1. Micro 204Cytotoxic T Lymphocytes (CTL) Lewis Lanier
Lewis.Lanier@ucsf.edu
2. CTL Recognition of antigen
Generation….”priming” via dendritic cells
Effector functions..killing and cytokines
Cytolytic process
Effector molecules..perforin & granzymes
Avoiding auto-destruction
Maintenance & memory
6. MHC class I “cross-priming”by dendritic cells
7. CTL and Immunity to Intracellular Infections Viral infections
Lytic viruses (polio, vaccinia, influenza)
Antibodies important, CTL less important
Persistent non-lytic viruses (CMV, HSV, EBV,HIV)
CTL & Ab important
Intracellular bacteria & parasites
Listeria, Mycobacteria, Toxoplasma
IFNg & Macrophage activation important, CTL important for clearance
8. Priming a CTL DC eats apoptotic cells, delivers peptides to class I pathway (peptides transported by heat shock proteins? Or delivery of intact protein?)
DC migrates to lymph node and presents antigen to naďve T cell
Clonal expansion of CD8+ T cells in lymph node
CD8 + T cells escape lymph node and traffic to site of infection
9. Priming a CTL CTL precursors - low frequency, no lytic granules, non-dividing
Naďve T cell and APC - interactions:
TcR----- MHC class I (a1 & a2)- peptide
CD8---- MHC class I (a3)
LFA-1 --ICAM (adhesion & signaling)
CD28 --CD80/CD86 or other costimulation (4-1BB)
Results in:
Synthesis of granzymes & perforin
Cytokine production (INF-g, TNF, Fas L, some IL-2)
Massive Proliferation
Requires transcription & protein synthesis (6 hrs minimum)
10. CD4+ T helper-dependent and independent CTL priming
12. CTL Clonal Expansion Rapid proliferation of antigen-specific T cells
In LCMV (mice) or EBV (human) infection - 70% of T cells can be antigen-specific!
Response is antigen-specific, little bystander expansion (ELISPOT & tetramers vs. limiting dilution assays)
Oligoclonal - a few specificities dominate the response
14. CTL - Target Interactions Adhesion
Low affinity adhesion
TcR recognition - shift to high affinity adhesion
Synapse formation & re-orientation of granules
Lethal Hit
Directional release of granule content
Does not require RNA or protein synthesis
Rapid (minutes)
Release
CTL hit & run…kill multiple targets
16. CTL forms ‘synapse’ with target cell
18. Lytic Mechanisms Granule Exocytosis - predominant pathway (FAST KILLING)
granzymes & perforin
Expression of cell surface TNF-family effector molecules (SLOW KILLING)
Membrane TNF, lymphotoxin, Fas ligand, Trail
Secretion of soluble toxic cytokines (SLOW KILLING)
TNF & Interferon-g
19. Granule exocytosis model
20. Perforin Protein with homology to C9
Expressed in CTL & NK, not naďve T
Ca++ dependent assembly to form pore in target membrane..(binds PC head groups)
Stored in granules (low Ca++, bound to calreticulin)
Purified perforin from granules lyses RBC, but not nucleated cells
22. Granzymes Granzyme B - Aspase…activates caspases
Stored in granules & released
KO mice show CTL defects
Granzyme A - Lys/Arg-ase…role?
Stored in granules & released
KO mice minimal effect on CTL activity
23. Granzyme A (green) atCTL ‘synapse’ with target cell
24. Granule Exocytosis Model Activation-induced re-orientation of granules to synapse
Release of perforin & granzymes
Perforin creates holes in membranes
Granzymes B (aspase) cleaves pro-caspases
Induces apoptosis in target cells
Caspase activation - DNA fragmentation
Mitochondrial damage (cytochrome C release)
25. Proof that granzyme/perforin cause CTL activity - Henkart Rat basophil line (RBL)
Has high affinity IgE receptor
Has histamine containing granules
Degranulates when IgE is cross linked
Coat targets with IgE - trigger granular release
RBL doesn’t kill IgE-coated RBC or tumor
RBL - transfect perforin - kill IgE-coated RBC, not IgE-coated tumor
RBL- transfect perforin & granzme - kill IgE-coated tumor
26. Cytotoxicity via TNF family
27. Why don’t released lytic granules kill the CTL? Surface cathepsin B protects CTL from self-destruction after degranulation
Proteinase inhibitor 9 - serpin that inhibits granzyme B….expressed by CTL, dendritic cells, endothelial cells, some tumors
29. Direct anti-microbial function Human CTL granules contain “granulysin”
Together with perforin is directly lytic for certain bacteria and viruses, including Mycobacteria tb
30. Expansion & contraction of T cells in an immune response
31. Primary CD8+ cell response does not require CD4 + T cell help - maintenance of memory CD8 + T cells does
32. CTL Maintenance After elimination of antigen, apoptosis of >90% of effector CTL (TNF-induced apoptosis?)
Persistence of small subset of oligoclonal CD8 + T cell provides memory…allows rapid re-activation
Naďve CD8 + T cells require class I in host to survive…memory CTL don’t require class I to live
33. CTL Maintenance Maintenance of CTL memory requires IL-15
Adoptively transferred CTL effectors require exogenous IL-2 or antigen-specific CD4+ T cells to thrive
E.g. adoptive transfer of CMV-specific autologous CTL in bone marrow transplant patient
35. Memory CD8+ T cells are delineated into TCM and TEM subsets Central Memory
CD62L+ & CCR7+
High proliferative potential
IL-2
Non-cytolytic
Secondary lymphoid tissue Effector Memory
CD62L- & CCR7-
Low proliferative potential
Inflammatory cytokines
Immediately cytolytic
Non-lymphoid tissue
36. Generating 1°, 2°, & 3° CD8+ T cell responsesHeterogeneous boost
37. Boosting results in quicker responses & more memoryVSV-immunized mice
38. Boosting results in quicker responses & more memory - VSV-immunized mice
39. Prime-boost vaccination preferentially drives TEM generation: location
40. Prime-boost vaccination preferentially drives TEM generation
41. Chronic infections Chronic infections result in CD8+ T cell exhaustion
Senescent
Poor cytokine production
CD8+ T cell exhaustion is major barrier to clearance
Can we restore CD8+ T cell responses against chronic infections?
42. PD-1 inhibitory receptor is preferentially expressed by CD8+ T cells specific for chronic infection
PD-1 maintains CD8+ T cell exhaustion
Blocking PD-1 “reactivates” CTL - allows viral clearance
46. CTL-mediated immunopathology Too vigorous CTL response is bad
CTL response to hepatitis
CTL response to LCMV
47. Selected Reading - CTL Persistence of Memory CD8 T Cells in MHC Class I-Deficient Mice, Science 286:1377-1381, 1999
Virus-specific CD8+ T cells in primary and secondary influenza pneumonia, Immunity 8:683-91, 1998
A non-cytotoxic mast cell tumor line exhibits potent IgE-dependent cytotoxicity after transfection with the cytolysin/perforin gene, Cell 64:1175-1181, 1991
Surface cathepsin B protects cytotoxic lymphocytes from self-destruction after degranulation, JEM 196:493-503, 2002
CD8+ but not CD8- dendritic cells cross-prime cytotoxic T cells in vivo. JEM 192:1685-96, 2000
Restoring function in exhausted CD8+ T cells during chronic viral infection by blocking PD-1. Nature 439:682-7, 2006
