slide1

Nexsan iSeries™

Complete iSCSI SAN

Zophar Sante

Product Management

Nexsan Technologies Inc.

555 St. Charles Drive

Thousand Oaks, CA 91360

Nexsan iSeries™ General Product PPT GA010810-A

slide2

What is Nexsan iSeries™

Complete iSCSI SAN for Storage Consolidation and Virtualization

  • Nexsan iSeries™
    • Includes enterprise-class storage services
    • High reliability and performance
    • High density, scalable to 1PB with Nexsan Storage
    • Nexsan “GREEN” AutoMAID
    • Includes:
      • Storage consolidation, tiering and virtualization
      • Snapshots, mirroring and replication
      • Redundancy and multi-pathing
  • Suitable for:
      • Server Virtualization (VMware Certified)
      • Exchange, SQL, Oracle, other databases
      • Storage and data consolidation

iSCSI Storage Area Network

Nexsan iSeries™ General Product PPT GA010810-A

slide3

Nexsan iSeries™ Includes

  • Nexsan iSeries Appliance (s)
  • Nexsan iSeries Storage Services
  • Nexsan Storage (New or Existing)
  • Integrated into a single iSCSI SAN

Enterprise

SMB

Nexsan iSeries™ General Product PPT GA010810-A

slide4

Nexsan iSeries™

A Truly Enterprise Class iSCSI SAN

  • High Speed iSeries Appliance
    • High speed, low latency - bus, OS and chip set
    • Address multiple applications simultaneously
    • Address high performance requirements
  • High Connectivity
    • Support small to large environments
    • Up to 200 servers per iSCSI SAN
    • Create 1000’s of unique volumes
  • High Availability
    • Nexsan iSeries™ Clustering and Multi-pathing
    • Ensure continuous data access
    • Protects against connection, network or system outage
    • Fault tolerant and hot-swappable
  • Enterprise Class Nexsan Storage
    • High performance, reliability and scalability
    • Over 21,000 units installed in 60+ countries
    • Independent performance engine – RAID and Cache
    • Create storage tiers using Nexsan SAS and SATA
    • Scale capacity to 1PB (petabyte)

iSeries Appliance

Nexsan Storage

Nexsan iSeries™ General Product PPT GA010810-A

slide5

Nexsan iSeries™ Storage Services

  • Storage Virtualization
    • Create virtual volumes from any storage tier
    • Create any size volume to precisely meet application needs
    • Increase volume size while online
    • Recycle capacity from obsolete volumes
  • Storage Tiering
    • Create different storage tiers
    • Use SAS for performance, SATA for capacity, or create a very green tier for backup/archive - All within the same SAN
    • Match different tiers with different applications
  • Scale from SMB to Enterprise
    • Support small to large environments
    • Support up to 200 servers
    • Create 1000’s of virtual volumes
    • Scale individual volume size to 64TB

iSCSI

Server

Network

Nexsan iSeries™ General Product PPT GA010810-A

slide6

Instant Volume Creation

  • Create and use a volume in seconds
  • Give it a volume name
  • Select the storage tier
  • Determine the size
  • That’s it – you’re done
  • Like RAID types are pooled into a single storage tiers
  • The volume is automatically created from the selected pool
  • iSeries load balancing assigns the volume to the least used iSeries host port
  • Volume is automatically exposed to the iSCSI SAN network
  • Volume is ready to be used by the server

Nexsan iSeries™ General Product PPT GA010810-A

slide7

New iSeries Feature - QoS – bandwidth management for iSeries tiered storage environments

  • Ensure bandwidth for demanding high performance applications
  • Applications using SAS storage can be given priority over applications using SATA storage to ensure optimum performance and responsiveness.
  • The user can configure iSeries bandwidth and control how much bandwidth is given to SAS based applications as opposed to SATA based applications
  • If SAS is not being accessed – bandwidth is given 100% to SATA until SAS bandwidth is required
  • Databases
  • email
  • VMware
  • Hyper-V
  • OLTP
  • Print servers
  • Web servers
  • Backup
  • Archive
  • Home directories

Limited

MAX

  • Example shows SATA bandwidth limited to 50MBs
  • Applications using SAS will have full use of the remaining bandwidth (approx. 220 MBs)

SAS Pool

SATA Pool

Nexsan iSeries™ General Product PPT GA010810-A

slide8

Nexsan iSeries™ Automated

Storage Services

  • Windows SQL and Exchange Setup Wizards
    • Meets Microsoft best practices requirements
    • Automatically creates separate volumes for LOGs and DATA
    • Automatically configures iSeries bandwidth mangers
  • Automatic storage pooling
    • All storage resources with the same drive and RAID type can be placed into a single “POOL”
    • When volumes are created, iSeries will automatically select the best resource within the pool to deliver optimal performance

