  1. The STEP to HECSALV Interface David JaramilloMARVIN Project Meeting - Patras/Greece17th - 19th January 2000

  2. Overview of HECSALV (1) • Integrated system of programs designed for rapid salvage response • The salvage features include: • Analysis of free-floating & stranded conditions. • Stability & Strength analysis. • Oil outflow prediction based on hydrostatic balance. • Evaluation of ballast and cargo movements as well as of tidal effects. STEP to HecSalv Interface

  3. Overview of HECSALV (2) • Standard naval architectural data entry and calculations: • Hull offset entry • Hydrostatics, bonjeans and cross curve calculations • Compartment definition • Intact, trim and stability calculations • Shear force and bending moment calculations STEP to HecSalv Interface

  4. Overview of HECSALV (3) • The system consist of 14 separate modules • The integration of the different modules is achieved through data exchange in form of files • Data flow for salvage analysis STEP to HecSalv Interface

  5. Structure of Load Case file • LC files are used to describe a “load case”, i.e. a loading condition of the analysed vessel. • They are ASCII formatted (human readable). • Structured in sections, keywords & values. • There is no official documentation of the format. • Becoming obsolete: all HECSALV input formats replaced by XML in upcoming new version. STEP to HecSalv Interface

  6. Scope and objectives of the Interface Prototype Development • Scope: • Data exchange between Ship Crew and ER-Company MEIT STEP  HECSALV • Only one direction covered by the prototype. • Objectives: • Achieve deliverable T2.2D1 (prototype interface modules). • Evaluate the MARVIN concepts for data exchange (STEP). • Validate the data models and identify problems and inconsistencies. STEP to HecSalv Interface

  7. Functionality of the Interface Prototype • Simple command line application which can be started providing one or two arguments. • Read a part 21 file containing instances of the Emergency Response Data model (this file is produced by the MEIT-STEP interface). • Write a HECSALV load case file (LC file) to be used for salvage calculations. STEP to HecSalv Interface

  8. Implementation steps (1) • Collect all required Building Blocks from the EMSA server (ship product model). • Generate Short Form (SF) of Emergency Response Data model (by hand). • Parse the SF and all other referenced EXPRESS schemas, correct errors. • Compile the SF schema, correct errors. STEP to HecSalv Interface

  9. Implementation steps (2) • Generate Long Form (LF) of the model. • Parse LF, correct errors. • Compile LF, correct errors. • Create a CDA (Central Data Administration) repository and populate it with sample data (instances) using SDAI facilities of the STEP tool. STEP to HecSalv Interface

  10. Implementation steps (3) • Generate Instance File (Part 21 Interface) • Create C++ Code (Part 23 Interface) • Implement interface application (coding) • Test application with sample part 21 file Tools used: • ProSTEP Developer Tools V5.0 • MS-Visual C++ V6.0 STEP to HecSalv Interface

  11. Future work • Incorporate feedback resulting from prototype evaluation (Task 4.1) and from further model improvements (Task 1.2) • Update interface to support XML-formatted input files of the upcoming HECSALV for Windows. • Implement transfer of recommendations and results to the MEIT. STEP to HecSalv Interface
