Presentation Transcript
slide1

An optimization of the SAFER+ algorithm for custom hardware and TMS320C6x DSP implementation.

By:

Sachin Garg

Vikas Sharma

motivation
Motivation

SAFER

  • Function can be implemented on different platform
  • Each platform has its own implementation & optimization issues

Software

Hardware

FPGA

Custom

We explore these issues by implementing SAFER+ (An Encryption standard) on different platform

safer secure and fast encryption routine a n introduction
SAFER+ (Secure And Fast Encryption Routine)An introduction

Encryption Structure

  • SAFER+ processes in blocks of 16 Bytes
  • SAFER+ can have a key length of 128, 192 or 256 bits
  • Can have 8, 12 or 16 number of rounds respectively
  • Each round uses two 16-Byte sub keys.
fpga implementation

Max.Freq.=43MHz

FPGA-Implementation
  • Resource usage = 13%
  • Used as a Bench Mark implementation
custom cell based implementation

Result Freq= 262 MHz

Custom(cell based) Implementation

1.Synopsys Design compiler used

2.Retiming and Pipelining driven synthesis

3. Commands used optimize_design pipeline_design balance_register

software implementation on tms320c64x
Software implementation on TMS320C64x
  • Algorithm implemented in C
  • Current results
summary

And writing report

Summary

Tasks Accomplished

  • Bench mark design implemented on FPGA (43 MHz)
  • Synthesized & optimized the design using DC and did standard cell based layout and achieved 4X improvement in performance (262 MHz).
  • Implementation in C for TMS320C64x DSPcore
  • Ongoing Work
  • Further optimization of C code for TMS320C64x DSPcore
