electronic chain

HV

1:1

1:1

Active

Splitter

Active

Splitter

1:1

1:1

Trigger

216

4:1

4:1

Trigger

front

PMT

atten

Trigger

LXe

612

lateral

PMT

3 crates

HV

DRS

DRS

1:1

Active

Splitter

60

120

DRS

bars

PMT

Ramp

1:1

DRS

4:1

TC

DRS

HV

DRS

8:1

APD

Pre-Amp

fibers

640

6 crates

HV

Hit

registers

32

Wires

Pre-Amp

576

DC

1156

4 boards

Strips

Pre-Amp

Aux. devices

Electronic chain
daq and control

pE5 area

‘counting room’

Trigger

Trigger

Trigger

Trigger

clock

start

stop

sync

Front-End PCs

Main DAQ PC

PC (Linux)

PC (Linux)

PC (Linux)

PC (Linux)

Run start

Run stop

Trigger config

PC (Linux)

DRS

PC (Linux)

DRS

Busy

Error

PC (Linux)

DRS

DRS

PC (Linux)

DRS

PC (Linux)

DRS

20 MHz

clock

PC (Linux)

Hit

registers

Event

builder

PC (Linux)

PC (Linux)

Gigabit

Ethernet

Trigger signal

Event number

Trigger type

PC (Linux)

PC (Linux)

On-line farm

storage

DAQ and control

Ancillary

system

3 crates

6 crates

hv system
HV System

4 different requirements:

  • Lxe: 1000V , 100 uA
  • TC bars: 2400V, 1 mA
  • TC curved: 500V, <1 uA
  • DC: 2400V, ~1 uA
  • System works from 10V – 2400V, 1.5mA, 1uAresolution, special version for 1nA resolution
  • Current-trip feature implemented and tested, the HV-off time determined by de-charging capacitance
  • HV will “end” at backplane
  • ‘Users’ have to decide about connectors
  • 4-channel system in 3HE crate

(40 channels are currently in use at PSI)

  • 10-channel system in 6HE crate

400 channels in preparation, ready by September

http://www.fischerconnectors.com/

1-15 kV

hv crate
HV crate
  • 10 chn per board
  • 180 chn per 3 HE crate
  • Back side connector

HV passes through backplane

splitter project requirements

input

DRS output

test

Trigger or

Spare output

DRS or trigger

summed output

Splitter – project requirements
  • Inputs:
    • 828 Lxe + 120 TC channels
    • Single ended (Rin=50Ω)
    • Dual row headers connectors
  • Test:
    • High-precision and constant amplitude levels
  • Outputs:
    • DRS:
      • Full bandwidth
      • Gain ~ 1
    • Trigger:
      • 100 MHz bandwidth
      • Gain ~ 1
    • Analog Adder:
      • 4-channels sum
      • 100 MHz bandwidth
      • Gain ~ 1
    • Differential (Rout=120Ω)
    • Standard profile boxed header connectors (3M
  • Dynamic range:
    • Limited into 0V - 2.5V
  • Card size and density:
    • Standard double Eurocard (6U)
    • 16 channels per card
components selected
Components selected
  • THS4509 – 1.9GHz, 6600 V/μs Low Distortion fully Differential Amplifier
    • DRS outputs driver;
  • AD8137 – Low Distortion Differential ADC Driver
    • Trigger and sum output driver.
prototype
Prototype
  • In the first half of 2005 the technical requirements for splitter were defined
  • The final prototype design started immediately
  • The 2-channels prototype was completed in March 2005 and tested
crosstalk test
Crosstalk test
  • Input pulse:
    • 1.6V amplitude (Vout+=+0.8V, Vout-=-0.8V)
    • <1 ns risetime
  • Input crosstalk (Metallic enclosure)
    • Crosstalk Ch1→Ch4: <0.1%;
    • Crosstalk Ch2→Ch4: ~0.5%;
    • Crosstalk Ch3→Ch4: ~1.5%;
  • Inside the board + output connector crosstalks (input connector contribution excluded)
    • Crosstalk Ch3→Ch4: ~1.5%
  • Inside the board crosstalk
    • Crosstalk Ch3→Ch4: ~0.5%;
final splitter board
Final splitter board

