Presentation Transcript
slide2

MVVM In Real Life

Partner logo to

go here

John Sotiropoulos

Chief Architect, Metastorm – part of OpenText

@metastorm

http://www.processmatters.com

jsotirop@opentext.com

slide3

MVVM often raises temperatures, causes high spirited debates, and can lead to ruined pub lunches.

Looking at how and why is being used in commercial enterprise applications may provide a useful insight.

slide4

Who is Metastorm?

  • A leader in Enterprise Architecture (EA), Business Process Analysis (BPA) and Business Process Management (BPM).
  • Brings people, technology, and processestogether in order to solve specific problems and connect strategy to execution.
  • Recently acquired by leading Content Management vendor OpenText.
slide5

Leaders in all process-related markets

Business Process Management SuitesMagic Quadrant Q410

Business Process Analysis Magic Quadrant Q110

Enterprise Architecture

Magic Quadrant Q410

IT Planning

Forrester Wave Q109

Enterprise ArchitectureForrester Wave Q109

Business Process Management Suites Forrester Wave Q310

Business Process Analysis

Forrester Wave Q109

slide7

MVVM raised temperatures

  • Confining the MVVM discussion to a “design pattern” led to conflicting views.
  • But MVVM is not just another technique.
  • MVVM liberates the design of User Experience to bring the user and developer together.

Why this extra work?

It’s too complex

No pub lunch with you

Design Patterns are important!

slide8

Where we used MVVM?

The Silverlight-based Business Workspace, is a common framework for building all our end-user applications

Including our free Azure M3 modeling application.

http://m3.cloudapp.net/

slide10

Initial Development Workflows

Review

Describe

Design Mockups

Prototype & Develop

slide11

Some early disconnects

Mock up

Implementation

slide13

Key Concerns

  • Developers, and not UI Experts, were designing the UI.
  • They were interpreting graphical mockups and it caused disconnects.
  • We introduced Silverlight mockups which improved communication and reduced cycles but the interactivity was limited and it the design-abilty was often lost.
  • Merging mock-ups caused integration defects and delayed user
  • reviews and acceptance.
slide14

and so we moved to this workflow

Designer

User

Widget UI

(XAML View)

Real / “Live” UI

ViewModel

Model

Developer

REST Service

slide15

Initial MVVM Adoption

  • Only Notify Property Changed Implemented, e.g
  • public class GridViewModel : INotifyPropertyChanged
  • {
  •         private IList _rows = new ObservableCollection<object>();
  •         private readonly Func<object> _createNewRow;
  •         public GridViewModel()
  •         {
  •             _createNewRow = () => new GridRowModel(null);
  •             AddGridRowCommand = new DelegateCommand<object> (ExecuteAddGridRowCommand);
  • }
slide16

Our MVVM Adoption Evolved

  • Moved towards re-use using base class that only wrapped INotifyPropertyChange
  • public class ViewModelLight : INotifyPropertyChanged, ICommandManager
  •     {
  •         public event PropertyChangedEventHandler PropertyChanged;
  •   ……
  • }
  • Then Expanded to a home-grown MVVMLight and an MVVM View Model Class
    • public class ObservableObject : DependencyObject, INotifyPropertyChanged, IDataErrorInfo {. Core object.}
    • public abstract class ViewModel : ObservableObject, IViewModel {…}
  • Learn from others and re-use: we are now looking to adopt
  • MVVMLight
slide17

It was not all plain sailing…

  • Steep learning curve / additional effort.
  • Overkill for some simple cases where UI is not all that critical.
  • Technical challenges in complex interactions (especially widget to widget events).
  • Verbose duplication in data bindings and standard approaches in a large and distributed team– Homegrown equivalent to MVVMLight.
slide18

But we also noticed…

  • MVVM decoupled UI and facilitated agile responses to changes.
  • UIs designed by the UI specialist topped, regularly, user acceptance.
  • Using MVVM educated our market-eers and users to what is feasible and made them more educated on the controls available.
  • MVVM-designed features were more stable and had more unit tests and automation tests.
slide19

Both M3 and the Smart Business Workspace were the highlight of our user conference and have received a great response from analysts and customers alike.

MVVM has been critical in making these products successful.

It forced a user-centric shift in our software development

slide21

Dynamic MVVM

  • We took MVVM a step further…
    • Applied it to business processes to allow end-user mash up extensibility.
    • Users can create their own data mash-ups, connected widgets, and interactive storyboards.
slide22

Dynamic MVVM overview

User Defined UI – Mock up of needs

Deployment

Service

Model

Data mashups

(REST + ODATA)

Auto generated ViewModel

Polished UI in

Blend

slide24

Some lessons learned

  • Round tripping too complex for full UI round tripping.
  • MVVM Requires Product UI Designer skills to get real value.
  • ODATA and a centralized model management helps ViewModel generation.
  • REST ODATA Services are easily accessible and help portability of the UI for the developer /designer round-trip.
  • Eventing can become complex and needs a central event bus.
slide25

What we think now

  • The learning, investment, and challenges is worth it, if the UI is important.
  • Re-Investing the gains in UI productivity in unit test and robust app logic is a good way to highlight the value of separating concerns.
  • MVVM is a product development issue, not just a technical choice.
  • Application Design-ability, is a trend that will move to other platforms, including HTML5
slide26

What’s cooking in our research labs

  • We are looking at using the separation of concerns in more specialised Business Process Design and management and beyond Silverlight.
  • Using ODATA and jQuery for MVVM-like approach in HTML/HTML5.

Metastorm BPM Designer

Process-connected HTML

slide27

Partner logo to

go here

John Sotiropoulos

Chief Architect, Metastorm – part of OpenText

@metastorm

http://www.processmatters.com

jsotirop@opentext.com
