Roof Mounting Systems for Solar Panels

Discover the ideal mounting structures for solar panels to ensure seamless installation o n rooftops. Our high-quality solar panel mounting structures are designed for durability and optimum performance. Explore various types of mounting structures and secure the best prices in India. Additionally, we also offer installation services for panoramic sunroofs, enhancing your solar experience further. http://solargreennature.com/roof-mounted-solar-structure/

Solar15
Download Presentation

Roof Mounting Systems for Solar Panels

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Roof Mounting Systems for Solar Panels Discover the ideal roof mounting structures for solar panels to ensure seamless installation on rooftops. Our high-quality solar panel mounting structures are designed for durability and optimum performance. Explore various types of mounting structures and secure the best prices in India. Additionally, we also offer installation services for panoramic sunroofs, enhancing your solar experience further.

  2. (a) Railed Mounting Structure: In a railed mounting structure, solar panels are fixed on several rails through a set of clamps. The rails are made of aluminum and attach to your roof by using a drill and nut bolts. (b) Rail-less/Ballasted Mounting System: Rail less mounting structure is also known as ballasted mounting structure. In this structure, solar panels are directly fixed to the roof by using hardware. This is a cost-effective and easy way to install solar panels on roofs. (c) Shared Rail Mounting System: Shared rail mounting system is very similar to the railed system. In the railed mounting system, 4 rails are used to fix 2 rows of solar panels. While in the shared rail system, only 3 rails will be used to mount 2 rows. The middle rail will be shared by both rows.

  3. In a rooftop mounting system, solar PV panels are installed on the roof of the building. It can either be any residential building or any commercial/industrial building. • The rooftop mounting structure is further divided into two types which are- • Standard Rooftop Structure • Elevated Rooftop Structure

  4. Elevated Solar Panel Structure In elevated solar panel structures, solar panels are installed at a height of 10 to 15 ft. There will be a little room-type space beneath the mounting structure. It is also the most common type of mounting structure.

  5. Thank You For more details, visit:http://solargreennature.com/roof-mounted-solar-structure/