Nexsan iSeries™ General Product PPT GA010810-A

8

slide9

Nexsan iSeries™ Data Protection

  • Data Mirroring
    • Mirror data across multiple storage systems, locally or to another location using FC
    • Stay in production – even if a storage system goes offline
    • Protect data if your main site is damaged
  • Snapshots
    • Multiple snapshots per volume
    • Eliminate the backup window, backup from snapshots and remain on line
    • Eliminate need for incremental tape backups
    • Integrated with Microsoft VSS for live database backup (SQL, Exchange)
    • Quickly recovery any volume
    • Convert snapshots to read and/or write for data mining and testing

A

A

A

A-S1

A-S2

A-S3

A-S4

Nexsan iSeries™ General Product PPT GA010810-A

slide10

Automatic Snapshot Scheduler

  • Create and Schedule Snapshots inSeconds
  • Select the size
  • Select the frequency
  • Decide how many you want to keep
  • That’s it – you’re done
  • Snapshots are created on a per volume basis
  • Snapshot volumes are automatically created and recycled

Nexsan iSeries™ General Product PPT GA010810-A

slide11

Nexsan iSeries™ Storage Services

  • Online Data Migration
    • Migrate data between storage systems
    • Reduce per TB costs by moving volumes to lower cost storage tiers
    • Move volumes to more green storage
    • Replace old storage systems with new storage systems while remaining online
    • Migrate volumes off 3rd party, legacy or obsolete storage systems to Nexsan iSeries
  • Data Striping
    • Stripe data across multiple storage systems
    • Increase read and write performance

A- OLD

A -NEW

AA

AB

AC

Nexsan iSeries™ General Product PPT GA010810-A

nexsan iseries remote data replication and disaster recovery
Nexsan iSeries™ Remote Data Replication and Disaster Recovery
  • Asynchronous or Synchronous remote data replication
    • Reduce or eliminate tape backup – dramatically reduce recovery time
    • Failover services to another site in the event of disaster
    • Agent and server free, non-disruptive - done in the background
    • Replicate only block changes to maximize connection bandwidth
    • Use consistency groups for multi-volume applications like databases
    • Use remote snapshots to test DR functionality without disrupting replication or production volumes
    • Keep it simple with wizard and policy based management

IP – LAN, MAN, WAN

Primary Volume

A-1

Secondary Volume

A-2

Nexsan iSeries™ General Product PPT GA010810-A

12

multiple sites topologies

Nexsan iSeries™ Data Replication Topologies

Multiple Sites Topologies
  • Back to Back
  • Two production sites – each replicating data to the other for disaster recovery
  • Any to Any
  • Replicate to any other Nexsan iSeries site
  • Many to One
  • Multiple sites can replicated to and use a single site for disaster recovery

Nexsan iSeries™ General Product PPT GA010810-A

13

nexsan iseries simple to deploy learn and manage
Nexsan iSeries™Simple to Deploy, Learn and Manage
  • Centralized and unified management (Nexsan iSeries™ Management)
  • Simple wizard based setup and administration
  • Administer local and remote systems with a single interface
  • Centrally manage volumes, snapshots, replication, mirroring and data migration
  • SNMP and email alerts

Nexsan iSeries™ General Product PPT GA010810-A

nexsan iseries expandable raid architecture
Nexsan iSeries ™Expandable RAID Architecture
      • iSeries Appliances
        • High speed, highly responsive – hyper transport bus, real-time OS and enterprise-class network chip set
  • Nexsan iSeries expandable RAID architecture
    • Leverages iSeries Appliance performance
      • Increase capacity and performance each time you add another storage system
      • Each Nexsan storage system within the iSeries SAN has its own performance engine independent from the iSeries appliance.
      • Each performance engine includes up to 4GB of cache and 4 RAID engines.
      • Every time you add another storage system – you increase iSeries performance
    • Use iSeries expandable RAID architecture to maximize performance across all available 1Gb iSCSI host network ports

iSeries Appliances

Nexsan iSeries expandable RAID architecture with Nexsan RAID storage

Independent Performance Engine RAID and Cache

Independent Performance Engine RAID and Cache

Independent Performance Engine RAID and Cache

Nexsan iSeries™ General Product PPT GA010810-A

nexsan iseries highly scalable
Nexsan iSeries™– Highly Scalable
  • Expand Nexsan iSeries capacity with Nexsan enterprise-class RAID storage
    • Expand capacity using Nexsan Boy and Beast
    • Expand capacity independent of the iSeries appliance
    • No Capacity Keys - No Server Keys – unlimited growth without restrictions
    • Fully redundant, multi-pathed enterprise class reliability
    • Scale capacity while remaining online
    • Tier storage using Nexsan SAS and SATA
    • Scale from a few TBs, 100’s TBs to 1PB (petabyte)

