Presentation Transcript


  1. SANYOVCC-HD4600P

  2. Camera: Sanyo VCC-HD4600P Illuminator: RM200-PLT-AI-10 (PLATINUM)Distance: 70m IR OFF IR ON Notes: 10 x zoom

  3. Camera: Sanyo VCC-HD4600P Illuminator: RM200-PLT-AI-10 (PLATINUM)Distance: 90m to subject, 300 m to tree line IR ON IR ON Notes: 1 x zoom – shows the full scene 10 x zoom – shows illumination level on a subject at 90m

  4. Camera: Sanyo VCC-HD4600P Illuminator: RM300 Distance: 50m IR OFF IR ON Notes: 1.3 x zoom

  5. Camera: Sanyo VCC-HD4600P Illuminator: RM300 Distance: 50m IR ON IR ON Notes: 5 x zoom – shows facial features

  6. CAMERA SET-UP All test images were achieved with the camera in default settings. IR ON IR ON
