Automatic data processing adp eurofighter typhoon technical publications

StephenBarnard

Automatic Data Processing

(ADP)

Eurofighter Typhoon

Technical Publications

BAE SYSTEMS Lead,

JSF Joint- Service Technical Data (JTD),Fort Worth, Texas


Eurofighter typhoon project

‘Eurofighter Typhoon’ Project:

‘Eurofighter Typhoon’ Technical Publications

  • ‘Eurofighter Typhoon’ is a BAE SYSTEMS and UK Lead Project, both in its deployed Technology and ‘SGML’ Data Production.

  • ‘Eurofighter Typhoon’ is a ‘Four Nation Partnership’ project:ALENIA Aeronautica, EADS_CASA, EADS_Deutschland and BAE SYSTEMS - Eurofighter Partner Companies (EPC).

  • Publications Data and all supporting Illustrations are created to a contractually agreed standard, by all EPCs – ‘AECMA S1000D’ to a Modular structure in the form of ‘Data Modules’ (DM).

  • BAES Eurofighter Typhoon ‘Tech Pubs’ area, consists of Approx. 60 People - Authors, Illustrators etc.


Data production milestones

Data Production Milestones:

‘Eurofighter Typhoon’ Technical Publications

  • Each ‘EPC’ is responsible for the provision of ‘Publications Data’ based on its Contractual SDR/EDR Work-share, as defined within ‘LSA’.

  • Publications information is generated within a ‘Common Source Database’ (CSDB) environment in accordance with ‘AECMA S1000D’ DTD .

  • ‘Common’ Publications Data is exchanged between the EPC ‘CSDB’, as SGML ‘Data Modules’ (DM) and delivered by each Partner Company against its customer contractual needs.

  • CSDB data is ‘Technically Verified’ by ‘Engineering Design Authority’ (Industry) before formal issue or release.

  • ‘Verified’ Exchanged DM’s are further customised (Nationalised), according to the requirements of the ‘Nations’ Air Forces (National Specific Deliverable).


Automatic data processing adp eurofighter typhoon technical publications

Development Support

ProductionInvestment

In-Service

Support

System

Breakdown

R, M & T

Analysis

Maintenance

Analysis

Tech Pubs

LSA/SAS

Candidate Selection

R, M & T

Data

Selection

Maintenance

Concept

Maintenance TaskDescription

MaintenancePlan

AGE

Training

Identification of

Support

Requirements

Level of

Repair Analysis

LSA

Materiel Support

Integrated Logistic Support

Integrated Logistic Support from Design to Support


Data production milestones1

Data Production Milestones:

‘Eurofighter Typhoon’ Technical Publications

  • Development Aircraft Programme started Dec 1990

  • ‘CSDB’ Deployed Jan 1991

  • Scaling down of Eurofighter Contract Jan 1994 to Sep 1995pending Signing of ‘Production Contract’

  • Series Aircraft data production programme Jan 1997 Including:Introduction of ‘FrameMaker + SGML’ Authoring toolset and implementation of ‘AECMA S1000D DTDs’ across all ‘Information Sets’ on the project.

  • Interactive Electronic Deliverable provided Sept 2002 to UK Customer


Automatic data processing adp eurofighter typhoon technical publications

Common Source Database (CSDB)

Data generated on ‘workshare basis’ and exchanged with EPCs to fully populate CSDB

CSDB

Data Modules to

AECMA DTD’s:

- Maintenance

- Schedules

- Air Fault

- Aircrew

- Equipment

- IPD

Data extracted for ‘National

Publication’ requirements

- NPB

In-process Review and

Customer Comment

Data Module (DM):

Self-contained unit of text and illustrations

Illustrations stored in CGM, CCITT Group 4 or JPEG format

Text content marked-up in SGML

DM structure controlled by AECMA S1000D ‘DTD’

‘Eurofighter Typhoon’ Technical Publications


Automatic data processing adp eurofighter typhoon technical publications

‘Eurofighter Typhoon’ Technical Publications

Publication Standards

  • Technical Publications -AECMA S1000 D‘Data Modules’

  • Materiel SupportAECMA 2000 M

  • TextSGML (ISO 8879:1986)

    XML (W3C WD-xml-lang-970331)

    XSL

  • AECMA Simplified English PSC-85-16598

  • IllustrationsCCITT Group 4 (MIL-PRF-28002)

    CGM Version 4 (ISO 8632) (MIL-PRF-28003A)


Automatic data processing adp eurofighter typhoon technical publications

‘Eurofighter Typhoon’ Technical Publications

Information Sets:

  • Aircrew Information

  • Aircraft Maintenance Information

  • Fault Reporting/Isolation Information

  • Non-Destructive Test Information

  • Wiring Data

  • Structural Repair Information

  • Storage Information

  • Corrosion Control Information

  • Maintenance Planning Information

  • Mass and Balance Information

  • Aircraft Inventory

  • Weapon/Stores Loading Information

  • Cross Servicing Guide

  • Non-Nuclear Weapon Delivery Information

  • Illustrated Parts Data

  • On-Aircraft Engine Maintenance Information

  • Battle Damage Repair Information

  • Equipment/AGE Information


Eurofighter typhoon technical publications

‘Eurofighter Typhoon’ Technical Publications

AUTHORING AND

ALENIA

SERVER

ILLUSTRATION

EJ

WORKSTATIONS

EADS_D

EADS_C

WORK IN PROGRESS

SUBCONTRACTOR

COMMON SOURCE DATABASE

CONTRIBUTORY DATABASES

SGML TAGGED TEXT

RASTER &

VECTOR

ILLUSTRATIONS

TRAINING

CORE

EPOS

ASTRAL

LSAR

NATIONAL PUBLICATIONS

BASE (NPB)

WIRING

CUSTOMER

SGML TAGGED TEXT

TPUBS

RASTER &

VECTOR

SUPPLIERS

ILLUSTRATIONS


Automatic data processing adp eurofighter typhoon technical publications

Integrated Technical Publications Process

National Publication Base (NPB)

  • Data filtered and extracted from the CSDB to a Customer-specific National Publications Base (NPB) from which output deliverable DMs are generated.