Full BW

Output

(34-pins)

Input

(64-pins)

Sum output

(16-pins)

Reduced BW

Output

(34-pins)

Power

and test

test circuit
Test circuit
  • The calibration of the DRS channels needs constant levels voltage on all inputs
  • A step voltage generator, with 4 voltage levels, was developed
  • Levels are defined with high precision low noise reference IC (LM4140) with

0.1% accuracy and

low temperature coefficient (3ppm/°C)

  • This circuit will be implemented on the backplane and it will feed all the splitter cards contained in the crate.
production
Production
  • October 05 – test of the final prototype
  • December 05 – end of full production
  • October 05 – order of the cables
  • March 05 – installation
pmt ramp generator
PMT ramp generator

B

to Splitter

Analog signals

to DRS and trigger

PMT

B

S

TC Analog Sign. Monitor

Passive

Splitter

RAMP

GEN.

D/D

6U Eurocards boards

8 boards

to Splitters

Signals to DRS

Dual Threshold

Discriminator

NIM Signal

for any possible use

apd pre amplifier

Kapton Flex.

APD

Black Coating

Electronics boards -10 channels

Scint. Fibers

Transition board

Copper Cold Finger(~20°)

Peltier Cell

Heat Exchanger

  • Input: 10 APD
  • Ouput:
    • 10 shaped and discriminated channels for the hit register
    • 1 analog sum for the trigger
  • ENC: 1500 e rms
  • Risetime:5 ns
  • Pulse-length: 50 ns
APD pre-amplifier
hit encoder register
Hit encoder/register

6U VME boards

5 boards

152

Curved TC right side

Curved TC left side

152

A*B

Mask Right

Mask Left

152

Clock

control signal

Encoder

Control

Logic

Trigger

and

monitor

VME bus

Register

FPGA

production19
Production

PMT ramp generator

  • October 05 – design of the final board
  • January 06 – system delivery (8 boards - 6U Eurocards)

APD pre amplifiers

  • September 05 – design of the final APD pre-amplifiers
  • October 05 – test of the final prototype
  • December 05 – system delivery (80 cards)

APD hit registers

  • December 05 – board design
  • April 06 – system delivery (6 boards – 6U VME)
dc electronics

right

left

up +

up -

down +

down -

At interface He bag – outside Cobra

DC electronics

inverting

anode

OR

small R

Preamplifier

16 x (2 x 9) x 6 = 1728 channels

16 ch.

cable

to DRS

cathode

OR

Large R

Non inverting

production22
Production

DC electronics

  • September 05 – design of the final pre-amplifiers
  • November 05 – test of the final prototype
  • January 06 – system delivery
trigger system structure

14 boards

. . .

Type2

Type2

Type2

Type2

Type2

14x 48

Type1

Type1

Type1

Type1

Type1

Type1

Type1

Type1

Type1

Type1

Type1

4

4

4

4

16

16

16

16

16

9 boards

. . .

9x 48

Trigger system structure

2 boards

2 VME 6U

1 VME 9U

Located on the platform

LXe inner face

(216 PMTs)

2 x 48

9+2 boards

. . .

1 board

LXe lateral faces

back (216 PMTs) 4 in 1

lat. (144x2 PMTs) 4 in 1

up/down (54x2 PMTs) 4 in 1

9 x 48

2 x 48

1 board

2 x 48

Timing counters

curved (640 APDs) 8 in 1

u/d stream (30x2 PMTs)

1 board

2 boards

Drift chambers

16+16 channels

2x 48

type1 present status
Type1 Present Status

CPLD : Coolrunner II (XC2C284-10-FG324) 

  • Type1 : CPLD design completed and simulated

FPGA : VIRTEX II- PRO (XC2VP20-7-FF1152)

  • Type1-1: LXe front face (Frequency 116 MHz)
  • Type1-2 LXe lateral faces in progress~
  • Type1-3 TCx
  • Type1-4 DC x

PCB :

    • import FPGA
    • Board Schematics
    • Footprints and routing 
    • Gerber files 
    • PCB production in progress
    • Board mountingx
type2 present status
Type2 Present Status

