  1. ACE-52NTU for Ethernet and E1/T1 Services over ATM Presented by: Robert Bell robert_b@rad.com ATM Product Manager

  2. Product Definition • The ACE-52 is a cost effective network termination unit that allows service providers to deliver transparent LAN services (10/100BaseT) and E1/T1 circuit emulation services over existing ATM infrastructure with no user exposure to ATM Branch Office FE ACE-52 E1 STM-1 PBX HQ Branch Office FE ATM Wide Area Network FE ACE-52 ACE-52 STM-1 STM-1 E1 PBX E1 PBX Branch Office FE ACE-52 STM-1 E1 PBX

  3. Product Application • The ACE-52 is installed at the customer’s premises and connected over fiber to an STM-1/OC-3 port of the ATM switch of an existing ATM WAN • No need for changes in the edge or the core • Fastest deployment • Minimal costs • Minimal risk ATM Wide Area Network Customer’s Premises ATM Switch Ethernet Switch ACE-52 STM-1 STM-1 Fiber Optic FE

  4. Product Features and Benefits

  5. Physical Description User interface: E1/T1 (CES) 8.5” wide 1U high User Interface: Fast Ethernet (FE) Copper or Fiber Network Interface: STM-1/OC-3c

  6. Interfaces • STM-1/OC-3 • Optical (1310nm) • Multi mode • Single mode short-haul (S1.1) • Single mode long-haul (L1.1) • Connector • SC or ST • SDH/SONET is software configurable • E1/T1 CES port • E1 Balanced/unbalanced • T1 Balanced • One or two Fast Ethernet ports • 10/100BaseT • Half/full duplex • Auto negotiation

  7. Summary • ACE-52 opportunity: • Allows service providers to leverage existing ATM infrastructure to meet the demand for transparent LAN services and for E1/T1 circuit emulation quickly with minimal costs and minimal risks
