adms compact model synthesis part i introduction and development outlook
ADMS: Compact Model SynthesisPART I: Introduction and development outlook

Laurent Lemaitre Freescale - Geneva

Ben Gu Freescale - Austin

1

outline of presentation
Outline of Presentation
  • Device Models in CAD tools
  • Device Model Implementation – hand-crafted
  • ADMS: software tool - translates Verilog-AMS to C
  • Overview of the Device Model Generator
  • Example of Model Generation
  • Ngspice Interface
  • Work on progress
  • Conclusion
device models in cad tool
Device Models in CAD tool

Spice netlists

+

Process libraries

(model parameters)

Electrical Circuit Simulator

DESIGNER

Simulation

Results

Spectre, ADS, Mica, ..

done manually or use model compiler (ADMS)

Built-in Device Model EquationsVBIC, EKV, SP, MOSCAP, R3, ..

model implementation hand crafted
Model ImplementationHand-crafted
  • Device Model Engineer:
  • provides equations of new model
  • to programmer. No standard.
  • Programmer:
  • hand-codes the model in source code of the electrical circuit simulator (most of the time the language is C). No standard.
  • C code must comply with the Simulator Programming Interface. Much coding needs to be done again for each simulator.
  • C code involves the manual computation and coding of partial derivatives. This process is tedious and error-prone.
  • C code is hard to read. Feedback to the Device Model Engineer is made difficult.
  • The process is a barrier to model maintenance and enhancement.
adms approach
ADMS Approach
  • ADMS translates Verilog-AMS to ready-to-compile C code for simulator API (application programming interface)
  • ADMS uses Verilog-AMS as input.
  • Advantages of Verilog-AMS:
    • Verilog-AMS code easy to read - no extra code specific to simulators.
    • Model can be easily and completely tested prior implementation !
  • ADMS uses XML (successor of HTML ) as internal language to build the translators from Verilog-AMS to Simulator API:
    • Simplifies development of new features of ADMS and support of multiple simulators
adms translator
ADMS Translator

STANDARD 1: AT MODEL LEVEL

DTD basedvalidation

Verilog-AMS

Model Code

Parsing

STANDARD 2:

AT SIMULATOR

LEVEL

Internal

XML program

data

Other

Code Generator

applications

Testing

prior implementation

C code

Mica, Spectre,

ADS, …

Documentation

Circuit Test benches

example verilog ams i
Example – Verilog-AMS I

`define NPN +1

`define PNP –1

module BIP (c,b,e);

// Nodes

input c,b; // input nodes

output e;// output nodes

electrical c,b,e; // all electrical

// Branches

branch (b,c) bc;

branch (c,e) ce;

branch (e,c) ec;

branch (b,e) be;

example verilog ams ii
Example – Verilog-AMS II

// Parameters

parameter real is = 1.0e-16;

parameter real bf = 100;

parameter real br = 1;

parameter real nf = 1.0;

parameter real nr = 1.0;

parameter integer type = `NPN;

// Variables

real Tdev, Vtv;

real Ifi, Ibf;

real Iri, Ibr;

real argf,expf;

example verilog ams iii
Example – Verilog-AMS III

analog begin // Analog section

Tdev = $temperature;

Vtv = 1.380662e-23 * Tdev / 1.602189e-19;

if ( type == `NPN ) begin

argf = V(be) / ( nf * Vtv );

end else if ( type == `PNP ) begin

...

expf = exp(argf);

Ifi = is *(expf-1.0);

Ibf = Ifi/bf;

begin

I(ce) <+ Ifi; // FORWARD Transport C-E

I(be) <+ Ibf; // FORWARD Diode B-E

end

example code for spectre
Example – Code for Spectre

SPECTREinterface.h

BIPdefs.h

BIPinitParameter.c

BIPloadJacobian.c

BIPevaluateStatic.c

BIPevaluateDynamic.c

BIPOLAR

TRANSISTOR

in

VERILOG-AMS

Run admsSpectre

Ready-to-compile

C code

example test bench circuit
Example – Test-bench Circuit
  • Automatically Generated by ADMS

Cint

1 kOhm

Bint

1 V

1 kOhm

Eint

1 V

1 Ohm

ngspice support
NGSPICE support
  • Motivation: standardization effort
  • Link to home page: http://ngspice.sourceforge.net/adms.html
  • How to: http://ngspice.sourceforge.net/admshowto.html#
  • ADMS distribution in ngspice:
    • ADMS is distributed separately from ngspice. You can download the ADMS compiler from it's web site. Once you have downloaded and installed the compiler, you can add Verilog-AMS model to ngspice.
    • The process of adding a new device is far from being automatic and need a certain knowledge of spice internals. The file README.adms distributed with ngspice describes the process.
  • Plan: update the XML interface by Q4-2006: integrate the latest versions of psp, hicum and mextram.
work in progress
Work in Progress
  • ADMS is written in the C language
  • Current release 2.2.4
  • Next release 2.2.5 planned by end of October
    • documentation
    • stronger XML parsers
    • faster (5X)
  • ADMS is open-source: mot-adms.sourceforge.net
  • Port to freeBSD (July 2006)
work in progress15
Work in Progress
  • Working with Agilent to provide a free MINT interface:
    • end 2006
  • Cadence provides support through CMI
  • Helene Parruit (ENSIB) writes the QUCS XML interface
  • Mentor Graphics is currently its XML interface for ADMS
  • The PSP family used ADMS to release its simkit version
  • Simucad who uses ADMS to implement some of its models.
conclusion
Conclusion
  • ADMS = automatic implementation of compact models into circuit simulators
  • ADMS automatically generates efficient, robust, correct-by-construction code
      • (bsim3 same speed as hand-crafted reported in 2 cases)
  • ADMS has been successfully used for the integration of new device models into Mica, Spectre, HSIM and ADS
  • Compact models are defined by Verilog-AMS, a standard high-level language
