  1. The MobileGrid Concept Vicente Olmedo Technical University of Madrid

  2. Contents • Introduction • The Akogrimo Project • The Next Generation Mobile Grid Concept • The Session Initiation Protocol (SIP) • SIP fundamentals • The Session Description Protocol (SDP) • SIP usage for Web Service mobility

  3. Introduction (1/2) • The Akogrimo EU IST project is aimed to the design and implementation of a Next Generation Mobile Grid. • Concept: Next Generation Mobile Grid (NGMG) • Concept: Mobile Dynamic Virtual Organization (MDVO)

  4. Introduction (2/2) • NGMG = Mobile Network + Grid Services Session Initiation Protocol (SIP) Session Management Mobility Support Presence & Context

  5. The Session Initiation Protocol (1/4) • Standardized by the IETF in RFC 3261. • Signaling protocol targeted to the management of sessions in IP networks. • SIP is independent of the type of session being managed. • Basic messages (methods): REGISTER, INVITE, ACK, BYE, CANCEL, OPTIONS. • Extensible: new methods can be defined in order to support new functionalities. • Signaling entities also defined: User Agent, Proxy, Registrar.

  6. The Session Initiation Protocol (2/4) • User registration process

  7. The Session Initiation Protocol (3/4) • Session establishment and termination

  8. The Session Initiation Protocol (4/4) • Message format example Request Line INVITE sip:volmedo@dit.upm.es SIP/2.0 Via: SIP/2.0/UDP 138.4.3.130:3456 CallID: a2e3a@138.4.3.130 From: sip:villagra@dit.upm.es To: sip:volmedo@dit.upm.es Cseq: 1 INVITE Content-type: application/SDP Content-Length: 117 v=0 c=IN IP4 138.4.7.148 m=application 8080 HTTP soap+xml a=setup:passive a=wsdl:http://138.4.7.148/service.wsdl SIP Headers Message body (SDP)

  9. Web Services are getting mobile • Network architectures tend to convergence  access technology independence is a must. • Architectural design tends to Service Oriented Architectures. • User terminals becoming more and more powerful. • In Grid environments, users themselves can also be resources.

  10. Traditional, fixed scenario

  11. Mobile, ubiquitous scenario SIP session establishment Classical SOAP interaction

  12. Extending SDP • SDP syntax can be extended by the definition of new attributes. Request Line INVITE sip:volmedo@dit.upm.es SIP/2.0 Via: SIP/2.0/UDP 138.4.3.130:3456 CallID: a2e3a@138.4.3.130 From: sip:villagra@dit.upm.es To: sip:volmedo@dit.upm.es Cseq: 1 INVITE Content-type: application/SDP Content-Length: 117 v=0 c=IN IP4 138.4.7.148 m=application 8080 HTTP soap+xml a=setup:passive a=wsdl:http://138.4.7.148/service.wsdl SIP Headers Message body (SDP)

  13. Conclusions • SIP for signaling, SOAP for application. • Mobility and ubiquity for Web Services. • Web Services can make use of full SIP capabilities (e.g. session transfer). • No need to standardize new SIP mechanisms. • The new SDP attribute needs to be standardized.

  14. Thank you! Questions? Vicente Olmedo <volmedo@dit.upm.es>
