Two Dimensional Hydraulic Fracture Simulations Using FRANC2D. Qingfeng Tan. Flow Index. 10. 1. 10. 100. 1000. 10000. k. /. k. frx. Vapor extraction well intersecting horizontal hydraulic fracture, from Bradner (2002). Importance of 2-D. Objective.

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about 'Two Dimensional Hydraulic Fracture Simulations Using FRANC2D' - Albert_Lan


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript
vapor extraction well intersecting horizontal hydraulic fracture from bradner 2002

Flow Index

10

1

10

100

1000

10000

k

/

k

frx

Vapor extraction well intersecting horizontal hydraulic fracture, from Bradner (2002)
objective
Objective

Develop and apply a model for predicting the forms of curving hydraulic fractures in two dimensions

overview
Overview
  • Previous work
    • Vertical and horizontal fracture
    • Analytical models
  • Theoretical Analysis
    • Coupling mechanical and fluid flow analysis
  • Code Development
    • Automatic propagation (EXC_AUTO_DRIVER_FLOW)
    • Fracture form calculation routines
    • Fluid flow simulation routines
  • Application
    • Shallow soil model
    • Effects of layering and lateral residual compression
hydraulic fracture design

h

X

Q

h

Y

Q

a

X

Z

a

Y

Z

Q

Z

Q

Z

d

d

r

r

a

a

Hydraulic Fracture Design

Vertical Fractures

(a)

(b)

Horizontal Fractures

(c)

(d)

previous models
Previous Models

Pressure

time

Length

time

Aperture

time

simulate hydraulic fracture
Simulate Hydraulic Fracture
  • Fracture aperture—analyze as elastic displacements due to fluid pressure
  • Fluid pressure—analyze as flow in deforming fracture
  • Propagation—require stress intensity to equal critical value
problem with analysis in 2 d
Problem with Analysis in 2-D
  • Fracture curves-- numerical methods for stress analysis required
  • Fracture propagation-- analyze as a series of quasi static models. Requires many analyses to be conducted.

Need FEM method with automatic regridding around fracture

franc2d
FRANC2D
  • 2-D stress and displacement
  • Developed for structural fracture mechanics applications
  • Auto regrid around

fracture

  • Fluid flow within

fracture not included

fracture with fluid flow coupled approach
Fracture with Fluid Flow-Coupled Approach
  • Modify FRANC2D to perform mechanical analysis, then calculate geometry of fracture, caused by fluid pressure, and other loadings
  • Fluid flow analysis adjust fluid pressure due to the shape changes of fracture, coupled with mechanical analysis
  • Propagation criterion:

is decided by fracture geometry and fluid pressure

propagation
Propagation
  • KI=Stress intensity factor
  • KI=KIc for propagation
  • KIC is material property, called fracture toughness.
how to ensure k i k ic
How to ensure KI=KIc?

Pressure

Ptip

x

KI

KIc

Ptip

code development
Code Development
  • Fracture propagation control routine

-EXC_AUTO_DRIVER_FLOW

  • Fracture geometry calculation routines

-EXC_LENGTH_FLOW

-EXC_APER_FLOW

-EXC_VOLU_FLOW

  • Fluid flow simulation routines

-FLUID_FLOW_INIT

-FLUID_FLOW_CALC

automatic propagation subroutine
Automatic Propagation Subroutine
  • Fluid flow and mechanical analysis coupling to decide pressure and geometry
  • Propagation criterion: KI=KIC
  • Auto-remesh around fracture tip
fracture form calculation
Fracture Form Calculation
  • Length – EXC_LENGTH_FLOW
  • Aperture – EXC_APER_FLOW
  • Volume – EXC_VOLU_FLOW
  • Obtain Crack node info
  • Calculation in each segment, then integral
fluid flow and aperture subroutine
Fluid Flow and Aperture Subroutine
  • Calculate new heads using initial aperture
  • Calculate aperture using new head
  • Calculate heads using new aperture
  • Repeat and compare heads and apertures between successive iterations
  • Converge when change is less than tolerance, usually less than 7 iterations
propagation subroutine
Propagation Subroutine
  • Calculate KI for pressure at tip
  • Adjust pressure at tip slightly, redo fluid pressure calculations, and calculate new KI
  • Use two values of KI and pressure tip to interpolate new value of pressure tip that should give KI=KIc
  • Check KI and revise pressure tip as needed until KI is within tolerance of KIc
verification uniform pressure model setting

a

VerificationUniform Pressure: Model Setting

P

  • Infinite elastic media
  • Uniform pressure
  • Radial symmetric
applications
Applications
  • Hydraulic fracture in shallow soil:
      • Gravity
      • Fluid injection
  • Soil with under-lying softer material
  • Soil with high lateral residual stress
field data adoption
Field Data Adoption

Cross 4

Cross 3

  • Four cross-section selection
  • Each cross-section starts from center of fracture to the edge of it, perpendicular with each other
  • Fracture path, uplift, and sand extent data are adopted

0.9

0.7

0.5

0.3

Cross 2

0.1

N

Cross 1

0

5

10

15

feet

general case model setting
General case-Model Setting

Depth

0 m

-1.6 m

-2 m

frx

-5 m

0 m

12 m

Distance from well

aperture and uplift
Aperture and Uplift

(m)

Average radial extent of sand

effects of layering
Effects of Layering

observed

Richardson

Simulated

conclusions
Conclusions
  • FRANC2D has been modified to simulate hydro-mechanical coupling conditions during hydraulic fracturing.
  • A new simulation tool, HFRANC2D?, is available
  • The model has been verified using analytical solutions, error within a few percent
conclusions applications
Conclusions, applications
  • Gentle bowl-like forms of hydraulic fractures in shallow soils can be predicted.
  • Effects of state of stress and material properties can be predicted and results resemble field observations.
