troubleshooting windows deployment with microsoft deployment toolkit 2010 lite touch
WCL404

Troubleshooting Windows Deployment with Microsoft Deployment Toolkit 2010 Lite Touch

Johan Arwidmark

Chief Technical Architect

Knowledge Factory

agenda
Agenda
  • Audience check
  • Debugging MDT 2010 Lite Touch
  • Troubleshooting
  • Common Issues
  • Test environment
audience check
Audience Check
  • Familiarity with BDD, or MDT 2008/2010
  • This is a 300-level session
  • We only have 75 minutes
    • Please save your questions to Q&A in the end of the session
debugging mdt 2010
Debugging MDT 2010
  • Use the TRACE32 Utility to read log files
    • Part of the ConfigMgr 2007 Toolkit
    • Works in WinPE too
  • Logs are initially stored in
    • C:\MININT\SMSOSD\OSDLOGS
  • Add Command Shell via F8
mdt 2010 deployment logs
MDT 2010 Deployment Logs
  • BDD.log
  • SMSTS.log
  • Wizard.log
  • LiteTouch.log
  • <ScriptName>.log
windows pe 3 x logs
Windows PE 3.x Logs
  • WPEinit.log
  • Setupapi.dev.log
windows setup logs
Windows Setup Logs
  • Device Drivers issues
    • XP / 2003 – Setupapi.log
    • Windows 7 / 2008/R2 - Setupapi.dev.log, cbs.log, dism.log
  • Other Setup issues
    • Setupact.log
    • Setuperr.log
go with the flow
Go with the flow...
  • Troubleshooting Reference Doc
    • C:\Program Files\Microsoft Deployment Toolkit\Documentation
dealing with error codes
Dealing with Error Codes
  • Converting Error Codes
    • An image capture fails with error code 0x80070040
    • Convert the last 4 digits to decimal = 64
    • Use Net Helpmsg 64
      • The specified network name is no longer available
windows pe issues
Windows PE Issues
  • Memory
    • WinPE requires 512 MB RAM
  • Drivers
    • Use monolithic version of two-tier drivers
  • Left over Junk may prevent setup
  • Filesystem ”converted” into RAW
    • The Windows PE Uberbug
  • Use the latest version
pxe issues
PXE Issues
  • DHCP Configuration
    • DHCP and WDS on the same server
      • Configure WDS not to listen on port 67
      • Allow it to configure the 60 PXE option
    • DHCP and WDS on different Subnets
      • Configure IP Helpers
  • Enable Tracing on the WDS Server
join domain issues
Join Domain issues
  • Verify AD Permissions
    • Create / Delete Computers
    • Update existing Computers
  • For both XP and Windows 7
    • Examine C:\Windows\Debug\Netsetup.log
misc common issues
Misc Common Issues
  • Blocked Applications
    • Unblock
    • Use Streams –d <filename>
  • Drivers
    • PNPID Detection vs. Old School
database issues
Database Issues
  • Named Pipes not enabled
  • Missing permissions
    • On the stored procedure
    • On the MDT database
create a test environment
Create a TEST Environment
  • Copy the following files to C:\Debug
    • CustomSettings.ini
    • ZTIGather.wsf
    • ZTIGather.xml
    • ZTIUtility.vbs
    • ZTIDataAccess.vbs
  • Create a batchfile with the following
    • if exist c:\minint\nul rd c:\minint /s /q
    • cscript.exe ZTIGather.wsf /debug:true
