Raspberry Drive

This project by Ronny Thiesies and Tom Schubert explores the development of a Raspberry Pi-powered car, remotely controlled via an Android device. Utilizing a WiFi hotspot for communication, the prototype features video streaming from a camera with adjustable frame rates and resolutions. The control system is optimized for efficient motor operation using AA batteries and a rechargeable unit for the Raspberry Pi. The total estimated cost is approximately 250 EUR, comprising various components from motors to structure. The project emphasizes the benefits of WiFi over alternatives like Bluetooth and IrDA.

chiku
Download Presentation

Raspberry Drive

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Raspberry Drive Ronny Thiesies Tom Schubert

  2. Anforderungen • Steuern eines Raspberry-Autos via Android • Kommunikation mittel WLAN-Hotspot • Übertragung einer Kamera

  3. Prototyp

  4. Prototyp Video (Nov. ‘13)

  5. Wieso WIFI? Controller: 45 Byte je 100ms = 3,5 kBit/s Kamera: 320 * 240 Pixel * 16bit Farbtiefe * 75% (JPEG) mit (10-30 FPS) = 9 Mbit/s bis 30 Mbit/s

  6. Wieso WIFI? IrDA (v. 1.3): 16MBit/s (Reichweite < 1m) Bluethoot (v.3): 24Mbit/s (Reichweite<100m) Bluethoot (v 4): 1Mbit/s (Reichweite < 100m) WIFI (802.11) : 54Mbit/s (Reichweite>100m)

  7. Android

  8. Workflow Kamera WebSite Kamera Stream WebView Kamera Android Raspberry UDP Control (100ms) Wifi

  9. Permissions

  10. Sensor-Parsing

  11. Kommunikation (JSON)

  12. Motoransteuerung

  13. Motoransteuerung

  14. Leistung 8 x 1,5V AA-Batterien (Antriebsmotor) 4 x 1,5V AA-Batterien (Servomotor) 3000 mAh Akku (Raspberry) Antriebsmotor: Betriebsspannung : 1-13V max. Leistung: 9,27W max. Drehmoment: 13,5mNm

  15. Kosten Raspberry Pi (45 EUR) Case (7 EUR) Antriebsmotor (5 EUR) Coppler,IDE-Kabel (10 EUR) Servomotor (10 EUR) WIFI-Stick (8 EUR) Getriebe (10 EUR) Hinterachse (20 EUR) Reifen (2 x 10 EUR) Baumaterial (30 EUR) Steckboard (5 EUR) Pizza-Karton (10 EUR) Akku (20 EUR) sonstiges (50 EUR) SUMME: ~ 250 EUR
