    3: Initial settings (cont) Initial settings were covered in the COM Quick Start presentation. Assumption here is that the Comm Quick Start has been viewed and understood.

    4: Initial settings (cont)

    5: Initial settings (cont) The SL30 NAV/COM is selected as No.2 Only the NAV side will be discussed here.

    6: Initial NAV settings (cont) To get customary OBS/CDI indications the GPS/NAV switch on the selector panel must be in the NAV position.

    7: Initial NAV settings (cont) Note that the NAV/GPS function is annunciated both on the selector panel and in the face of the CDI/OBS unit.

    8: Initial NAV settings (cont)

    9: Initial NAV settings (cont) Press the NAV button Set the desired frequency (will be displayed as ‘Standby Frequency’) Large right knob is 1 Mhz per step Small right knob is 25 Khz per step Press the <-> key to transfer the frequency to the active window.

    10: Initial NAV settings (cont) To monitor the channel lift the NAV2 toggle switch on the audio panel (Note: this toggle switch selects another radio in the down position) Set SL30 volume control for comfortable level. Identification

    11: Initial NAV settings (cont) This will provide normal VOR/LOC operations. CAUTION Since both NAV 1 and NAV 2 are duplex units, assure the desired mode is being displayed when changing data.

    12: Initial NAV settings (cont) All are encouraged to download the full manuals to become familiar with the options available. (http://www.garminat.com/down_home.shtml) FLY SAFE and enjoy.