CPLD : Coolrunner II (XC2C284-10-FG324) 

  • Type1 : CPLD design completed and simulated

FPGA : VIRTEX II- PRO (XC2VP40-7-FF1152)

  • Type2-0 Final Level completed  
  • Type2-1 LXe inner faces x
  • Type2-2 LXe lateral faces x
  • Type2-3 TCx

PCB :

    • import FPGA
    • Board Schematics 
    • Footprints and routing 
    • Gerber files 
    • PCB production in progress
    • Board mountingx
ancillary boards
Ancillaryboards

Type2

Type2

Type2

Type1

Type1

Type1

Type1

Type1

Type1

5

5

5

5

2

5

2

5

Event counter

Trigger pattern

to DRS

Busy

from DAQ

START

STOP

START

STOP

SYNC

RES

CLK

ANCILLARY Mother

. . .

CLK

20 MHz

SYNC

RES

VME

ANCILLARY Daughters

60 x CLK

to DRS

ancillary present status
Ancillary Present Status

CPLD : Coolrunner II (XC2C284-10-FG324) 

  • Type1 : CPLD design completed and simulated

Components : MAX9153 – 3D3418

PCB :

    • import FPGA
    • Board Schematics 
    • Footprints and routing in progress
    • Gerber files x
    • PCB production x
    • Board mountingx
trigger components
Trigger components

All components already delivered, including LVDS interconnect cables

trigger test
Trigger test
  • The test of the final boards can be done in September, as foreseen in the schedule
  • The test will be done by using Struck interfaces. The present read-out speed of all trigger WFS for the full system is around 15 Hz.
  • This rate is more than adequate for the trigger system needs: calibration, efficiency measurements and stability
  • We are investigating the possibility of increasing the readout speed.
trigger schedule
Trigger schedule

2002

2003

2004

2005

Prototype Board

Final Prototype

Full System

partial

installation

Prototype Board

Final Prototype

Full system

1st lot of components ordered

full

install.

2nd lot of components

Design

Manufactoring

Assembly

Test

Milestone

drs2 plastic plcc
674 additional chips produced

150 chips for MAGIC

4200 channels for DC/TC/LXe

DRS2 plastic PLCC
improved sampling range
Improved Sampling Range

Domino wave can be operated below 500 MHz if started with a longer starting pulse.

Minimum is ~5 MHz.

Modified start pulse makes operation at 500 MHz stable.

cause of spikes
Cause of spikes

At 33 MHz, spike is always sampled, independent of FADC phase

At 16.5 MHz, FADC phase can be adjusted to skip spike

fixing spikes
Fixing spikes

before

Spikes were fixed by reducing readout speed from 33 MHz to 16.5 MHz.

Longer dead time will be compensated by having two FADCs in new mezzanine board

after

double peaks
Double Peaks

Double peaks in signals were caused by crosstalk from domino tap signal used for domino frequency measurement

Domino Tap signal

crosstalk

Fix: different routing, multilayer, ground shield

Clock signal

timing stability
Timing Stability

Frequency Stabilization

Trigger Signal Sampling

domino wave

FADC

8 inputs

Freq.

Cntr

FPGA

16-bit

DAC

shift register

Implemented in FPGA (VHDL)

→ 400 ps stability

Low-jitter

clock

MUX

recovery of timing
Recovery of Timing

4) Timing of all PMT pulses is expressed relative to t=0 point

1) Trigger publishes phase f of trigger signal f relative to clock in multiples of 10 ns

f

50 ns

2) Each DAQ card determines and fits “Time-Zero-Edge” in clock signal and uses this as t=0

3) Measure pulse width of clock to derive domino speed

Domino speed stability of 10-3 : 400ps uncertainty for full window

25ps uncertainty for timing relative to edge

domino wave jitter
Domino wave jitter

30 ns

  • 33 MHz calibration clock
  • Peak fit with reference pulse
  • Average over all pulses for many events
  • Jitter is 115 ps
  • Maximum distance of any signal to next clock peak is 15 ns → accuracy should be ~60 ps
calibration
Calibration
  • Measure Vin – Vout characteristics with precise DC power supply at the DRS2 input for all bins
  • Fit characteristics and use it for calibration
  • One curve needed per bin, under improvement
  • Is now done offline, will later be done online (front-end or FPGA)

mV

ADC counts / 10

effect of calibration
Effect of calibration
  • Calibration in mV
  • “Fixed pattern noise” is gone
  • Crosstalk from clock remains
noise measurement
Noise Measurement

