lessons learned migrating applications to the windows azure platform
SVC30

Lessons Learned: Migrating Applications to the Windows Azure Platform

Wade Wegner

Senior Architect

Microsoft Corporation

agenda
Agenda
  • Lessons learned from real solutions
  • Four different scenarios
    • Internal line-of-business application
    • Autonomous services
    • E-commerce website
    • Video transcoding service
  • Q&A
speakers
Speakers
  • Joseph Paradi
    • Accenture
  • Gurleen Randhawa
    • CCH, a Wolters Kluwer business
  • David Haubenstricker
    • Domino’s Pizza
  • Mark Richards
    • OriginDigital
real world azure

Real World Azure

accenture

Joseph Paradi

Innovation Lead for Internal IT

Accenture

corporate concerns
Corporate Concerns
  • “The Pillars of Concern”
    • Authentication
    • Authorization
    • Data Synchronization
    • Security of Data
    • Application Integration
    • Operations / Management
  • Minimize the cost/effort to move to Azure
before infrastructure
“Before” Infrastructure

Web App

Database

User

Web App 2

AD

after infrastructure
“After” Infrastructure

Web App

Windows Azure

Database

SQL Azure

User

Database

Web App 2

ADFS Server

AD

what did we find
What did we find?
  • Authentication – ADFS server against corporate AD in our DC
  • Authorization – ADFS custom claim to make the authorization decision
  • Data Sync – SSIS to push subset of rows and columns to SQL Azure
  • Security/Audit – specific to each organization and industry for data and operations
  • Application Integration – use of ADFS Passive Fed allowed Web SSO model between apps in different locations
  • Operations/Management – cannot use Windows Event Log and SCOM
  • Cost – very little code change to existing application; quick time to deliver
why is this cool
Why is this cool?
  • You already have the skills you need (Visual Studio, SSIS)
  • No infrastructure required! (assuming you already have ADFS)
  • Don’t worry about the plumbing, just build the application
  • Microsoft is providing the tooling and guidance to reduce the barrier to leveraging Azure
sales tax engine

SALES TAX ENGINE

CCH

Gurleen Randhawa

Development Manager

CCH, a Wolters Kluwer business

application overview
Application Overview
  • Sales Tax Office
    • Real-time sales tax calculation
    • Multiple business entities, multiple ERP modules or even different ERP systems
  • Sales Tax Office works behind the scenes with minimal user interaction
original architecture
Original Architecture

Web Client

Web Server

RDB

App Server

Admin Client

cloud architecture
Cloud Architecture

App Server

Admin Client

Web Client

Web Services

RDB

challenges
Challenges
  • Plex (3rd party libraries)
  • State management
  • Performance
  • Security
  • Database migration
  • Database partitioning
lessons learned
Lessons Learned
  • Be prepared to sacrifice hardware and software control in exchange for lower maintenance costs.
  • Log, log and log. Verbose logging will make application troubleshooting easier.
  • Design your systems for scaling out, not up. If dealing w/ an existing system some code refactoring may be necessary.
  • Use database partitioning techniques (the database also has to scale out due to the 10 GB limitation on the db size).
  • Plan your data migration.
  • Store sensitive customer data on premises.
  • Use proper State management techniques - think “Stateless”.
pizza delivery platform

Pizza Delivery Platform

Domino's Pizza

David Haubenstricker

Enterprise Architect

Domino’s Pizza

current architecture
Current Architecture

Java / Tomcat Solaris

VB6/C#

Win2000/2003

Web

SOA

Stores

VPN

Web

SOA

Stores

Stores

RDB

Oracle

Cisco

co deployed architecture
Co-Deployed Architecture

Web

SOA

Stores

VPN

Web

SOA

Stores

Stores

RDB

Web

SOA

Stores

VPN

Web

SOA

Stores

Stores

RDB

azure runs java
Azure Runs Java

Web

SOA

Web

Web

SOA

SOA

Stores

VPN

Web

SOA

Web

Web

SOA

SOA

Stores

Stores

RDB

Web

SOA

Stores

Migrate (Relatively) Easily

VPN

Web

SOA

Stores

Stores

RDB

connection issues
Connection Issues

Svc Bus

Svc Bus

Web

SOA

Stores

VPN

Web

SOA

Stores

Stores

RDB

Web

SOA

Stores

No Hardware Allowed

VPN

Web

SOA

Stores

Stores

RDB

data issues
Data Issues

Svc Bus

Web

SOA

Stores

Web

SOA

Stores

Stores

Azure

Storage

Azure

Storage

RDB

Hot Spot

Sharding?

Web

SOA

Stores

VPN

Web

SOA

Stores

Stores

RDB

Key-Value

Storage

Key-Value

Storage

pain in the cloud
Pain in the Cloud

Svc Bus

Web

SOA

Stores

Web

SOA

Stores

Stores

Azure

Storage

Web

SOA

Stores

VPN

Web

SOA

Connectivity

Differences

Logging

Differences

Storage

Differences

Stores

Stores

Key-Value

Storage

solution abstraction layer
Solution: Abstraction Layer

Application

Abstraction Layer

Azure Technology

Domino’s

Technology

Domino’s

Technology

Domino’s

Technology

take aways
Take aways
  • Java runs in Azure
  • Service Bus provides VPN like connectivity
  • Azure storage technologies are easily abstracted
mark richards vp business development origin digital
Origin Digital

Mark Richards

VP, Business Development

Origin Digital

overview
Overview
  • Application Overview
    • Build a video and audio transcoding solution based on the Windows Azure cloud computing platform
  • Key Business Goals
    • Decrease transcoding costs
    • Provide greater scalability
    • Greater Geographic distribution
  • Platform Adoption Driver
    • The key factor driving Azure adoption is to be able to cost effectively respond to changing customer demands and volumes
odaptor overview
Odaptor Overview

XYZ Corporation

File Upload

UGC, Corporate content, etc…

Odaptor File Upload

HTTP Post, iFrame, Silverlight, Flash

Odaptor

CMS

Source Media File

Postback with Asset Information

Transcoded Files

CDN

Akamai, Limelight, Azure etc..

Video/Audio

Transcoding

solution architecture
Solution Architecture

Transcoding Worker Role

Manager Worker Role

Web Role

File Uploads

CDN’s

Blob

Queue

challenges1
Challenges
  • Finding and implementing a inexpensive and reliable software based encoding, and implementing it in the cloud
  • Determining an algorithm for auto scaling
  • Working with pre-release SDKs, as they tend to change
  • Deployment and release process
benefits
Benefits
  • Significant cost savings versus existing transcoding hardware and software
  • Ability to quickly and cheaply respond to varying demand levels
  • Ability to easily provide geographically relevant solutions to our customers
slide32
