real time tracking of multiple people using stereo

Real-time Tracking of MultiplePeople Using Stereo

David Beymer Bob Bolles

Kurt Konolige Chris Eveland

Artificial Intelligence Center

SRI International

problem people tracking for surveillance
Problem: people tracking for surveillance
  • return coarse 3D locations of people
  • real-time on standard hardware
  • multiple people in scene
  • stationary camera
approach
Approach
  • consider: template-based tracking
    • maintain template of object
    • correlation used to update object position
    • template is recursively updated to handle changing object appearance
  • limitations/problems

1) object initialization/detection

2) template drift

goal add modality of stereo
Goal: add modality of stereo
  • segmentation: background subtraction on stereo disparities to detect foreground
  • detection: person templates encoding head and torso shape
  • tracking:
    • person templates used to avoid drift
    • stereo segmentation used to add “support” template

left

background

disparities

foreground

approach5
Approach
  • detection
    • segment foreground into depth layers
    • correlate with person templates
  • tracking
    • intensity and "support" templates are recursively updated
    • Kalman filtering on person location in 3D
    • person templates used to avoid drift
related work
Related Work
  • Companies
    • Teleos Research/Autodesk, People Tracker
    • DEC/Compac, Smart Kiosk [Rehg, et al, 1997]
    • Interval, Morphin' Mirror [Darrell, et al, 1998]
    • Sarnoff [IUW, 1998]
    • Texas Instruments [Flinchbaugh, 1998]
    • Electric Planet
  • Universities
    • MIT, Pfinder [Wren, et al, 1997]
    • Toronto, [Fieguth and Terzopoulos, 1997
    • Maryland, W S [Haritaoglu, et al., 1998]
    • MIT, Forest of Sensors [Grimson, et al., 1998]
    • CMU [Kanade, et al, 1998]
    • Columbia/Lehigh [Nayar and Boult, 1998]
    • Boston Univ., [Rosales and Sclaroff, 1998]

4

stereo module sri s small vision system svs
Hardware

two CMOS cameras

low power (150mW), inexpensive ($100 components)

adjustable baseline: 2.7'' to 6.2'' in 1'' increments

another version with DSP processing onboard

Software

stereo algorithm is area correlation based

optimized C and MMX code

20 Hz on 320x240 image, 24 disparities, 400 MHz Pentium II

Stereo module: SRI's Small Vision System (SVS)
svs stereo results
SVS Stereo Results

left

right

notation:

current disparities

background estimate

disparities

background subtraction
Background subtraction
  • look for disparities closer than background
  • using stereo disparities versus intensities
  • less sensitive to lighting changes, shadows
  • can segment people at different depths

more computationally expensive

tends to blur & expand object boundaries

handling scale
Handling scale
  • idea: range info from stereo can be used to fix scale of processing avoid search over scale parameter
    • person width is proportional to disparity
    • from similar triangles:
    • stereo equation:

d: disparity

b: baseline

K: constant

detection example
Detection example
  • during detection, extract intensity and “support” template from layer(x,y)
tracking coordinate space
Tracking -- coordinate space

image 3D

(x, disparity)(X, Z)

tracking steps
Tracking Steps
  • prediction
    • predict Kalman filter (X, Z)
    • predict person disparity
  • segmentation
    • select foreground layer around predicted disparity
  • localization
    • correlate gray level template against left image, weighted by support template [coarse localization]
    • correlate head/torso shape template against segmented foreground layer [re-centering step that addresses template drift]
  • update
    • Kalman filter
    • recursive update of intensity and support templates
tracking videos
Tracking Videos
  • recursive template update

walking figure eight

running

Please click on image to start video. Once finished viewing the video, use the “back” button on your browser to return.

tracking videos16
Tracking Videos

visualizing tracks from map view

tracking under multiple occlusions

Please click on image to start video. Once finished viewing the video, use the “back” button on your browser to return.

evaluating use of stereo in tracker
Evaluating use of stereo in tracker
  • Experiment: disable stereo in tracker
    • code modifications:
      • disable re-centering step
      • weighted intensity correlation unweighted correlation
    • results:
      • mean tracking rate (TR) drops 4%
      • mean false positive rate (FP) increases from 3% to 10%
      • (qualitative) template drift causes people to be lost and re-detected
conclusion
Conclusion
  • Stereo is an effective segmentation tool:
    • detection: provides a foreground layer divided into different depth layers
    • tracking: helps to avoid template drift by focusing on foreground pixels at object’s depth
  • Combine segmentation with priors on person shape (i.e. head/torso templates) for person localization.
