Presentation Transcript
slide1

Latin American Spectrum Conference 2012

Mexico City October 24-25, 2012

Session on The Possibilities of 700MHz

October 25th 15.00 – 17.30

Stephen A. Wilkus

the ben e fits of wireless broadband social and economic ben e fits
The Benefits of Wireless Broadband Social and Economic Benefits

Currently, “there are over 6 billion mobile phone subscribers, 75% of the world’s population has access to a mobile phone, more than have access to a bank account, electricity or even clean water.” (World Bank 2012)

Developing countries are “more mobile” than developed, and are developing unique applications and services to empower local economies.

The world is increasingly “flat,” with the world’s information available to all.

Broadband growing faster in developing countries with over a 200% growth rate.

A 2008 Deloitte & Touche study found that the mobile industry in 6 countries was responsible for 3.7% to 6.2% growth in GDP and 0.2% to 1.1% growth in employment

A study by McKinsey & Company on Latin American countries stated that the combined GDP could increase by up to $70 billion, and add up to 1.7 million more jobs

Enriching & Developing people with access to “Symmetrical information”

us experience at 700 mhz early 2009
US Experience at 700 MHz early 2009

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz mid 2009
US Experience at 700 MHz Mid 2009

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz early 2010
US Experience at 700 MHz early 2010

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz late 2010
US Experience at 700 MHz late 2010

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz early 2011
US Experience at 700 MHz early 2011

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz mid 2011
US Experience at 700 MHz mid 2011

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz mid 20111
US Experience at 700 MHz mid 2011

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

us experience at 700 mhz current
US Experience at 700 MHz current

LTE

Used with Permission; Jeff Engel, D. Roberson, of IIT with funds provided by the National Science Foundation

Movie available at: http://www.youtube.com/watch?v=h-Ffq1kCvas

lte deployments now in the 700 mhz band
LTE Deployments now in the 700 MHz band
  • One Tier 1 Operator reports that over 35% of the data traffic now goes over LTE in 700 MHz.
  • Over 75% of US population now has access to LTE service, overwhelmingly from the 700 MHz band.
challenging interference issues near border
Challenging interference issues near border

Interference

Interference

Only the worst cases of interference are highlighted.

Filter 2

Filter 1

Filter 2

Filter 1

Substantial interference issues throughout the band requires careful coordination within 110km of US Mexican border. Particularly challenging for Public Safety (PS) with noise limited long-range systems on high towers.

lte s carrier aggregation enabling much more flexible use of spectrum
LTE’s Carrier Aggregation Enabling Much More Flexible Use Of Spectrum
  • LTE-Advanced Rel-10 (first office applications in 2013) introduces Carrier Aggregation (CA).
  • CA of different size and numbers of carriers, inter-band and intra-band Component Carriers.
  • Downlink-only Carriers to be supported (such as Lower 700 MHz D&E blocks.)
  • This provides new opportunities for unleashing stranded bands such as AWS-3, WCS, and Lower-700 MHz A block, where uplinks have been problematic.
  • Methods are emerging for improving UL Spectral Efficiency, more so than DL SE.
  • But… there are CA combination restrictions, complications of radios and stresses on signaling channels.

Traditional band plan

With Carrier Aggregation

GuardBand

A

B

C

D

A

B

C

D

GuardBand

C

A

B

B

C

D

C

Another Band

Downlink

Uplink

Downlink

Uplink

A

B

key takeaways
Key TakeAways
  • Demand is outstripping spectrum supply  Need for DD
  • Creative use of CarrierAggregation & Small cells require regulatory and community support
    • It’s not just spectrum any more.
  • Packing Broadcast TV unleashes spectrum for Mobile BB
  • Spectrum Considerations:
    • 700 MHz APT band plan will provide good economies of scale
    • Learning curve suggests that doubling the cumulative quantityproduced reduces costs by ~ 15%. 10X  50% FOR COMPONENT.
    • RF Front End Module costs less than about $3.
    • Border interference should be manageable at the low frequency end effectively. Without careful coordination, US Public Safetyinterference is more problematic.PS Terminals will cause interference to APT-700 terminals at high frequency end.
    • There is much more downlink traffic than uplink.
  • The benefits of mobile broadband are enormous, and fun!

9362 Enterprise Cell

incentive auctions
Incentive Auctions
  • FCC released Incentive Auction NPRM from last Wednesday’s meeting:http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC-12-118A1.pdf
  • 1st stage reverse auction: for full-power and Class A TV licensees and allows participants to
    • (a) relinquish a 6 MHz license,
    • (b) channel-share, or
    • (c) move from a UHF to a VHF channel.
  • Repacking broadcast licenses
  • 2nd stage forward auction of 5 MHz blocks without advance knowledge of which blocks.
    • Separate up and down blocks clearing X downlink and Y uplink spectrum.
  • Whitespace use in Channel 37, in the guard bands, and in two channels used by wireless microphones
  • Expected Order in 2013 with auction in 2014.
incentive auctions1
Incentive Auctions
  • FCC released Incentive Auction NPRM from last Wednesday’s meeting:http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC-12-118A1.pdf
  • 1st stage reverse auction: for full-power and Class A TV licensees and allows participants to
    • (a) relinquish a 6 MHz license,
    • (b) channel-share, or
    • (c) move from a UHF to a VHF channel.
  • Repacking broadcast licenses
  • 2nd stage forward auction of 5 MHz blocks without advance knowledge of which blocks.
    • Separate up and down blocks clearing X downlink and Y uplink spectrum.
  • Whitespace use in Channel 37, in the guard bands, and in two channels used by wireless microphones
  • Expected Order in 2013 with auction in 2014.
incentive auctions2
Incentive Auctions
  • FCC released Incentive Auction NPRM from last Wednesday’s meeting:http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC-12-118A1.pdf
  • 1st stage reverse auction: for full-power and Class A TV licensees and allows participants to
    • (a) relinquish a 6 MHz license,
    • (b) channel-share, or
    • (c) move from a UHF to a VHF channel.
  • Repacking broadcast licenses
  • 2nd stage forward auction of 5 MHz blocks without advance knowledge of which blocks.
    • Separate up and down blocks clearing X downlink and Y uplink spectrum.
  • Whitespace use in Channel 37, in the guard bands, and in two channels used by wireless microphones
  • Expected Order in 2013 with auction in 2014.
