1. MRAM: Giant and Tunneling Magnetoresistance Phenomena
2. Outline
GMR
TMR
MRAM
3. Giant magnetoresistance (GMR) Magnetic metallic multilayers
(Fe/Cr or Co/Cu)
Ferromagnetic layers
separated by
nonmagnetic metal
layers of a few nm thick
Magnetic field
Resistance changes
4. Definition of GMR GMR(%) = (RAP-RP)/RP
with
RAP: Resistance in
the antiparallel configuration
RP : Resistance in
the parallel configuration
5. Origin of GMR
6. Different conductivities
High conductivity of Cu
In ferromagnetic 3d metals the d band is exchange-split
High conductivity of majority-spin channel
Low conductivity of the minority-spin channel Origin of GMR
7. Interface
Good band matching
? High transmission for the majority-spin electrons
Large band mismatch
?Weak transmission of the minority-spin electrons
Interface Co/Cu = spin-filter
Origin of GMR
8. Tunnel Magnetic Resistance Effect Spin dependant tunneling
d band : Split exchange
9. Tunnel Magnetic Resistance Effect Julliere’s Modell
2 Assumptions :
Spin conservation during tunneling
Current # Density of states
10. Tunnel Magnetic Resistance Effect Magnetic Tunnel Jonction
11. MRAM Bit Cell TMR effect ? 30 – 50%
2 resistance values ? 2 bit states
Bit cell :
12. MRAM Reading Process Measurement of the bit cell
resistance by applying a current
in the ‘bit line’
Comparison with a reference
value mid-way between the bit
high and low resistance values
13. MRAM Writing Process Currents applied in both lines
? 2 magnetic fields
Both fields are
necessary to reverse
the free layer magnetization
When currents are removed :
Same configuration
? Non-volatile memory, Low power consumption
14. MRAM Device Bit cells arranged in array:
Need of 2 magnetic fields for writing
15. Improvements I Two pinned layers, separated by a thin coupling layer to allow for antiferromagnetic coupling
Increases resistance against
external fields
Smaller size possible
16. Writing Processes
Toggle Writing
Flips the direction of the free layer by a rotating current
Only one current direction required
Thermally Assisted Writing
Heating the cell before writing to make it more susceptible to magnetic fields
Spin Torque Transfer
Writing by injecting spin-polarized current into the device
Promises higher memory densities and faster write speeds Improvements II
17. Comparison with other Tech Volatile
DRAM
High power consumption due to continuous refresh
SRAM
Very fast, but not as dense as DRAM Nonvolatile
Flash
Slow and limited write cycles
18. History & Commercialization 1988 Discovery of GMR by Peter Grünberg and Albert Fert (Nobel Prize 2007)?
2000 IBM and Infineon establish joint research program
2003 First MRAM chips sold by Cypress, 128KBit
July 2006 Freescale starts selling 4MBit chips
August 2007 IBM and TDK to start researching spin-momentum-transfer for 65nm – MRAM - chips
19. Future Depending on the material, the superparamagnetic effect does not allow single MRAM cells to become smaller than around 10nm
Semiconductor processes will, at current development speed, reach 10nm at around 2015
MRAM will have to be developed into a working and economically producable and competetive product before then.