Trigger

mV

0.55 mV / 1V

> 11 bits

mV

crosstalk inside drs
Crosstalk inside DRS
  • Measured with signal generator
  • Current crosstalk is not good but acceptable for the moment
  • Since integral of crosstalk is zero, it should mainly affect the timing and pile-up recognition
  • Expect crosstalk in DRS3 (differential inputs) smaller by ~5x

+

=

current readout mode
Current readout mode
  • First implemented in DRS2
  • Sampled charge does not leave chip
  • Current readout less sensitive to cross-talk etc.

R

I

Vin

Vout

read

write

. . .

C

I = c1 * Vin + c2 * Vin * kT

temperature dependence
Temperature Dependence

Tc ~ 1.4 % / ºC

Vout [V]

T [º C]

DRS2 has a marked dependence on the temperature

strategy for temperature problem
Strategy for Temperature Problem
  • Put temperature sensors on boards
  • Keep electronics temperature stable (control air condition with temperature sensors on electronics to compensate for day-night cycles)
  • Calibrate temperature drifts as much as possible, expect ~1% accuracy by using the constant level test pulses
  • Design DRS3 with temperature compensation

Vin

Vout

write

C

Ib

Matched

Transistors

drs board production
DRS board production
  • New mezzanine card by end of July → 192 channels
  • Test of mezzanine card in September
  • Next mezzanine card production cycle in October → O(1000) channels
  • All channels (~2000 DC, ~800 XE, ~200 TC) before detectors become ready
  • Start design of DRS3 in October
  • Replace DRS2 by DRS3 in the second half of 2006
drs3 design
DRS3 Design

New DRS3 design:

  • All channels differential
  • Additional shielding between channels (ground bond wires)
  • Reduced readout time (5x) minimized dead time
  • Internal cascading allows for n x 1024 sampling bins
  • Intrinsic temperature compensation
slide54

DRS (DAQ)

2003

2004

2005

2006

DRS2

DRS2 production

1600 chn

DRS2 test board

DRS3

VME boards

Full System

DRS2

DRS2 production

4000 chn

DRS2 test board

4000 chn

DRS3

VME boards

Replacement

Full System

Milestone

Design

Manufactoring

Assembly

Test

conclusions
Conclusions
  • An electronics integration scheme has been developed
  • Minor details needs to be fixed
  • All key electronics elements will be available before March 06
  • A test of the final electronics systems, together with crates, in magnetic field environment is planned in autumn
electronic daq overview

1:1

1:1

1:1

Active

Splitter

Active

Splitter

Active

Splitter

1:1

1:1

1:1

4:1

4:1

4:1

Electronic/DAQ overview

area

Trigger

2+1 VME

crates

216

PMT

trigger

LXe

ready

612

PMT

6 VME

crates

optical

fiber (~20m)

DRS

Board

(32chn)

+ CPU

Front-End PCs

60

Rack – PC (Linux)

TC

PMT

Ramp

Rack – PC (Linux)

SIS

3100

SIS

3100

Rack – PC (Linux)

1920

Rack – PC (Linux)

DRS

Board

(32chn)

+ CPU

DC

DC

Pre-Amp

Rack – PC (Linux)

Rack – PC (Linux)

Gigabit

Ethernet

Rack – PC (Linux)

Rack – PC (Linux)

Raw data:

2920 channels

Up to 100 Hz

50% / 10% / 10% occupancy

2kB / waveform

-> 5 x 25 MB/sec.

Rack – PC (Linux)

Fitted data:

10 Hz waveform data

-> 1.2 MB/sec

90 Hz ADC / TDC data

-> 0.9 MB/sec

Rack – PC (Linux)

On-line farm

storage
