240-650 Principles of Pattern Recognition

1. 240-650 Principles of Pattern Recognition Montri Karnjanadecha montri@coe.psu.ac.th http://fivedots.coe.psu.ac.th/~montri 240-572: Appendix A: Mathematical Foundations

2. Appendix A Mathematical Foundations 240-572: Appendix A: Mathematical Foundations

3. Linear Algebra • Notation and Preliminaries • Inner Product • Outer Product • Derivatives of Matrices • Determinant and Trace • Matrix Inversion • Eigenvalues and Eigenvectors 240-572: Appendix A: Mathematical Foundations

4. Notation and Preliminaries • A d-dimensional column vector x and its transpose xt can be written as 240-572: Appendix A: Mathematical Foundations

5. Inner Product • The inner product of two vectors having the same dimensionality will be denoted as xty and yields a scalar: 240-572: Appendix A: Mathematical Foundations

6. Euclidian Norm (Length of vector) • We call a vector normalized if ||x|| = 1 • The angle between two vectors 240-572: Appendix A: Mathematical Foundations

7. Cauchy-Schwarz Inequality • If xty = 0 then the vectors are orthogonal • If ||xty|| = ||x||||y| then the vectors are colinear. 240-572: Appendix A: Mathematical Foundations

8. Linear Independence • A set of vectors {x1, x2, x3, …, xn} is linearly independent if no vector in the set can be written as a linear combination of any of the others. • A set of d L.I. vectors spans a d-dimensional vector space, i.e. any vector in that space can be written as a linear combination of such spanning vectors. 240-572: Appendix A: Mathematical Foundations

9. Outer Product • The outer product of 2 vectors yields a matrix 240-572: Appendix A: Mathematical Foundations

10. Determinant and Trace • Determinant of a matrix is a scalar • It reveals properties of the matrix • If columns are considered as vectors, and if these vector are not L.I. then the determinant vanishes. • Trace is the sum of the matrix’s diagonal elements 240-572: Appendix A: Mathematical Foundations

11. Eigenvectors and Eigenvalues • A very important class of linear equations is of the form • The solution vector x=ei and corresponding scalar are called the eigenvector and associated eigenvalue, respectively • Eigenvalues can be obtained by solving the characteristic equation: 240-572: Appendix A: Mathematical Foundations

12. Example • Let find eigenvalues and associated eigenvectors Characteristic Eqn: 240-572: Appendix A: Mathematical Foundations

13. Example (cont’d) Solution: Eigenvalues are: Each eigenvector can be found by substituting each eigenvalue into the equation then solving for x1 in term of x2 (or vice versa) 240-572: Appendix A: Mathematical Foundations

14. Example (cont’d) • The eigenvectors associated with both eigenvalues are: 240-572: Appendix A: Mathematical Foundations

15. Trace and Determinant • Trace = sum of eigenvalues • Determinant = product of eigenvalues 240-572: Appendix A: Mathematical Foundations

16. Probability Theory • Let x be a discrete RV that can assume any of the finite number of m of different values in the set X = {v1, v2, …, vm}. We denote pi the probability that x assumes the value vi : pi = Pr[x=vi], i = 1..m • pi must satisfy 2 conditions 240-572: Appendix A: Mathematical Foundations

17. Probability Mass Function • Sometimes it is more convenient to express the set of probabilities {p1, p2, …, pm} in terms of the probability mass functionP(x), which must satisfy the following conditions: For Discrete x 240-572: Appendix A: Mathematical Foundations

18. Expected Value • The expected value, mean or average of the random variable x is defined by • If f(x) is any function of x, the expected value of f is defined by 240-572: Appendix A: Mathematical Foundations

19. Second Moment and Variance • Second moment • Variance • Where is the standard deviation of x 240-572: Appendix A: Mathematical Foundations

20. Variance and Standard Deviation • Variance can be viewed as the moment of inertia of the probability mass function. The variance is never negative. • Standard deviation tells us how far values of x are likely to depart from the mean. 240-572: Appendix A: Mathematical Foundations

21. Pairs of Discrete Random Variables • Joint probability • Joint probability mass function • Marginal distributions 240-572: Appendix A: Mathematical Foundations

22. Statistical Independence • Variables x and y are said to be statistically independent if and only if • Knowing the value of x did not give any knowledge about the possible values of y 240-572: Appendix A: Mathematical Foundations

23. Expected Values of Functions of Two Variables • The expected value of a function f(x,y) of two random variables x and y is defined by 240-572: Appendix A: Mathematical Foundations

24. Means and Variances 240-572: Appendix A: Mathematical Foundations

25. Covariance • Using vector notation, the notations of mean and covariance become 240-572: Appendix A: Mathematical Foundations

26. Uncorrelated • The covariance is one measure of the degree of statistical dependence between x and y. • If x and y are statistically independent then and The variables x and y are said to be uncorrelated 240-572: Appendix A: Mathematical Foundations

27. Conditional Probability • conditional probability of x given y • In terms of mass functions 240-572: Appendix A: Mathematical Foundations

28. The Law of Total Probability • If an event A can occur in m different ways, A1, A2, …, Am, and if these m subevents are mutually exclusive then the probability of A occurring is the sum of the probabilities of the subevents Ai. 240-572: Appendix A: Mathematical Foundations

29. Bayes Rule • Likelihood = P(y|x) • Prior probability = P(x) • Posterior distribution P(x|y) X = cause Y = effect 240-572: Appendix A: Mathematical Foundations

30. Normal Distributions 240-572: Appendix A: Mathematical Foundations