112TB

Higher

14TB

46TB

Nexsan iSeries™ General Product PPT GA010810-A

slide17

Speed with Green, Nexsan iSeries™

“Ultra-Green” iSCSI Storage

Green

Energy Efficiency

Worst

Best

Highest Performance

Performance

Other iSCSI Systems

Low Performance

Nexsan iSeries™ General Product PPT GA010810-A

slide18

Nexsan iSeries™ - Ultra-Green Storage

Less Power – Less Cooling

  • Next Generation Green Storage
  • Speed with Green
    • Green without impacting application performance
  • Reduce power by up to 52%
    • (The StorageIO Group – MAID Jan. 2008)
  • Nexsan storage supports AutoMAID
    • Nexsan Green means less electricity
    • Nexsan Green means less cooling
    • Nexsan Green means more TB/s per shelf.
    • Nexsan Green means LOWER COSTS!

18

Nexsan iSeries™ General Product PPT GA010810-A

slide19

Virtualization Partners

  • VMware Hardware Compatibility List Certified
  • VMware Technology Alliance Partner
  • Microsoft Hyper-V Integrated
  • Microsoft Windows Certified (WHQL)
  • Virtual Iron Certified
  • Xen Server Certified

Nexsan iSeries™ Competitive Overview GA010810-A

slide20

Unique iSeries Metro Cluster

HA Architecture for HA Virtual Server Environments

Site A

Site B

Guests

IP Network

Virtual Server Host

Heart-beat

iSCSI Failover Data Path

iSCSI Data Path

Heart-beat

Nexsan iSeries

FC Mirror/ failover Path

FC Connection

FC Data Path

Production IO

Nexsan

FC Storage

Nexsan iSeries™ Competitive Overview GA010810-A

slide21

Unique iSeries Metro Cluster – Site Outage

HA Architecture for HA Virtual Server Environments

Site A

Site B

IP Network

Heart-beat

Heart-beat

FC Connection

Production IO

Dropped Paths

Nexsan iSeries™ Competitive Overview GA010810-A

why iseries for server virtualization
Why iSeries for Server Virtualization
  • Speed, Reliability and Scalability
  • Scale capacity and performance
    • Non-disruptive – no need to move server connections or data
    • SAS and SATA
  • Much lower latency than EQ or LH
    • More responsive to virtual / guest machines
  • Real-time / low latency support for HA environments
    • Support VMware and Hyper-V HA

Nexsan iSeries™ Competitive Overview GA010810-A

nexsan iseries competitive edge better than any other iscsi san
Nexsan iSeries – Competitive EdgeBetter Than Any Other iSCSI SAN

Nexsan iSeries™ Competitive Overview GA010810-A

nexsan iseries family
Nexsan iSeries™ Family

Shown with 3 Nexsan Storage Systems - Support up to 200 Nexsan Storage Systems

Shown with 1 Nexsan Storage System – Supports up to 100 Nexsan Storage Systems

Small to Mid-range Enterprise, Department, Remote Office

Mid-range to Large Enterprise

Nexsan iSeries™ General Product PPT GA010810-A

24

conclusion nexsan iseries iscsi san for storage consolidation and virtualization
Conclusion – Nexsan iSeries™ iSCSI SAN for storage consolidation and virtualization
  • Complete enterprise class iSCSI SAN
  • Includes all storage services
    • Storage tiering, virtualization, data migration
    • Snapshots, mirroring, replication
  • Scale to 1PB with Nexsan SAS and SATA storage
  • High reliability, fault tolerance and expandable RAID performance
  • Nexsan “Ultra-Green Storage” energy saving
  • Tier 1 storage at Tier 2 prices

Designed to meet

all your storage consolidation

and virtualization needs

Nexsan iSeries™ General Product PPT GA010810-A

slide26

Nexsan iSeries™

Complete iSCSI SAN

Zophar Sante

Product Management

Nexsan Technologies Inc.

555 St. Charles Drive

Thousand Oaks, CA 91360

Nexsan iSeries™ General Product PPT GA010810-A

slide27

Nexsan –Nexsan iSeries™ General Product Slide Deck

Rev. GA010810-A

Nexsan iSeries™ General Product PPT GA010810-A
