slide1

Authorized Access Only: Providing Secure Internet Access to Patient Information using Windows 2000 Server

Rex E. Gantenbein, Ph.D.

Center for Rural Health Research and Education

University of Wyoming

technological solutions
Technological solutions
  • Telecommunications
  • Databases
  • Geographic information systems (GIS)
  • Internetworking

Information Portal

technological problems
Technological problems
  • Interoperability
  • Scalability
  • Data integration
  • Quality of service
  • Privacy and security
creating a secure information portal
Creating a secure information portal
  • Security requires us to maintain:
    • Integrity of data
    • Confidentiality of data (storage and transit)
    • Availability of data
    • Authorization of users
    • Accountability of users
basis for our solution
Basis for our solution
  • NASA JSC Countermeasures and Evaluation Project (CEVP) database
    • Developed by Wyoming research team
    • Designed to efficiently disseminate life science data to discipline experts and extramural investigators
    • Centralized storage and distribution center for NASA life science research data
    • Provides multi-level security and Internet access to data
  • Resulting technology now being adapted for a secure health information portal
creating a secure information portal10

Internet

SECURE LAN

Firewall

Domain controller

Firewall/Router

UPS

Datamart

Hub

UPS

Data warehouse

JetDirect

UPS

Switch

Data warehouse

Printer

LAN printer

Tape backup

Desktop workstations

UPS

Local printer

Public Web server

www.health.uwyo.edu

Creating a secure information portal
creating a secure information portal11
Creating a secure information portal
  • Firewall
    • 2 NIC Server Cards w/onboard encryption capability, i.e. 3COM 3CR990SVR97)
    • Microsoft Windows 2000 Server
    • Microsoft ISA Server, Enterprise Edition
  • Domain Controller
    • NIC Server Cards w/onboard encryption capability
    • Microsoft Windows 2000 Server
    • Microsoft Access 2000 or Office 2000 w/Access
    • Microsoft Visual Studio
creating a secure information portal12
Creating a secure information portal
  • Datamart
    • NIC Server Cards w/onboard encryption capability
    • Microsoft Windows 2000 Advanced Server
    • Microsoft Internet Information Server
    • Microsoft SQL Server
    • Microsoft Access 2000 or Office 2000 w/Access
  • Data warehouse
    • NIC Server Cards w/onboard encryption capability
    • Microsoft Windows 2000 Advanced Server
    • Microsoft Internet Information Server
    • Microsoft SQL Server
creating a secure information portal13
Creating a secure information portal
  • Public Web server
    • NIC (Server card)
    • Microsoft Windows 2000 Advanced Server
    • Microsoft Internet Information Server
creating a secure information portal14
Creating a secure information portal
  • Tape backup unit
    • HP SureStore robotic tape drive
    • Seven 80-GB tapes
  • Networking
    • 24-port switch for secure LAN
    • 8-port hub for external LAN
    • Firewall/router for Internet protection
  • Printers
    • Internal printer for secure LAN
    • Network printer for external LAN
    • Local printer for public Web server
supporting secure connections
Supporting secure connections
  • Secure data storage
  • Multiple levels of authorization
  • Virtual private networking
data warehousing
Data warehousing
  • Public Web server and non-secure machines reside in DMZ (semi-public LAN)
  • Data warehouses reside in secure LAN
    • Local (administrator) access only
    • Physically secure
    • Can be disconnected from network
  • Datamart also resides in secure LAN
    • Accessible from Internet
    • Stores data authorized for off-site use
dmz implementation
DMZ implementation
  • Internet connections protected by virtual private networking (Windows 2000)
    • Authorization (ticket) via Kerberos utility
    • Authentication via passwords
    • Encrypted communication between server and remote user
  • IP addresses of servers locally defined
    • No public DNS names except entry point
dmz implementation18
DMZ implementation
  • Firewall is configured to deny all requests from machines outside the network except through VPN
  • Domain controller acts as Kerberos key distribution center for authentication and public key encryption
  • These machines cooperate to carry out local network address translation
virtual private networking
Virtual private networking
  • VPN extends the secure LAN over the Internet
    • Authenticates both ends of the connection and encrypts information passing between them
    • Built into Windows 2000 Server
benefits of a secure portal
Benefits of a secure portal
  • Improved access to health-related data (overcoming geography)
  • Increased confidence in use of Internet for health information (overcoming fear)
center for rural health research and education
Center for Rural Health Research and Education

http://www.health.uwyo.edu/

Rex Gantenbein, Technical Director

Voice: 307.766.6549

Fax: 307.766.6608

Email: rex@uwyo.edu
