applocker your solution for true application smackdown

Required Slide


AppLocker: Your Solution for True Application Smackdown

Jeremy Moskowitz, Group Policy MVP

Chief Propeller-Head:

Founder: PolicyPak Software (

what s the point why do you need application whitelisting technology
WHAT’S THE POINT?Why do you need “Application Whitelisting” technology?
  • Common arguments “against” the need:
    • “We’re already locked down…”
    • “We’re already running with ‘standard user’ rights.”
  • Good uses for:
    • Prevent users from running “portable” (non-installed) applications
    • Prevent users from installing MSIs.
      • Seriously: Try FireFox or Google Chrome as local non-elevated user
    • Restricting parts of the operating system (sol.exe)
    • Restricting Junior admins or “prying eyes” from “big things” (gpmc.msc)
    • Ensuring specific applications of “correct” version numbers are used
in the beginning there was software restriction policy srp
IN THE BEGINNING….There was Software Restriction Policy (SRP)

And it was good…

  • Built-in to Windows XP
  • Has whitelisting and blacklisting ability
  • Four rule types:
    • Hash
    • Path
    • Windows Installer / Network Zone Rule
    • Certificate rules
in the beginning there was software restriction policy srp4
IN THE BEGINNING….There was Software Restriction Policy (SRP)
  • Of course, still available on XP and…
  • Also available in ALL versions of Windows 7
  • No “direct” migration path to AppLocker. Will need to re-create rules during a transition time
  • Huge gotcha ! :
    • Once AppLocker is turned on, and first rules are applied.. SRP no longer enforced!
applocker 101
  • Good news:
    • Under the hood, references as “SRPv2”
    • Active Directory Group Policy or Local Policy
    • Way better for whitelisting
  • Targets can be:
    • Windows 7
    • Windows Server 2008 / R2
  • Only available in the following Windows 7 editions:
    • Enterprise
    • Ultimate
immutable applocker laws
  • Applocker’s “brain” is in a loop, like this:
    • Law #1: Explicit deny: A specific rule which denies an action.
    • Law #2: Explicit allow: A specific rule which allows an action.
    • Law #3: Implicit deny: All files that are not specifically named by an Allow rule are automatically blocked.
  • Not related to Azimov’s “Three Laws or Robotics”
applocker rules
  • Action:
    • Allow
    • Deny
  • Based upon condition:
    • Path
    • File Hash
    • Publisher
  • Rule types:
    • Executable
    • DLL
    • Windows Installer
    • Script
  • Can make “Exceptions”
  • Mix and Match, like this:
    • ALLOW Executable, based upon who PUBLISHED the application (publisher condition) EXCEPT a specific application (or version), which is DENIED
    • Windows Installer Rule, based upon a specific build (file hash)
    • DENY Scripts, based upon where its executing from (PATH condition), EXCEPT for a certain (known good) directory
applocker four steps to success
APPLOCKERFour Steps to Success
  • Setting up the default rules (highly recommended, not required)
  • Adding more rules (also, highly recommended, not required)
  • Leveraging AUDIT vs. ENFORCE mode
  • Turning on the client’s Application Identity (AppID) service
step 1 setting up the default rules or how not to blow your foot off
STEP 1: SETTING UP THE DEFAULT RULES(or… how NOT to blow your foot off)
  • Default rules are NOT set by default.
  • Different default rules for each rule type
executable rule defaults good ideas to get started with
EXECUTABLE RULE DEFAULTS(Good ideas to get started with)
  • Allow anything to run that’s already installed in Program Files
  • Allow anything to run if it’s in the Windows folder
  • Allow local administrators to run any file
step 2 adding your own rules
  • On rule type, right-click, select “Create New Rule…”
  • Add your rule, with conditions (will see in demonstration)
step 3 audit only vs enforce
  • AppLocker Modes:
    • Enforce rules
    • Audit Only
      • Logs go to Applications and Services Logs | Microsoft | Windows AppLocker
step 4 turn on appid service on client
  • Final step to fully engage AppLocker
  • Can be done manually (good for one-off testing)
  • Can be scripted
  • Can be done via Group Policy Preferences (my preferred way!)
applocker results
  • Default user pop-up as seen here:
applocker safety precedence how safe can you get
APPLOCKER: Safety PrecedenceHow safe can you get?
  • Hash rule:
    • Safest, most specific
    • Issue: Unmanageable at scale
  • Publisher Condition
    • Next safest
  • Path Condition
    • Next safest
    • Issue: Might expose “too much” file system within whitelist
applocker security awareness how the bad guys can still get you
APPLOCKER: SECURITY AWARENESSHow the bad guys can still get you
  • Path Condition: They could figure out where an application isn’t allowed to run, and move it to a place that is allowed to run. (ie: move the application to somewhere in Program Files and run from there; the default rule allows me to do that.)
  • Publisher Condition: A publisher certificate gets compromised. A “bad guy” signs malicious code with (Allowed) certificate
  • Code Injection: .DLL rules; fool .EXE it’s not supposed to load.
    • Safe when .DLL rules are enabled
applocker security awareness part ii how the bad guys can still get you
APPLOCKER: SECURITY AWARENESS (Part II)How the bad guys can still get you
  • EXE Rules: .EXE, .COM – and that’s it.
    • DLL Rules: .DLL, .OCX – and that’s it.
  • Script Rules: .PS1, .BAT, .CMD, .VBS, .JS – and that’s it.
    • AppLocker is extensible by 3rd party script hosts
  • Windows Installer Rules: .MSI and .MSP – and that’s it.
applocker more info for users default vs more info dialog
APPLOCKER: MORE INFO FOR USERSDefault vs. “more info” dialog
  • Optional result
  • Computer | Policies | Administrative Templates | Windows Components | Windows Explorer | Set a Support Web Page Link
automatically generating rules
  • Get “representative machine”
  • Automatically Generate Rules
  • Export Rules / Import Rules
applocker appv gotcha
AppLocker + AppV - GOTCHA
  • AppV has a “virtual drive” it uses
  • Usually Q: drive
  • Must Allow the Q: drive, or AppLocker continues to lock
applocker powershell automation subtitle
  • Get them via PowerShell upon Windows 7 vusing
    • Import-module applocker
  • PowerShell Cmdlets
    • Get-AppLockerFileInformation
    • Get-AppLockerPolicy
    • Set-AppLockerPolicy
      • Apply specific “fully formed” AppLocker XML policy
    • New-AppLockerPolicy
    • Test-AppLockerPolicy
  • Check out:
applocker powershell examples

