進 度 報 告. 宋育泰. 2004/12/06. NPGS. 銅網鍍金後 300x SEM 照片. Result ( 劑量 130). Result ( 劑量 140). Practice for Hall Bar. 製 程. Wafer: 3*3 mm C015A. 1.Clean TCE ACEMethylDI-Water ……repeat 2.Coating AZ6112 Step1: 8000 (r.p.m.) 2 (sec) Step2: 6500 (r.p.m.) 15 (sec)

symona
Download Presentation

2004/12/06

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 進 度 報 告 宋育泰 2004/12/06

  2. NPGS

  3. 銅網鍍金後 300x SEM 照片

  4. Result (劑量130)

  5. Result (劑量140)

  6. Practice for Hall Bar

  7. 製 程 Wafer: 3*3 mm C015A 1.Clean TCEACEMethylDI-Water ……repeat 2.Coating AZ6112 Step1: 8000 (r.p.m.) 2 (sec) Step2: 6500 (r.p.m.) 15 (sec) 3.Baking 80 (℃) 80 (sec) 4.曝光 80 (sec) MASK: Omhic contact 5.顯影 Developer:AZ300 6.蒸鍍 1.Au--10(nm)--2.0~4.0(A/sec) 2.AuGe--20(nm)—2.0~4.0(A/sec) 3.Au--20(nm)--3.0~4.0(A/sec) 4.AuGe--20(nm)--2.0~4.0(A/sec) 5.Au--80(nm)--3.0~4.0(A/sec) 7.Left-off 8.燒結 420 (℃) 15(min) 通 H2:N2=3:7 9.Repeat (2.) and (3.) 10.曝光 80(sec) MASK:MESA 11.Repeat (5.) 12.蝕刻 8(sec) around 0.8(nm) H2SO4:H2O2:H2O=1:8:80

  8. Result
