1. 1 Deploying Carrier Ethernet Services to the Customer12-Sep-2005
2. 2 Yossi Saad VP Marketing and BD
Actelis Networks Inc.
+1 (301) 649 2653
yossi.saad@actelis.com
3. 3 Agenda Ethernet in the First Mile (EFM)
EFM Overview
EFM Applications
Practical considerations when using EFM
4. 4 Ethernet in the First Mile (EFM)
EFM Overview
EFM Applications
Practical considerations when using EFM
5. 5 Universal Etherent Access
6. 6 Two Access Network Paradigms The journey towards a true broadband society has started, with broadband penetration growing day by day.
But will the current path operators are traveling on allow them to achieve this kind of society? Will operators find a way to a profitable broadband destination, if they continue in the current direction?
We believe that it’s time to make a choice.The journey towards a true broadband society has started, with broadband penetration growing day by day.
But will the current path operators are traveling on allow them to achieve this kind of society? Will operators find a way to a profitable broadband destination, if they continue in the current direction?
We believe that it’s time to make a choice.
7. 7 The ATM-way
8. 8 The Ethernet Way
9. 9 Ethernet – Universal Communications Outlet Service independent interface
Bandwidth independent interface
10. 10 What’s the optimal Access Medium? Optical fiber provides:
High (unlimited) bandwidth
Long reach
High quality transmission
Resilience to interference
EFM defines optical access:
Point to point
Point to Multipoint (PON)
11. 11 Does Fiber Need Help?
12. 12 Ethernet in the First Mile Interfaces EFMCu
2Base-T
Long reach, SHDSL-based
Minimum of 2 Mbit/s up to 2.7 km
10Pass-TS
Short reach, VDSL-based
Minimum of 10 Mbit/s up to 750 meters
P2P OLT
1000Base-BX: up to 10km
P2MP OLT
The 1000BASE-PX10 and 1000BASE-PX20 PMD sublayers provide point-to-multipoint (P2MP) 1000BASE-X connections over passive optical networks (PONs) up to at least 10 km and 20 km, respectively and with a typical split ratio of 1:16.
EFMCu
2Base-T
Long reach, SHDSL-based
Minimum of 2 Mbit/s up to 2.7 km
10Pass-TS
Short reach, VDSL-based
Minimum of 10 Mbit/s up to 750 meters
P2P OLT
1000Base-BX: up to 10km
P2MP OLT
The 1000BASE-PX10 and 1000BASE-PX20 PMD sublayers provide point-to-multipoint (P2MP) 1000BASE-X connections over passive optical networks (PONs) up to at least 10 km and 20 km, respectively and with a typical split ratio of 1:16.
13. 13 802.3ah EFM Interface Applications
14. 14 EFM Copper - Short Reach 10PASS-TS Business and Residential access over existing copper loops.
Existing (Cat-3) copper loops with POTS left unaffected.
Reach for Ethernet over copper increased up to 750m.
Ethernet Speed – minimum 10Mbps symmetrical
Based on VDSL (DMT) line-code
Typical applications: MTU/MDU service distribution, intra-campus connectivity
15. 15 EFM Copper - Long Reach2BASE-TL Ethernet access across the serving area
Reach for Ethernet over copper increased at least to 2700m (could extend up to 6km)
Symmetrical bandwidth – from 2Mbps up to 45Mbps
Based on Extended SHDSL (ITU-T G.991.2. rev. 2)
Enabler for consolidation of disturbing E1/T1/HDSL sources
Typical applications: service delivery from CO, DSLAM backhaul, cellular/WiFi backhaul
16. 16 EFM Fiber Point-to-Point100BASE-LX & 100BASE-BX Business and Residential access over Single Mode Fiber
Single fiber (100Base-BX10) or dual fiber (100Base-LX10)
Reach for Ethernet over fiber increased up to 10 km.
100Mbps – Direct fiber access at lowest possible cost
Options defined for either single or dual fiber infrastructure
Dedicated fiber per user – flexibility for future upgrades
17. 17 EFM Fiber Point-to-Point 1000BASE-LX & 1000BASE-BX Business and Residential access over Single Mode Fiber
Single fiber (1000Base-BX10) or dual fiber (1000Base-LX10)
Reach for Ethernet over fiber increased up to 10 km.
1Gbps – Maximized performance to each user.
Options defined for either single or dual fiber infrastructure
Dedicated fiber per user – flexibility for future upgrades
18. 18 EFM Fiber Point-to-Multipoint1000BASE-PX Business and Residential access over Single Mode Fiber
Reach for Ethernet over fiber increased up to 10/20km.
1Gbps – Available bandwidth shared by up to 16 users
Fiber loop designed to concentrate traffic to few fibers.
An Ethernet based alternative for Passive Optical Networks.
19. 19 Ethernet in the First Mile Interfaces Enabling Ubiquitous Ethernet Services
20. 20 Ethernet in the First Mile (EFM)
EFM Overview
EFM Applications
Practical considerations when using EFM
21. 21 Metro Ethernet Access Fiber and Copper Complement Each Other
22. 22 Multi-Tenant Unit Ethernet Service Over Existing Copper Pairs
23. 23 Residential FTTH – Triple Play
24. 24 Ethernet Over Copper BackhaulIP DSLAM and 3G/3.5G Base-stations Backhaul
25. 25 Ethernet in the First Mile (EFM)
EFM Overview
EFM Applications
Practical considerations when using EFM
26. 26 EFMCu Long-Reach Architecture
27. 27 EFMCu – Optimal Bonding for Ethernet Services
28. 28 EFM and Systems Implementation EFM defines an Interface, not a System
Some system level considerations are beyond the scope of EFM:
Ease of deployment / maintenance
High performance
Scalability
Carrier grade robustness (99.999% service availability)
The above issues can be addressed by:
Verify MEF-endorsed Certification
Specific system architecture
EFM vendor-specific extensions
29. 29 EFMCu Vendor-Specific Extensions Addressing System-Level Carriers Deployment Issues
30. 30 Summary Ethernet in the First Mile (EFM) defines the access for Metro Ethernet networks
EFM provides fiber and copper access for ubiquitous service
Business and residential service delivery
EFM is a mature, approved standard – EFM systems are already widely deployed