Get AppLocker File Info (for .EXEs) :

Get-AppLockerFileInformation -Directory 'C:\Program Files' –recurse -FileType exe

Create AppLocker Policy XML rule set:

(Get-AppLockerFileInformation… line above) | New-AppLockerPolicy -ruletype publisher, hash -user everyone -XML

Create a new Applocker Local GPO with that rule set:

Get-AppLockerFileInformation -Directory 'C:\Program Files' -recurse -FileType exe | New-AppLockerPolicy -ruletype publisher, hash -user everyone | Set-AppLockerPolicy–merge

applocker powershell examples part 2

Create a new GPO AppLocker Policy:

Get-AppLockerFileInformation -Directory 'C:\Program Files' –recurse -FileTypeexe | New-AppLockerPolicy -ruletype publisher, hash -user everyone | Set-AppLockerPolicy-LDAP "LDAP://{4391FF66-197D-4BBE-B83E-4B536A09B543},CN=Policies,CN=System,DC=Fabrikam,DC=com"

Dump a domain-based GPO’s AppLocker rules:

Get-AppLockerPolicy -Domain -LDAP "LDAP://{4391FF66-197D-4BBE-B83E-4B536A09B543},CN=Policies,CN=System,DC=Fabrikam,DC=com“ –XML > output.xml

The applications for which a user is blocked:

Step 1: Get-AppLockerPolicy-EFFECTIVE -Xml > output2.xml

Step 2: Get-ChildItem-Path "C:\Program Files" -Recurse -Filter *.exe | Convert-Path | Test-AppLockerPolicy -XMLPolicy.\output2.xml

some tips and best practices part 1 of 2 things to think about before during after your rollout
Some Tips and Best Practices (PART 1 of 2)Things to think about before / during / after your rollout
  • ALLOW rules with DENY exceptions, likely your best bet
  • DLL rules – turn on if you have the horsepower and can monitor it
    • Subtip: Note, not all DLLs from a package are necessarily digitally signed !
  • Try to get your “internal Devs” on board with digitally signed apps (.EXEs and .DLLs)
some tips and best practices part 2 of 2 things to think about before during after your rollout
Some Tips and Best Practices (PART 2 of 2)Things to think about before / during / after your rollout
  • When ready, use Group Policy Preferences to turn on AppID service en-mass
  • Don’t turn on the WRONG service, like “Application Experience” (oops!)
  • Start with Executable Rules, and move onward toward Install, Script, and possibly DLL rules
  • Emergency Troubleshooting:
    • Use Group Policy Preferences to DISABLE AppID service
more information
  • Microsoft AppLocker Documentation:
    • as Beta)
  • Microsoft AppLocker PowerShell Reference
  • Understanding why users can install MSI apps as regular users (Darwin Sanoy)
  • and
    • Hands on examples (live training, and in book form)
