Presentation Transcript
Elizabeth a krupinski phd arizona telemedicine program l.jpg

Elizabeth A. Krupinski, PhD

Arizona Telemedicine Program


Slide2 l.jpg

Ovitt, et al.Intravenous angiography using digital video subtraction: x-ray imaging system.AJR 135(6):1141-4, 1980.

An x-ray imaging system, using digital subtraction techniques, has been developed. The system requires: (1) high output generation equipment; (2) an image intensifier capable of receiving high output exposures, 1 mR (2.58 X 10(-7) C/kg) at the face of the intensifier, without loss of either contrast or resolution; (3) a precision digital video camera; (4) processing computer with sufficient storage capacity; and (5) digital image storage. With this system it is possible to visualize the major arteries after intravenous contrast injection.


Slide3 l.jpg

Capp et al.

The digital radiology department of the future.

Rad Clin N Am 23(2):349-55, 1985.

The boom in microelectronics, including cost-effectiveness, has

now allowed us to consider the use of these objects to store

digital images. There remains much research, development,

And clinical evaluation to be done in receptor technology.

Further improvements in image processing, optical laser disk

storage, & optical transmission and further commercial

Development of display technology must take place. All of

These developments are occurring simultaneously. Within 5 to

10 years, radiology departments will most likely be totally

electronic, probably cost-effective, and, it is hoped, more

diagnostically accurate.


Slide5 l.jpg

  • Oldest established TM application

  • Well integrated in numerous settings

  • Facilitated by co-evolution PACS

  • Few to no reimbursement issues

  • Only interventional radiology currently less amenable to teleradiology applications

  • Little/no differences between teleradiology & on-site radiology


Slide6 l.jpg

  • ACR-NEMA development DICOM

  • Continual updates of DICOM

  • Development of standards & practice guidelines that explicitly include teleradiology

  • http://medical.nema.org/

  • http://deckard.duhs.duke.edu/~samei/tg18.htm





Slide10 l.jpg

  • Key is the human-computer interface

  • Series of observer performance studies designed to optimize the digital reading room environment

  • Performance metrics

    • Diagnostic accuracy (ROC)

    • Search efficiency (eye position)

  • Human Visual System Modeling


Slide12 l.jpg

  • Softcopy display parameters

    • Luminance

    • Calibration (tone scale)

    • Type of phosphor

    • CRT vs LCD

    • MTF

    • Viewing angle

    • Number of displays

    • Ambient lighting

    • Compression

    • Role of color

P45

P104


Slide13 l.jpg

Spatial & contrast resolution limitations require radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze.


Slide14 l.jpg

  • Total viewing time shorter radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • Time to first hit shorter

  • Total time on lesion shorter

  • Fewer returns to lesion

  • Total path length shorter

  • Overall = more EFFICIENT


Slide15 l.jpg

Task radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze


Slide16 l.jpg

Experience radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze


Slide17 l.jpg

Med Student radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

Resident

Pathologist


Slide18 l.jpg

Display & Interface radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

20% fixations fell outside diagnostic image


Slide19 l.jpg

  • Hospital/MC radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • Clinics

  • Mobile van

    • Mammo

  • Dedicated

    • PET clinic

    • THH

    • UASA

  • Public Health

  • Battlefield

  • Hand-held


Slide23 l.jpg

  • Medical Imaging Consultants -> ? radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

    • Data acquisition & archiving

  • RadWorks (GE) -> Siemens/Fuji

    • Viewing station

  • 35% of department’s reading volume

  • 25% department’s income

    • Reading only & reading + archiving

    • $/case & $/set volume


Slide24 l.jpg

  • 68% sites using AHSC hub for TM services use TR service radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • TR typically 1st service requested

    • 79% of sites with TR use only TR

    • 21% started with TR & added services

  • TR specialty with most volume


Slide25 l.jpg

  • Time from mammography to consult with oncologist ~ 28 days radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

    • Screening mammography

    • Diagnostic mammography

    • Biopsy

    • Pathology processing & report

    • Oncology consultation

  • THIS IS TOO LONG!


Slide26 l.jpg

Even Worse in Rural radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze


Slide27 l.jpg

  • DS3 (45 Mbps) backbone radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

    • ATM protocol

  • T1 (1.5 Mbps) links

  • 65 direct link sites

  • ~ 85 with affiliated

    • NARBHA

    • DOC

    • IHS

  • RT & SF applications

  • ~ 55 sub-specialties

  • Teleradiology core app.


