uml unified modelling language for effective oo development

UML – Unified Modelling LanguageFor Effective OO Development

Yves Holvoet

Rational Software Corporation

(say Eve Olvoot)

agenda
Agenda
  • Modelling
    • Why?
    • Levels of Abstraction
    • 5 Views and 2 dimensions of System Architecture
  • UML
    • History
    • 10 diagrams
  • Summary
what is a model
What Is a Model?
  • A model is a simplification (abstraction) of reality.
abstraction
Abstraction
  • Is conceptual and captures the essential characteristics of an entity that distinguish it from all other kinds of entities.
  • Defines a boundary relative to the perspective of the viewer.
instance
Instance

myAccount :

BankAccount

yourAccount :

BankAccount

  • Is an actual entity instance of the conceptual abstraction.
  • All instances of a given abstraction share a common structure (data and behavior as described in the Abstraction).
levels of abstraction
Levels of Abstraction

Scenario

High Level

object

object

Is an instance of

Is an abstraction for

Low Level

Processor

Processor Type

modeling process
Modeling Process

Modeling Process

Business

Business

Business Use Cases - Activities

Business Use Cases - Activities

High Level

Use Cases

Scenarios

Classes

Objects

System

Abstraction

Instance

Sources

Processes

Processors

Low Level

uml 1 2 2 views
UML 1 + 2 * 2 Views

Layers

Use Cases

Packages

Scenarios

Logical View

Use Case View

Classes

Objects

Software

Implementation View

Sources

Process View

Tasks

Packages

Processes

Layers

Systems

Hardware

Deployment View

Processors

4 1 1 2 2 views
4 + 1 = 1 + 2 * 2 Views

Logical View

Logical View

Use Case View

Implementation View

Implementation View

Use Case View

Deployment View

Deployment View

Process View

Process View

  • The Use-Case view describes the behavior of the system in term of use-cases and scenarios
  • The Logical view packages the classes of the system and their relationships
  • The Implementation view describes the mapping of the logical classes to components of the target environment
  • The Process view deals with concurrency and synchronization
  • The Deployment view describes the mapping of the software on the hardware
use case view
Use-Case View

Specification

Class

Validation

DevelopmentPlan

  • 3MainBenefits

Abstraction for many scenarios

message instance

of operation

link instance

of association

object instance

of class

use case view main benefits
Use Case View: Main Benefits
  • Specification
    • in terms of use cases
  • Development plan
    • lists iterations
    • assign scenarios to iterations according to their risk levels
  • Validation of classes
    • the necessary objects for the whole system are collectively all the objects participating in all scenarios
    • the messages between objects drive class relationships
logical view
Logical View

Terminology

Object

Validation

Development Teams

  • 3 Main Benefits

Logical grouping of classes

Strong inner coupling (cohesive classes)

Weak outer coupling (for reuse, resilience)

logical view main benefits
Logical View: Main Benefits
  • Terminology
    • it provides vocabulary for common unambiguous understanding of the problem domain
  • Development Teams
    • they are derived from packages
    • packages are created to minimize the coupling
  • Validation of objects
    • the objects, links and messages must be in synch with class, relationships and operations
2 dimensions for software architecture
2 Dimensions for Software Architecture

Logical packages

form horizontal layers

where layers can only

access what is below

and not what is above

Scenarios form vertical slices where each slice traverses all layers but only “hits” a small

sub-set of the classes

Rational Unified Process is:

Architecture Centric

Use Case Driven

agenda1
Agenda
  • Modelling
    • Why?
    • Levels of Abstraction
    • 5 Views and 2 dimensions of System Architecture
  • UML
    • History
    • 10 diagrams
  • Summary
history of the uml
History of the UML

Nov ‘97

UML approved by the OMG

uml concepts
UML Concepts
  • The UML may be used to visually model:
    • The interaction of your application with the outside world
      • Use Case Diagram
    • The behavior of your system
      • Interaction Diagram
    • The structure of your system
      • Class Diagram
      • Package Diagram
    • The components in your system
      • Component Diagram
      • Deployment Diagram
10 uml diagrams
10 UML Diagrams

Activity Diagram

Sequence Diagram

Use Case Diagram

Interaction Diagram (Scenarios)

Collaboration Diagram

Class Diagram (static part of class)

State-Transition Diagram (behavioral part of class)

Object Diagram

Component Diagram (Sources & Processes)

Deployment Diagram (Processors)

use case diagram
Use Case Diagram

Request Course Roster

Professor

Student

Register for Courses

Billing System

Maintain Course Information

Registrar

  • Use case diagrams are created to visualize the interaction of your system with the outside world
sequence diagram
Sequence Diagram

registration

registration

math 101

: Student

math 101

form

manager

section 1

1: fill in info

2: submit

3: add course(joe, math 01)

4: add(Joe)

5: are you open?

6: add (Joe)

  • A sequence diagram shows step-by-step what has to happen to accomplish a piece of functionality provided by the system
collaboration diagram
Collaboration Diagram

course form :

1: set course info

CourseForm

2: process

3: add course

: Registrar

theManager :

aCourse :

CurriculumManager

Course

4: new course

  • A collaboration diagram displays object interactions organized around objects and their links to one another
class diagram
Class Diagram

RegistrationUser

Student

major

Professor

3..10

CourseOffering

4

1

0..4

  • A class diagram shows the structure of your software
2 main relationships inheritance vs association
2 Main Relationships: Inheritance vs. Association

Person

Food

<<deferred>> eat(Food)

Vegan

Vegetarian

Omnivore

eat(Food)

eat(Food)

eat(Food)

pre-condition of eat() is:

pre-condition of eat() is:

No pre-condition at all for

-Food parameter must be a

-Food parameter must be either a

eat()

Vegetable

Vegetable or Derived from Animal

the physical world
The Physical World

Register.exe

Billing.exe

Billing

System

People.dll

User

Course.dll

Course

  • Component diagrams illustrate the organization and dependencies among software components
deploying the system
Deploying the System

Registration

Database

Main

Library

Building

Dorm

  • The deployment diagram visualizes the distribution of components across the enterprise.
summary
Summary
  • Visual modeling can be used to:
    • Define business process
    • Communicate
    • Manage complexity
    • Define software architecture
    • Promote reuse
  • The UML is the standard language for visualizing, specifying, constructing, and documenting the artifacts of a software-intensive system
