outline
Outline
  • Importance of teaching power electronics in a power systems course
  • Description of proposed approach consisting of four segments
    • Functional aspects of power electronics
    • Power device capabilities and Power Electronic Structures
    • Role of power electronics in utility applications
    • Details of the power electronics structures
importance
Importance
  • Increasing applications of Power Electronic Equipment in Power Systems
    • Availability of high power semiconductor devices
    • Decentralized renewable energy generation sources
    • Increased power transfer with existing transmissionsystem
    • Effective control of power flow needed in a deregulated environment
    • Norms for Power quality

Future Power System

approach
Approach
  • Top Down approach consisting of four segments
    • Function of power electronics as an interface, and the listing of utility applications requiring power electronics interface (1 lecture)
    • Power device capabilities and the resulting structures of power electronic interfaces to exploit them (1 lecture)
    • Importance and the role of power electronic interfaces in various applications (2 lectures)
    • Discussion of power electronics interface in appropriate detail (3 lectures)
segment 1 function of power electronics in utility applications
Segment 1: Function of Power Electronics in Utility Applications
  • Enabling technology providing interface between two (ac/dc) electrical systems
  • E.g.
    • Interconnection of two asynchronous ac systems
    • dc to ac conversion is required to connect fuel cells or photovoltaics to the utility grid
segment 1 listing of power electronic applications
Segment 1: Listing of Power Electronic Applications
  • Distributed generation (DG)
    • Renewable resources (wind and photovoltaic)
    • Fuel cells and micro-turbines
    • Storage: batteries, super-conducting magnetic energy storage, flywheels
  • Power electronics loads: Adjustable speed drives
  • Power quality solutions
    • Dual feeders
    • Uninterruptible power supplies
    • Dynamic voltage restorers
  • Transmission and distribution (T&D)
    • High voltage dc (HVDC) and medium voltage dc
    • Flexible AC Transmission Systems (FACTS): Shunt and Series compensation, and the unified power flow controller
segment 2 power device capabilities resulting power electronic structures
Segment 2: Power Device Capabilities & Resulting Power Electronic Structures
  • Power Semiconductor Devices and their Capabilities
    • Polarity of voltage blocked and direction of current conduction
    • Switching speeds and power ratings
segment 2 structure of power electronic systems
Segment 2: Structure of Power Electronic Systems
  • Voltage-Link Systems
    • Transistors and diodes that can block voltage of only one polarity
  • Current-Link Systems
    • higher power bipolar voltage-blocking capabilities of thyristors
  • Solid State Switches
    • bidirectional voltage blockingand current conduction
segment 3 role of power electronics in important utility applications
Segment 3: Role of Power Electronics in Important Utility Applications
  • Distributed Generation (DG) ApplicationsPower electronic interface depends on the source characteristics

Wind Power Generation with Doubly Fed Induction Motors

Photo-voltaics Interface

(c)

segment 3 role of power electronics in important utility applications10
Segment 3: Role of Power Electronics in Important Utility Applications
  • Power Electronic Loads: Adjustable Speed Drives

(c)

segment 3 role of power electronics in important utility applications11

Dynamic Voltage Restorers (DVR)

Dual Feeders

Uninterruptible Power Supplies

Segment 3: Role of Power Electronics in Important Utility Applications
  • Power Quality Solutions for
    • voltage distortion
    • unbalances
    • voltage sags and swells
    • power outages

(c)

segment 3 role of power electronics in important utility applications12

HVDC

MVDC

Segment 3: Role of Power Electronics in Important Utility Applications
  • Transmission and Distribution: DC Transmission
    • most flexible solution for connection of two ac systems
segment 3 role of power electronics in important utility applications13

Series Compensation

Shunt Compensation

Shunt and Series Compensation

Segment 3: Role of Power Electronics in Important Utility Applications
  • Transmission and Distribution: Flexible AC Transmission Systems (FACTS)
segment 4 discussion of power electronics interface
Segment 4: Discussion of Power Electronics Interface
  • Fundamental concepts for understanding the operation of the power electronic structures
    • voltage-link systems
    • current link systems
    • solid state switches
voltage link systems

Voltage

port

Current

port

Voltage-Link Systems
  • Unifying approach: Power-Pole Building Block
    • building block of all voltage-link systems
voltage link systems16

Voltage

port

Current

port

Voltage-Link Systems
  • Power conversion using Pulse Width Modulation (PWM)
    • Power reversal with reversal of current direction
    • Averaged conversion
voltage link systems17

Voltage

port

Current

port

Voltage-Link Systems
  • Averaged Representation of Power Pole
    • Average quantities are of main interest
voltage link systems18
Voltage-Link Systems
  • Synthesis of AC voltages
    • voltage to be synthesized
    • duty ratio needed
    • dc side current
voltage link systems19
Voltage-Link Systems
  • Implementation of bi-positional switch

(d)

current link systems
Current-Link Systems
  • Exclusively thyristor based
    • One of (T1, T2, T3) and (T2, T4, T6)conduct at a time
    • Average dc voltage controlled by ‘firing angle’
    • Power flow reversed by reversing voltage polarity

(d)

solid state switch
Solid State Switch
  • Can conduct current in both directions
  • Turn-on or off in an ac circuit in one-half of a line-frequency cycle

(d)

conclusion
Conclusion
  • Teaching utility applications of power electronics in a power systems course is very important
  • A top down approach, starting with functional aspects and going to implementation details is suggested
  • Topics outlined in the four segment proposed structure will introduce students to future practices and technologies in power engineering
  • The proposed structure may be adapted based on individual preferences
