Forging new generations of engineers

Feb 18, 2012

190 likes | 394 Views

Tolerances. Variation is Unavoidable. No two manufactured objects are identical in every way. Some degree of variation will exist.Engineers apply tolerances to part dimensions to reduce the amount of variation that occurs.. ANSI/ASME Standard. ANSI/ASME Standard Y14.5Each dimension shall have a tolerance, except those dimensions specifically identified as reference, maximum, minimum, or stock. The tolerance may be applied directly to the dimension or indicated by a general note located in the 34135

arlais

Download Presentation

Forging new generations of engineers

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

4. ANSI is an acronym that stands for the American National Standards Institute. ASME is an acronym that stands for the American Society of Mechanical Engineers.ANSI is an acronym that stands for the American National Standards Institute. ASME is an acronym that stands for the American Society of Mechanical Engineers.

20. Three Types of Fit There are three types of fit that should be considered when working with tolerances. Clearance Fit- have limits of size so prescribed that a clearance always results when mating parts are assembled. Interference Fit- have limits of size so prescribed that an interference always results when mating parts are assembled. Transition Fit- have limits of size indicating that either a clearance or an interference may result when mating parts are assembled.
