Fault injection tool

Fault Injection Tool

Pavel Čírtek

Fault injection tool


  • Introduction

  • C-Sim based components

  • Fault injector component

  • Conclusion

Fault injection tool


  • Fault tolerant systems are used in safety critical applications.

  • Fault tolerant (FT) system – a system that provides required functionality even in the presence of faults.

  • Safety critical application – the cost of a failure is much higher than the price of the system, e.g. human lives are in danger, a production plant is stopped.

  • Real-time (RT) system – the system responds to events immediately as they occur. Hard RT systems provide guaranteed deadlines.

Fault injection tool

Fault tolerance
Fault Tolerance

  • A fault is a random or malicious defect introduced to the system. A fault may cause an error state of the system.

  • A system enters error state if its normal operation can not be performed anymore (due to a fault). A recognized error does not mean a failure of the system.

  • The system fails if it no longer meets the requirements for proper functions.

Fault injection tool

C sim based components
C-Sim based components

  • Simulation library

  • Simulation world

  • Simulation model

  • Simulation program

Fault injection tool

Simulation library
Simulation library

  • A simulation library is a set of object types definitions and it is not executable itself.

  • Object type can be:

    • passive (LINK, HEAD)

    • active (PROCESS)

  • Construction for creating object type:

    • typedef struct {…} TYPE_NAME;

  • Types methods can be created as C language functions with one parameter typed as TYPE_NAME*.

Fault injection tool

Simulation world
Simulation world

  • Simulation world is on object type that describes an activity, i.e. it is a process type or it contains at least one attribute of a process type or it contains an attribute of another world type

  • Public methods:

    • Constructor

    • Interaction(s) - functions to exchange data

    • Execution - specializad constructor. Creates a separate event list.

Fault injection tool

Sim model and program
Sim. model and program

  • Simulation model (SM) is a statically structured set of simulation worlds.

  • Sim. model instance is interconnected set of simulation worlds instances.

  • Sim. program (SP)executes sim. model.

  • Functions in sim. program:

    • init -creates a model instance

    • some form of main - simulation loop (because of present C-Sim doesn’t support a world execution constructor)

Fault injection tool

Fault injector component
Fault injector component

  • Problem of construction of an universal fault-injector component (world FIC)

  • It should be attached to any C-Sim based simulation model of FT system (world MFTC)

  • Two basic types of fault injection:

    • asynchronous – FI emits fault whenever

    • synchronous – FI emits fault according to model-time value and/or its internal state

Fault injection tool

Simulation world of fi
Simulation world of FI

  • Constructor (if any) only prepare environment for creating faults

  • Type of fault is a class that have its own constructor and attributes

  • A fault is an instance of this class

  • State of fault:

    • active – fault injection already running

    • passive – fault is waiting for an activation

Fault injection tool

Fault types
Fault types

  • Single-bit fault – random setting of a bit within a continuous memory array

  • Multiple fault – group of M single-bit faults in one model time-point

  • Burst of faults – Poisson stream of K multiple faults

  • Stream of bursts – Poisson stream of events, where one event means one burst of faults

Fault injection tool

Fic config table
FIC config table

  • FIC config table (FICC)– one row describes one fault:

    • pointer to fault

    • state

    • index (key)

  • One instance of FICC should “inter-connect” both worlds FIC and MFTC

Fault injection tool

Interaction mftc to fic
Interaction (MFTC to FIC)

  • FIC have to have method run_fault(). This function is called from an instance of MFTC world whenever it wants to “trigger fault”

  • Parameters:

    • Pointer to FICC instance – identifies the interconnection object

    • Index (key) into FICC – selects the fault

Fault injection tool

Interaction fic to mftc
Interaction (FIC to MFTC)

  • MFTC should have methods:

    • fi_result() – returns a result of (a previous) fault injection. Parameter of function should be a pointer to FICC instance and index into FICC

    • init_fi() – should be called during SM construction. Parameter is pointer to FICC instance.

Fault injection tool


  • Three main ways of interaction:

    • From FIC to MFTC:

      • the fault injection itself (asynchronous faults)

      • the test of injection result

    • From MFTC to FIC

      • calling a fault (synchronous faults)

Fault injection tool


  • initialization function should do following steps:

    • create instance of MFTC (using its constructor)

    • create instance of FIC (i.e. create all necessary faults instances)

    • create instance of FICC and fill fault parameters into rows of table

    • call MFTC init_fi() function

Fault injection tool


  • current version of FIC is customized for a TTP/C protocol based on FT systems

  • advantages of this solutions:

    • universal FI component

    • synchronous fault calling

  • disadvantages:

    • no easy way for massive faults injection experiments

Fault injection tool
