## Formal Models for Distributed Negotiations A Calculus of Compensations

- - - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - - -

**XVII Escuela de Ciencias Informaticas (ECI 2003), Buenos**Aires, July 21-26 2003 Formal Models forDistributed NegotiationsA Calculus of Compensations Roberto Bruni Dipartimento di Informatica Università di Pisa**Compensations**• Long running transactions may abort also when some of their sub-transactions have been committed • Committed sub-transactions should be undone • Not always possible: visible events cannot be canceled • e.g. when booking holiday (flights, hotels, cars, shows), only partial refund can be obtained by canceling • e.g. when negotiating services and goods, some fines must be for canceling the contract • To Compensate = • to amends for, to make up for Formal Models for Distributed Negotiations**Objectives**• Clear understanding of long running transactions (LRT) and of their compositions • Formal models to clarify assumptions and obligations of the various components of a business system • Visual rendering of control structures • Algebra of LRTs • Design automatic analysis tools for checking coherence of business systems and guard against deadlocks and race conditions Formal Models for Distributed Negotiations**LRTs are not ACID**• LRTs • are composed out of a collection of traditional atomic transactions • for them, roll-back is supplied automatically • usually engage in externally visible events • these events cannot be undone automatically • user-defined (application-dependent) compensations are needed • approximately atomic and consistent, not isolated and globally durable, no automatic roll-back Formal Models for Distributed Negotiations**Inspiration**• From XLANG • context P exception E compensation C failure normal entry point compensation exit normal exit point compensation entry Formal Models for Distributed Negotiations**Sound Traces**• Normal flow is vertical, from top to bottom • Compensation flow is still vertical, but in the reversed direction (from bottom to top) • For the moment we regard internal failures just as compensations • Sound traces • OK: normal in (nin) – normal out (nout) • FAIL: nin – compensation out (cout) • COMP: nin – nout – cin - cout Formal Models for Distributed Negotiations**Tree of Traces**• Traces can be conveniently represented as a tree • Nodes are labeled by events • A trace is a path from the root of the tree • Sound transactions • tree of traces must be conform to nin nout cout cin cout Formal Models for Distributed Negotiations**Succeed and Fail**• Straight arrows have no effects nin nin nout cout cin cout Formal Models for Distributed Negotiations**nin & R.nin**R.nout & S.nin R.cout & cout S.nout & nout S.cout & R.cin cin & S.cin R.cout & cout S.cout & R.cin R.cout & cout Sequential Composition • sequence R S • Compound events • nin & R.nin • R.nout & S.nin • S.nout & nout • cin & S.cin • S.cout & R.cin • R.cout & cout • Simultaneous occurrence of joint events R;S R S Formal Models for Distributed Negotiations**Sequential Composition is Sound for R**nin & R.nin • sequence R S • Compound events • nin & R.nin • R.nout & S.nin • S.nout & nout • cin & S.cin • S.cout & R.cin • R.cout & cout • Simultaneous occurrence of joint events R;S R R.nout & S.nin R.cout & cout S.nout & nout S.cout & R.cin S cin & S.cin R.cout & cout S.cout & R.cin R.cout & cout Formal Models for Distributed Negotiations**Sequential Composition is Sound for S**nin & R.nin • sequence R S • Compound events • nin & R.nin • R.nout & S.nin • S.nout & nout • cin & S.cin • S.cout & R.cin • R.cout & cout • Simultaneous occurrence of joint events R;S R R.nout & S.nin R.cout & cout S.nout & nout S.cout & R.cin S cin & S.cin R.cout & cout S.cout & R.cin R.cout & cout Formal Models for Distributed Negotiations**Sequential Composition is Sound**nin & R.nin • sequence R S • Compound events • nin & R.nin • R.nout & S.nin • S.nout & nout • cin & S.cin • S.cout & R.cin • R.cout & cout • Simultaneous occurrence of joint events R;S R R.nout & S.nin R.cout & cout S.nout & nout S.cout & R.cin S cin & S.cin R.cout & cout S.cout & R.cin R.cout & cout Formal Models for Distributed Negotiations**Notes About Sequence**• Dynamic behaviour uniquely defined by the flowchart • Only tree that satisfies all three conditions of soundness • Sequential