

ODBC/ADO

ASPUpload

Test

IIS

Web Server

IIS

Web Server

MSSQL

Database Server

MSSQL

Database Server

Test

ODBC/ADO

Test

Test

Server-U

FTP Service

system testing
System Testing
  • Testing the entire system
  • System testing is a black-box technique.

(黑箱測試的test case是根據use case而來)

  • Goal: Determine if the system meets the requirements (functional and non-functional)

Requirements

Specification

Entire

System

System

Test

functional testing
Functional Testing

2

2

  • The goal of the tester is to select valid and invalid inputs that are relevant to the user and have a high probability of uncovering a failure.(測試人員要以使用者角度選用各種可能發現failure的input進行測試)
  • Test cases are derived from the use cases. (test case依據use case而來)
  • We do not consider implementation details. (不需了解實做細節,只管inputs與results)
  • Impossible to generate all possible inputs

3

3

Input data

Output data

Expected

Expected

System

4

1

1

Invalid

Invalid

4

non functional testing
Non-functionalTesting
  • Product testing
    • Usability Testing
    • Performance Testing
    • Space Testing
    • Reliability Testing
    • Availability testing
    • Portability Testing
  • Organisational testing
    • Delivery Testing
    • Implementation Testing
    • Standards Testing
  • External Testing
    • Interoperability Testing
    • Ethical Testing
    • Privacy Testing
    • Safely Testing
  • Configuration Testing
performance testing
Performance Testing
  • Timing Testing(時間測試)Response times and time to perform a function
  • Stress Testing(壓力測試)Stress limits of system (maximum number of users, peak demands)
  • Recovery Testing(回復測試)System’s response to presence of errors or loss of data
tools for performance testing
Tools for performance testing
  • WAPT 4.0 http://www.loadtestingtool.com/
  • TestView http://www.radview.com/products/testview.asp
  • AdventNet QEngine Web Performance Test tool http://www.adventnet.com/products/qengine/web-performance-test.html
exercises
Exercises
  • 試完成第20張投影片(Bottom-up)及第22張投影片(top-down)全部測試的順序
  • 請依照教學網站作業功能製作I/O Form
  • 至教學網站下載testing plan進行system testing,需使用bugzilla進行bug report
