  1. Introducing Sound Waves RitchelDyan Z. Bagayas

  2. The Nature of Sound • Sound travels in waves as it moves through the air or some other medium (substance) • Waves are produced by a vibrating object. • As a vibrating object moves outward, it compresses the surrounding medium, producing a region of compression called a condensation. • As the vibrating object then moves inward, the medium expands into the space formerly occupied by the object. This region of expansion is called a rarefaction.

  3. Sound waves consist of these condensations and rarefactions. • Sound waves must travel through a medium. • Sound is called a longitudinal wave because the vibrations are in the same direction as the motion and speed of the wave. • It travels at a speed of 331 m/s in air at 0 oC. • The speed increases, at a rate of 0.6 m/s per Celsius degree. • If something moves faster than sound, it is said to be supersonic. If it travels at the speed of sound, it travels at Mach 1; three times the speed of the sound is called Mach 3.

  4. Acoustics is the science of sound and of its effects on people. • Condensation is a region of compression in a sound wave. • Frequency of sound waves refers to the number of condensation or rarefactions produced by a vibrating object each second. • Decibel is the unit used to measure the intensity level of a sound. A 3000-hertz tone of zero decibels is the weakest sound that the normal human can hear. • Hertz is the unit used to measure frequency. One hertz equals one cycle (vibration) per second. • *Other terms used in the study of sound can be found in page 451.

  5. The nature of a particular sound can be described in terms of • Frequency and Pitch • Intensity and loudness and • Quality

  6. Frequency and Pitch • Pitch is related to its frequency. Higher frequency means higher pitch. • Frequencies of sound waves humans can hear range from about 20-20,000 hertz or cycles per second. • The loudness of sound is related to the wave’s energy or intensity. • As the frequency of sound waves increases, the wavelength decreases. Wavelength is the distance between any point on one wave and the corresponding point on the next one.
