  1. CHAPTER 8. MANAGING DATA RESOURCES

  2. FILE ORGANIZATION • BIT:Binary Digit (0,1;Y,N;On, Off) • BYTE:Combination of BITS which represent a CHARACTER • FIELD:Collection of BYTES which represent a Fact • RECORD:Collection of FIELDS which reflect a TRANSACTION • FILE:A Collection of Similar RECORDS

  3. The layout of a personnel file in traditional file organization. Managing Digital Data

  4. FILE ORGANIZATION • DATABASE:An Organization’s Electronic Library of FILES • Primary FIELD or Key:Field in Each Record Uniquely Identifies THIS Record ForRETRIEVAL UPDATING SORTING

  5. Different information making up a student record retained in three different sites. TRADITIONAL FILE ENVIRONMENT(FLAT FILE) • DATA REDUNDANCY • PROGRAM / DATA DEPENDENCY • LACK OF FLEXIBILITY • POOR SECURITY • LACK OF DATA SHARING & AVAILABILITY

  6. DATABASEMANAGEMENTSYSTEM(DBMS) SOFTWARE TO CREATE & MAINTAIN DATA *** ENABLES BUSINESS APPLICATIONS TO EXTRACT DATA *** INDEPENDENT OF SPECIFIC COMPUTER PROGRAMS DBMS

  7. Managing Digital Data • Traditional Files vs. Databases: Pros and Cons • Traditional File Advantages • Simplicity • Efficiency • Customization • Database Advantages • Reduced data redundancy • Application/data independence • Better control • Flexibility

  8. COMPONENTSOFDBMS: • THE SCHEMA: describe the structure of the Database. DATA DEFINITION LANGUAGE: • Defines Data Elements in Database • and Used to construct the schema DATA MANIPULATION LANGUAGE: • Manipulates Data for Applications • DATA DICTIONARY: • Maintains all information supplied by the developer when constructing the schema * DBMS

  9. Data definition language to create a schema in NOMAD • Data Definition Language (DDL)

  10. Figure 8.14 A Paradox query by example Components of Database Management Systems • Data Manipulation Language (DML) • Used to query the database

  11. A typical data dictionary for a staff file DATA DICTIONARY

  12. ADVANTAGESOFDBMS: • REDUCES COMPLEXITY • REDUCES DATA REDUNDANCY • CENTRAL CONTROL OF DATA DEFINITIONS • REDUCES PROGRAM / DATA DEPENDENCE • REDUCES DEVELOPMENT / MAINTENANCE COSTS • ENHANCES SYSTEM FLEXIBILITY • INCREASES ACCESS / AVAILABILITY OF INFORMATION * DBMS

  13. ROOT Employer Job Benefits Compensation FIRST CHILD Assignments 2nd CHILD Ratings Salary Pension Insurance Health Database Models HIERARCHICAL DATA MODEL • Records are related hierarchically – each category is a subcategory of the next level up • Disadvantages of hierarchical databases • To retrieve a record, a user must start at the root and navigate the hierarchy. • If a link is broken, the entire branch is lost. • Requires considerable data redundancy

  14. NETWORK 1 NETWORK 2 NETWORK A NETWORK B NETWORK C NETWORK DATA MODEL • VARIATION OF HIERARCHICAL MODEL • Allows a record to be linked to more than one parent • USEFUL FOR MANY-TO-MANY RELATIONSHIPS

  15. RELATIONAL DATA MODEL • Consists of tables; links among entities are maintained with foreign keys • DATA IN TABLE FORMAT • RELATION: TABLE • TUPLE: ROW (RECORD) IN TABLE • FIELD: COLUMN (ATTRIBUTE) IN TABLE *

  16. STUDENT ID ONE-TO-ONE: CLASS ONE-TO-MANY: STUDENT A STUDENT B STUDENT C CLASS 1 CLASS 2 MANY-TO-MANY: STUDENT A STUDENT B STUDENT C TYPES OR RELATIONS

  17. Relational Operations • Data Manipulation • Select :is the selection of records that meets certain condition. • Project: is the selection of certain columns from a table. • Join : is the joining of data from multiple tables. • Structured Query Language (SQL) • International standard DDL and DML for relational DBMS. • Advantages of using SQL • Users do not need to learn different DDLs and DMLs. • SQL can be embedded in widely used 3rd generation languages, increasing efficiency and effectiveness. • Programmer not forced to rewrite statements since SQL statements are portable.

  18. Advantages and disadvantages of database models Database Models

  19. DatabaseArchitecture • Shared Resource and Client/Server Systems • Four basic client/server models • Applications run at a server • Applications run on local PCs • Applications run on both the local PCs and the server • Applications and key elements of the database are split between the PCs and the server

  20. A replicated database: each computer holds a copy of the entire database Database Architecture • Distributed Databases • Replication :Full copy of the entire database is stored at all sites

  21. A fragmented database: each computer holds only the part of the database that is most frequently accessed by the local users Database Architecture • Fragmentation: Parts of database are stored where they are most often accessed

  22. Web Databases • Databases on the Web • Catalogs • Libraries • Directories • Client lists and profiles • When linking a database to the Internet, consider • Which application to use • How to ensure Web surfers do not interfere with database updates • How to maintain security

  23. Data Warehousing • Data warehouse • Collection of data that supports management decision making • Phases in Building a Data Warehouse • Extraction Phase • Cleansing Phase • Loading Phase • Data Mining • Selecting, exploring, and modeling data to discover unknown relationships

  24. DataWarehousing

  25. Potential applications of data-mining Data-Mining

  26. DATABASEADMINISTRATION • DEFINES & ORGANIZES DATABASE STRUCTURE AND CONTENT • DEVELOPS SECURITY PROCEDURES • DEVELOPS DATABASE DOCUMENTATION • MAINTAINS DBMS *

  27. Ethical and Societal IssuesA Too-Risky Info Highway • Out of Hand -- Out of Control • DBMSs allow organizations to collect, maintain, and sell vast amounts of private personal data easily. • Where is the Information Going? • Many consumers provide information daily without being aware of where it is actually going. • http://www.publicrecordfinder.com/ • The Upside • Database technology enables better and faster services.