  • DM’s are delivered in the form of an ‘IETP’.Specific hard copy publications are provided (with some additional processing) – Aircrew FRCs

  • DM’s to be accessed via the ‘Ground Support System’ (GSS) within the integrated Engineering Support System (ESS) and Mission Support System (MSS) utilities, using the integrated ‘Browser’ - “trilogiView”.

  • Data Modules may also be accessed on dedicated Stand-alone/Networked applications.


Automatic data processing adp eurofighter typhoon technical publications

Customer Requirements

CUSTOMER

CSDB

IETP

SGML Text

Illustrations

IPL Data

(AECMA 2000M)

AGE

MS

Design

Engineering

AGE Data Sheet

Wiring Diagrams

& Data

Integrated Technical Publications Process

Nationalisation Process:

Commenting (via TPIRF)

NPB

Customise

Deliverables


Automatic data processing adp eurofighter typhoon technical publications

‘Eurofighter Typhoon’ Technical Publications

Current Quantification in Core Programme

  • Aircrew 800DM

  • General Vehicle2000DM

  • Specific Systems 15’500DM

  • Airborne Equipment 5000DM

  • Aerospace Ground Equipment 1700DM

  • Total:25’000DM


Automatic data processing adp eurofighter typhoon technical publications

‘Eurofighter Typhoon’ Technical Publications

Data Module Updates:

  • An Update/Revision Process was established, as contractually agreed.

  • Customer Change Requests (CR’s) are provided using the Technical Publications Improvement and Reply Form (TPIRF) process.

  • Service Bulletins will be issued as necessary. Containing information for Modifications, Special Inspections/Checks, Replacement/Substitution of Parts, etc, to be carried out by the customer.


Eurofighter typhoon technical publications1

‘Eurofighter Typhoon’ Technical Publications

What are the benefits of the Eurofighter Typhoon Approach ?Data Creation and Production:

  • Use of Neutral International Standards (ISO, CALS, etc.)

  • Efficient update/change process

  • Effective Configuration Management with all other Contractually agreed Deliverables.

  • Interactive Electronic Technical Publication Deliverable

  • Integrated Logistic Support deliverable

  • User friendly, Web-based viewer

  • Use of Integrated Off-the-Shelf software(Isoview etc.)

  • Easy to manage and update

  • Facilitates rapid search and retrieval of required data.


Eurofighter typhoon technical publications2

‘Eurofighter Typhoon’ Technical Publications

The application of ‘AECMA S1000D’ provided:

  • Flexibility and efficiency to the Technical Data process, allowing Customized Data to be produced. Resulting in the generation of Multi-Media Deliverable - Interactive Electronic Technical Publication (IETP).

  • Exchange of contributory data from suppliers and partners, utilising different systems/applications.

  • Longevity, reusability

  • “Single source - multiple use”

  • “Write once” – “Use many times”.

  • “Style Sheets” for various layouts

  • Various document views


Interactive electronic technical publications viewer browser solution

Interactive Electronic Technical Publications - Viewer/Browser Solution

IETP Browser Development

Developed via the ‘trilogi’ (tri-service Logistic Information) partnering agreement between BAE SYSTEMS and UK MoD DLO (Defence Logistics Organisation)

  • Major involvement of UK DPA (Defence Procurement Agency) and the ‘Eurofighter IPT’

  • Browser solution known as “trilogiView”

  • First formal populated “trilogiView” delivered to UK MoD Sept 01 - “trilogiView” v2 released in March 02

  • Initial roll-out on Eurofighter Typhoon, closely followed by other UK MoD Land, Sea and Air Programmes

  • Eurofighter ‘Wiring Data’ delivered as a database (Wiring Data Management System - WDMS). Developed by BAES Eurofighter Project.


  • Automatic data processing adp eurofighter typhoon technical publications

    CSDB

    /NPB

    Interactive Electronic Technical Publications- Viewer/Browser Solution

    CD/DVD

    t r i l o g i View

    Multiple Input

    Standards

    Data Specifications

    AECMA S1000D*

    DEFSTAN 00-60*

    AvP70

    ATA2100

    NES40

    AESP

    Mil-Std 83495

    Data Types

    SGML*

    XML*

    PDF*

    All word processor

    types

    Graphics

    CGM

    (all versions)*

    TIFF

    JPEG

    GIF

    etc.

    • A managed end to end

    • Build and Delivery

    • Process

    • t r i l o g i View

    • Provides:

    • One browser for all

    • Technical Information

    • Internet capability

    • XML Viewer

    • View all data in

    • native form

    • A solution for all BAE SYSTEMS platforms, delivered EuroFighter as lead project

    • Access by:

    • Internet

    • Intranet

    • SDE

    Hard Copy

    Multiple Delivery

    Methods

    *Eurofighter Agreed Standard


    Automatic data processing adp eurofighter typhoon technical publications

    Interactive Electronic Technical Publications - Viewer/Browser Solution

    Training

    Maintenance

    Inspection

    Wiring

    Aircrew

    ciros

    Battle Damage

    Assessment

    IPD

    Integration with

    Eurofighter

    GSS utilities

    Fault Isolation

    IETP

    Browser


  • Login
