Lesson 6-6. Trapezoids and Kites. 5-Minute Check on Lesson 6-5. L. LMNO is a rhombus. Find x Find y QRST is a square. Find n if m TQR = 8n + 8. Find w if QR = 5w + 4 and RS = 2(4w – 7). Find QU if QS = 16t – 14 and QU = 6t + 11.

Download Presentation
## Lesson 6-6

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**Lesson 6-6**Trapezoids and Kites**5-Minute Check on Lesson 6-5**L • LMNO is a rhombus. • Find x • Find y • QRST is a square. • Find n if mTQR = 8n + 8. • Find w if QR = 5w + 4 and RS = 2(4w – 7). • Find QU if QS = 16t – 14 and QU = 6t + 11. • 6. What property applies to a square, but not to a rhombus? (8y – 6)° (3x + 12)° 7 M O P 12 (5x – 2)° N Q R 10.25 U 6 T S 65 Standardized Test Practice: A C Opposite sides are congruent Diagonals bisect each other D B D Opposite angles are congruent All angles are right angles Click the mouse button or press the Space Bar to display the answers.**Objectives**• Recognize and apply the properties of trapezoids • Solve problems involving medians of trapezoids • Apply properties of kites**Vocabulary**• Trapezoid – a quadrilateral with only one pair of parallel sides • Isosceles Trapezoid – a trapezoid with both legs (non parallel sides) congruent • Median – a segment that joins the midpoints of the legs of a trapezoid**Polygon Hierarchy**Polygons Quadrilaterals Parallelograms Kites Trapezoids IsoscelesTrapezoids Rectangles Rhombi Squares**Trapezoids**Trapezoid CharacteristicsBases Parallel Legs are not Parallel Leg angles are supplementary (mA + mC = 180, mB + mD = 180) Median is parallel to basesMedian = ½ (base + base)½(AB + CD) base A B legmidpoint legmidpoint median C D base A B Isosceles Trapezoid CharacteristicsLegs are congruent (AC BD) Base angle pairs congruent (A B, C D) Diagonals are congruent (AD BC) M C D**Kites Characteristics**Two pairs of consecutive sides congruent AB AD and CB CD Diagonals are perpendicular AC BD Diagonals are angle bisectors BAC DAC and ABD CBD ADB BDC and BCA DCA Diagonal from noncongruent angles bisects other diagonal diagonal BD is cut in half Only one pair of opposite angles are congruent (the pair of angles formed by the non-congruent sides)ABC ADC A D B C**Example 1a**A. If WXYZ is a kite, find mXYZ. Since a kite only has one pair of congruent angles, which are between the two non-congruent sides, WXY WZY. So, WZY = 121. mW + mX + mY + mZ = 360 Polygon Interior Angles Sum Theorem 73 + 121 + mY + 121 = 360 Substitution mY = 45 Simplify. Answer: mXYZ = 45**Example 1b**B. If WXYZ is a kite, find NP. Since the diagonals of a kite are perpendicular, they divide MNPQ into four right triangles. Use the Pythagorean Theorem to find MN, the length of the hypotenuse of right ΔMNR. NR2 + MR2 = MN2 Pythagorean Theorem (6)2 + (8)2 = MN2 Substitution 36 + 64 = MN2 Simplify. 100 = MN2 Add. 10 = MN Take the square root of each side. Answer: Since MN NP, MN = NP. By substitution, NP = 10**Example 2**The top of this work station appears to be two adjacent trapezoids. Determine if they are isosceles trapezoids. Each pair of base angles is congruent, so the legs are the same length. Answer: Both trapezoids are isosceles.**Example 3**The sides of a picture frame appear to be two adjacent trapezoids. Determine if they are isosceles trapezoids. Answer: yes**DEFG is an isosceles trapezoid with median Find DG**if and Answer: Example 4a Theorem 8.20 Substitution Multiply each side by 2. Subtract 20 from each side.**DEFG is an isosceles trapezoid with median Find**, and if and Example 4b Since EF // DG, 1 and 3 are supplementary Because this is an isosceles trapezoid, 1 2 and 3 4 Substitution Combine like terms. Divide each side by 9. Answer: If x = 20, then m1 = 65° and 3 = 115°. Because 1 2 and 3 4, 2 = 65° and 4 = 115°**WXYZ is an isosceles trapezoid with median**a. Answer: b. Answer: Because Example 5**Quadrilateral Characteristics Summary**Convex Quadrilaterals 4 sided polygon 4 interior angles sum to 360 4 exterior angles sum to 360 Parallelograms Trapezoids Bases Parallel Legs are not Parallel Leg angles are supplementary Median is parallel to basesMedian = ½ (base + base) Opposite sides parallel and congruent Opposite angles congruent Consecutive angles supplementary Diagonals bisect each other Kites 2 congruent sides (consecutive) Diagonals perpendicular Diagonals bisect opposite angles One diagonal bisected One pair of opposite angle congruent Rectangles Rhombi IsoscelesTrapezoids Angles all 90° Diagonals congruent All sides congruent Diagonals perpendicular Diagonals bisect opposite angles Legs are congruent Base angle pairs congruent Diagonals are congruent Squares Diagonals divide into 4 congruent triangles**Summary & Homework**• Summary: • In an isosceles trapezoid, both pairs of base angles are congruent and the diagonals are congruent. • The median of a trapezoid is parallel to the bases and its measure is one-half the sum of the measures of the bases • Homework: • pg 440-42; 1, 6, 7, 16-21, 41
