A box and whisker plot is a graphical representation of variation in a set of data. In this probability and statistics video tutorial, you will learn all about Box and Whisker Plot. We will start with discussing the essential terms and definitions of the Box and Whisker plot and then move on to see How you can create a box and whisker plot by taking an example.<br><br><br>Learn More: https://www.simplilearn.com/big-data-and-analytics/senior-data-scientist-masters-program-training?

Simplilearn
Download Presentation

Box And Whisker Plots | How To Make Box And Whisker Plot |

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. What’s in it for you? What is Box and Whisker Plot? How to construct Box and Whisker Plot? Create a Box plot using Python

  2. What is Box and Whisker Plot? Box and Whisker Plot in statistics shows the distribution numerical data to analyze the variability and existence of outliers in a dataset

  3. Click here to watch the video

  4. What is Box and Whisker Plot? It is also called as Five number summary box, as it consists of the median, the quartiles (lower quartile and upper quartile), and the smallest and largest values in the distribution median Q3 Q1 max min whisker whisker

  5. How To Construct Box And Whisker Plot? Suppose, we have sample age of 10 students at a training centre • Arrange in ascending order 15, 18, 19, 19, 20, 24, 25, 25, 27, 28 1 15, 27, 19, 18, 24, 19, 20, 25, 25, 28 • Find the median • 15, 18, 19, 19, 20, 24, 25, 25, 27, 28 2 Median = Q2 = 22

  6. How To Construct Box And Whisker Plot? Find the medians of the two halves 15, 18, 19, 19, 20, 24, 25, 25, 27, 28 3 15, 18, 19, 19, 20 24, 25, 25, 27, 28 Lower Quartile/Q1 Upper Quartile/Q3

  7. How To Construct Box And Whisker Plot? 15, 18, 19, 19, 20, 24, 25, 25, 27, 28 Min Max Median Q1 Q3 The five-number summary is 15, 19, 22, 25, 28 4

  8. Graphical Representation of Box Plot • Scale and label an axis that fits the five-number summary 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 • Draw a whisker from Q1 to the min and from Q3 to the max age value

  9. Graphical Representation of Box Plot Below is the box plot that shows the distribution of age of students at the training centre 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 Max Min Q1 Q2 Q3 25% 25% whisker whisker
