  1. THANKS FOR YOUR INTEREST!!

  2. THE CLEVELAND VALVE STORY • Cleveland Valve & Gauge • Renew Valve & Machine Company • Phoenix Partners, LLC Who are we?

  3. THE CLEVELAND VALVE STORY • Founded @ 1857 • Acquired by Vernon Schill and others 1965 • Max Czarnota marries daughter – the ’70’s • Doug Gifford employed – the ’80’s • Sold to Jay Industrial Technologies 1997 • Repurchased in 2004 by Phoenix Partners LLC (Doug Gifford & J.B. Rorick)

  4. New Products Offered • Dresser/Consolidated Pressure Relief Valves • Tyco Product Line • Yarway, Hancock, Dewrance, Rovalve, Intervalve, Raimondi, Fasani, Gimpel, Sempell • High Pressure Ball Valves • SST, Jarecki • Rodney-Hunt Butterfly Valves • Re-certified Limitorque Motor Actuators

  5. Services Offered • Pressure Relief Valve Repair • Line/Isolation Valve Repair • (Gate, Globe, Check, etc.) • Control Valve Repair • (Masoneilan, Fisher, Valtek, etc.) • Motor Actuator Repair & Retrofitting • Shop & Field Machining Services

  6. Valve Repair • Capabilities • Pressure Relief Valves • Certified Dresser Green Tag Center • Mobile Repair Facility • Field Service Capabilities • Large Inventory of Parts and New Valves • Inline Electronic PRV Testing and Setting • Factory Trained and Certified Technicians • National Board VR Stamp Holder • High Pressure High Capacity Shop Facilities • Air, Steam, Liquid

  7. What is a Dresser Green Tag Center ?

  8. Green Tag Center Overview • Program Started in 1982- Dresser Franchise • Philosophy- “Combine the highest level of Valve Repair with off the shelf valve assembly.” • Factory/OEM expertise to plant door steps • GTC Standards- Training, QC Audits, UV-V, VR stamps, facilities, test equipment

  9. Dresser- GTC • Independently owned repair, sales and service organization that represents the OEM (Consolidated) in their local territory • Brings Consolidateds 115 years of PRV experience to the local area • OEM- training, annual audits, drawings • Local Inventory- New Valves and Parts

  10. Green Tag Centers • 44 Green Tag Centers in North America • GTC’s represent over half Consolidated Sales • Program is “Maturing” • Next Level- Plant Safety Ownership/ValvKeep

  11. Equipment High Capacity Test Eqt 1500 # Boiler Tools/Machines/Truck Training 3 Phases of Technician training Annual Dresser Audit ASME/NBIC Stamps V, UV, VR QC Manual/ Program VR/GTC paperwork Record storage-mngt Requirements to be a GTC • Consolidated Invty • Average $400-750k • Springs/accessories

  12. SHOP REPAIR ...

  13. WORLD CLASS INVENTORIES

  14. REPLACEMENT PARTS INVENTORIES

  15. MOTOR ACTUATOR REPAIR

  16. ALL MAKES – ALL MODELS

  17. REMOVE IT … REPAIR IT … INSTALL IT. AS FAST AS OVERNIGHT

  18. Motor Op Parts

  19. MOTOR OPERATOR REPAIR PROCESS • BEFORE:

  20. MOTOR OPERATOR REPAIR PROCESS • AFTER:

  21. MOTOR OPERATOR REPAIR PROCESS • CATALOGING & TEAR-DOWN:

  22. MOTOR OPERATOR REPAIR PROCESS • CLEANING:

  23. MOTOR OPERATOR REPAIR PROCESS • COMMON FINDINGS: • Electrical • Motor Problems • Over-torquing • Gearing & Drive-train wear

  24. MOTOR OPERATOR REPAIR PROCESS • Electrical Repairs – AS FOUND – CHAOS :

  25. MOTOR OPERATOR REPAIR PROCESS • Electrical Repairs – ORDER RESTORED:

  26. MOTOR OPERATOR REPAIR PROCESS • MOTOR REPAIRS:

  27. MOTOR OPERATOR REPAIR PROCESS • OVER-TORQUING DAMAGE:

  28. MOTOR OPERATOR REPAIR PROCESS • GEAR & DRIVETRAIN WEAR:

  29. MOTOR OPERATOR REPAIR PROCESS • Putting It All Back Together:

  30. BUT REMEMBER … IT’S NOT JUST THE MOTOR OPERATOR !!

  31. Cleveland Valve & Hughes Primeau Control Valve Repair

  32. LINE VALVE REPAIR …Gate ValvesGlobe ValvesBall ValvesCheck ValvesAll Makes – All Models