composition is associative • We can • omit outer boxes in nested serializations • omit parentheses in algebraic expressions • investigate properties by considering two operands at a time Formal Models for Distributed Negotiations**Sequential Choice (Pick)**• In sequential composition, a failure of a single component triggers the compensations of all previous activities • The pick operation allows to specify two or more alternatives for the same goal • tried sequentially • until one succeeds • or all have failed Formal Models for Distributed Negotiations**nin & R.nin**R.nout & nout R.cout & S.nin cin & R.cin S.nout & nout S.cout & cout R.cout & cout cin & S.cin S.cout & cout Sequential Choice (Pick) • pick R S • (associative) S R The tree is more informative than the flowchart Formal Models for Distributed Negotiations**Parallel Composition (All)**• Two or more transactions can be executed concurrently • The all operation allows to specify two or more concurrent activities • initiated together • fail if any of them fail • completed when all succeed • roll-back all on subsequent failures Formal Models for Distributed Negotiations**The tree is trivial**nin & R.nin & S.nin R.cout & S.cout & cout R.nout & S.nout & nout The implementation is difficult! What if, after R.nin and S.nin, it happens that R.nout but S.cout? Deadlock? (dealt with exceptions) cin & R.cin & S.cin R.cout & S.cout & cout Parallel Composition (All) • all R S • Petri net–like flowchart • (assoc., comm.) S R Formal Models for Distributed Negotiations**Concurrent Waiting (Parallel Pick)**• Speculation • local extra work in anticipation it may need later • Two or more transactions can be attempted concurrently • take the one that succeeds first • compensate all the others • alternatives must be independent each other and with no interaction Formal Models for Distributed Negotiations**Concurrent Waiting (Parallel Pick)**nin & R.nin & S.nin non-determinism R.nout & S.nout R.nout & S.cout & nout R.cout & S.nout & nout R.cout & S.cout & cout S.cin R.cin S.cout & nout R.cout & nout cin & R.cin cin & S.cin cin & R.cin cin & S.cin R.cout & cout S.cout & cout R.cout & cout S.cout & cout Formal Models for Distributed Negotiations**The Pi-Calculus Approach**• The pi-calculus is the most famous calculus for (name) mobility • Similar to join • many receivers on the same channel • hiding (x) and binding input prefix x(y).P instead of def xyPin … • Similar to CCS (with value passing) • outputs carry values xy • inputs have (bound) arguments x(y) Formal Models for Distributed Negotiations**Compensation Primitives**• Asynchronous pi-calculus • P ::= 0 | xy | x(y).P | (x)P | !P | P|P • Additional primitives • done – successful termination of transaction • abort – internal failure • context(P,Q,R) – Process P with exception handler Q and compensation R • Some structural laws • P | done = P • abort | abort = abort • context(xy|P, Q, R) = xy | context(P, Q, R) Formal Models for Distributed Negotiations**Handling Failures**• Compensations are remembered after commit by attaching them to on-failure processes of outer contexts • context(P|context(done,Q’,R’), Q, R) context(P, R’|Q, R) • context(abort, Q, R) Q • This allows for • Establishing abstract equivalences • e.g. if P is abort-free, then P is equivalent to any context(P,Q,R) • Formal encoding and comparison with other calculi • extended processes can be “compiled” in the pi-calculus Formal Models for Distributed Negotiations**Extending Compensations**• Standard approach • Compensations associated with primary activities of LRTs • When required, all compensations of successful activities are executed (in reversal order) • If savepoints are reached (committed choices), then compensations are no longer required and can be forgotten • StAC (Structured Activity Compensation) • In the spirit of Sagas • More general mechanisms (concurrent and non-atomic activities) • Multiple compensations (selective / alternative) Formal Models for Distributed Negotiations**Business Process Beans**• Business Processes • model activities that are useful to the business • must be composable • hierarchy of abstractions • IBM’s BPBeans Application • hierarchy of nested components • bottom level: primitive Java beans components • activities act on a global set of shared variables • composed via the Application