Slide28 l.jpg

  • Started in 2001 to rural sites radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • 7/28 telerad sites send mammo

  • Mostly use GE system

  • Directly to TBC for reading

  • Some archive some do not

  • Contracts specify 30-45 min TAT

  • > 26,000 telemammography


Slide29 l.jpg

UltraClinic Model radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze


Slide30 l.jpg

Quick Processing radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

Milestone Medical Systems RHS-1-30

Vacuum Histoprocessor


Slide31 l.jpg

Telepathology radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

DMetrixTM -40 Slide Scanner System


Slide34 l.jpg

  • Telepathology report sent S&F to oncologist radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • Oncologist connects RT videoconference to rural location

  • Discuss pathology results

  • If necessary discuss treatment options and plan of action


The future of tr pacs l.jpg
The Future of TR & PACS radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • MI = prevention, detection, diagnosis, treatment & therapy

  • Acquisition & display technology continually changes

  • Clinician shortages are not easing

  • Rapidly expanding types & number images

    • Multi-modality & fusion complimentary information sources is becoming common

    • Anatomy & function gross & molecular levels

    • Merging specialties


Slide39 l.jpg

( radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gazeQuon et al. J ClinOncol; 2005; 23:1664-1673)


Slide40 l.jpg

Clarke et al. Validation if Tumor Burden Measurements radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

Using 3D Histopathology. In: Digital Mammography 2008.

Springer-Verlag.


The future of tr pacs41 l.jpg
The Future of TR & PACS radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • Image Display, Analysis & Processing are key links in the imaging chain

  • Need to present data to the clinician in the most efficient & informative manner

  • Taking into account perceptual & cognitive capabilities of human observer

  • Ultimate goal = facilitate decision-making process & enhance patient care

  • Related goal = improve workflow & the reading environment


Slide42 l.jpg

  • Stereo vs Traditional radiologists to search images. The UVF is about 2.5 deg radius. Probability of target detection falls off as a function of target eccentricity from axis of gaze

  • Az 0.85 to 0.94

  • 23% increase TPs

  • 105% increase calcs

  • 46% decrease FPs

Getty et al. Stereoscopic Digital Mammography:

Improved Accuracy of Lesion Detection in Breast Cancer Screening.

In: Digital Mammography 2008. Springer-Verlag.


Slide46 l.jpg

  • 50 DR chest images (PA) : 1/2 solitary pulmonary nodule verified CT; 1/2 nodule free

  • 6 radiologists (3 sr residents, 3 board-certified)

  • 3MP Barco color medical-grade display (BarcoCoronis MDCC-3120-DL) vs COTS color 2MP monitor (Dell 2405)

  • Calibrated (DICOM GSDF ) to luminance corresponding to backlight aging 1-year time

    • Max Barco 500 cd/m2 min 0.77 cd/m2

    • Max Dell COTS 342 cd/m2 min 0.376 cd/m2


Color vs color l.jpg
Color vs Color verified CT; 1/2 nodule free

F = 4.1496, p = 0.0471

Sensitivity = 0.91 vs 0.86

Specificity = 0.93 vs 0.92


Color vs color48 l.jpg
Color vs Color verified CT; 1/2 nodule free

F = 3.38, p = 0.067


Color vs color49 l.jpg
Color vs Color verified CT; 1/2 nodule free

No significant differences

TN significantly different


Slide51 l.jpg

  • Carpal tunnel syndrome verified CT; 1/2 nodule free

  • Elbow & shoulder (cubital tunnel)

  • Neck, back & shoulder strains

  • Computer vision syndrome

    • Eye strain

    • Dry eyes

    • Glaucoma

    • Headaches

    • Corneal erosion and abrasions

    • Contact lens problems


Slide52 l.jpg

Reader Fatigue verified CT; 1/2 nodule free

BLURRED VISION


Slide56 l.jpg

  • TR has made a significant impact on patient care over the past 20 years

  • Advances in technology will further change MI & interpretation of medical data by more clinicians

  • Costs can increase & decrease

  • Optimizing observer accuracy while maintaining efficiency & comfort are critical to continued success


Slide57 l.jpg

THANK YOU! past 20 years
