Cyclone Separator

Cyclone Separator are ideal for separating dust with particle size greater than 5 um. Cyclone Separator provides a very cost effective solution to the problems of dust collection, materials and for conveying bark and chips. Cyclone Separator unit basically consists of a cylindrical and a conical portion. As the dust leaden air enters the inlet port, it spirals downwards in an outer vortex and comes out of the unit in an inner vortex.

It uses centrifugal force for the separation of particles. Centrifugal action causes the air material to move around the inside walls of the cyclone, from where the material drops by force of gravity at the bottom leaving the air to escape through the top.


AIRFILT TECHNOLOGIES is one of the most trusted name in the field of industrial ventilation equipment and pollution control equipment. We engineer technology that ensures 100% pollution control and perfect industrial ventilation. At Airlift Technology, quality is imperative. With efficient in-house testing facilities, we have established a name for delivering flawless products consistently.

Incepted in the year 1996 by the name of Venticon Engineers. In the year 2000 the company was changed to M/s Airfilt Technologies Pvt. Ltd.

We are well equipped with all latest and advance machinery to cater to all sorts of industrial and commercial requirements. We are one of the most trusted name in the field of ventilation equipment, pollution control equipment, air pollution control equipment. Our team comprises of dedicated engineers & experts. A separate team of workers, who undertake the site work and commissioning of the equipment. Apart from this, we have a dedicated team of designers, draughtsman, technicians, erectors-fabricators etc.

For more information –

C-51, Bali Nagar,Behind Rajdhani College, New Delhi – 110 015India

Mobile.No: + 91 9810022367

Tele Fax: +(91)-(11)-25162303 , 25432191