Builder for Components (ABC) tool Formal Models for Distributed Negotiations**StAC Syntax**• P ; P (sequential composition) • P | P (parallel composition) • par i in S do i.P (generalized parallel comp.) • if C then P else P (conditional) • (early termination) • {P} (termination scoping) • P P (compensation pair) • [P] (compensation scoping) • (accept) • (reverse) Formal Models for Distributed Negotiations**Sequential and Concurrent Activities**• P ; Q • P is executed first. When P completes, Q is executed • associative • P | Q • associative • par i in S do i.P • used for generating many concurrent instances uniquely indexed by i • e.g. par i in 1..10 do i.P • creates 10 distinct concurrent instances of P Formal Models for Distributed Negotiations**Early Termination**• • termination is limited by scoping brackets • e.g. {P;;Q} ; R • first executes P, then terminator prevents Q from being executed, but being termination limited within brackets, then R will be executed • also concurrent activities are terminated • maybe not immediately, but at a later stage • either prematurely or at completion • e.g. {(P;;Q) | S} | R • the termination causes S to terminate (not R, which is outside the scoping) • Termination scoping can be nested Formal Models for Distributed Negotiations**Compensations I**• P Q • P is the primary task • Q is the compensation task for P • First the primary task is executed, when completed, the compensation task is remembered for later use (in reversal) • • executes available compensations • e.g. (P Q) ; • executes P and remembers Q, then reverse by executing Q • e.g. (P1 Q1); (P2 Q2);(P3 Q3); • executes P1 then P2 then P3 then Q3 then Q2 and finally Q1 Formal Models for Distributed Negotiations**Compensations II**• e.g. ((P1 Q1)|(P2 Q2)|(P3 Q3)) ; • executes P1, P2 and P3 concurrently, and then compensates with Q1, Q2 and Q3 concurrently • Invoked compensations are then cleared • e.g. (P Q) ; ; is the same as (P Q) ; • • forgets all currently remembered compensations (committed choice) • e.g. (P1 Q1) ; ; (P2 Q2) ; • executes P1 then P2and finally Q2 (Q1 is not performed because it has been removed by the accept operation) Formal Models for Distributed Negotiations**Compensations III**• Compensations can be nested • e.g. (P (P1 Q1) ) ; • executes P and remembers (P1 Q1), then on reversal executes P1 but remembers Q1 for later use • Square brackets delimit the scope of the accept and reverse operators • Restrictions in BPBeans • nested compensations are not allowed • each level in the hierarchy overrides lower levels (as if P was modeled by [P;]) • concurrent activities have separated compensation scopes (as if P|Q was modeled by [P]|[Q]) Formal Models for Distributed Negotiations**Multiple Compensations**• Aim: to allow processes to remember several simultaneous compensation tasks • Individual tasks can then be accepted or reversed • Facilitate reuse of processes • Language extension • P i P (indexed compensation pair) • i (indexed accept) • i (indexed reverse) Formal Models for Distributed Negotiations**Selective and Alternative Compensations**• Selective compensations • reversals select some activities to be compensated for, while preserving the compensations for other activities • Alternative compensations • several alternative compensations are attached to the same activity and the reversal picks one of these alternatives for invocation and forget the others Formal Models for Distributed Negotiations**StAC vs Other Models**• Sagas • non hierarchical and purely sequential • compensations invoked on system failure • assumption of perfect compensation • Nested transactions • compensations invoked on system failure • rigid scoping • multiple compensations are not allowed • ConTracts • single compensations • implicit accept and reversal Formal Models for Distributed Negotiations**Recap**• We have seen • Different approaches to the formal modeling of compensations • Difficulties • Advantages • Mismatching • Basis for implementations Formal Models for Distributed Negotiations**References**• Notes by T. Hoare, C. Fournet, A. Gordon, L. Bocchi, C. Laneve, G. Zavattaro • Extending the concept of transaction compensation (IBM System Journal 41(4), 2002, pp. 743-758) • M. Chessell, C. Griffin, D. Vines, M. Butler, C. Ferreira, P. Henderson Formal Models for Distributed Negotiations
