  1. Comdial DX 80

  2. Modular design incremental modules scalable customizable Installation adaptable MDF/no MDF Voice Processing Multiple solutions DX-80 : Configuration

  3. APM4 CPM MDM 408M DX-80 Standard Configuration • 4x8x4 • CID on all CO Lines • 2 Music Source Inputs • 1 External Page Port Interface • 1 Control Contact (Door/LBC/Ext. Page) • 2 RS-232C ports (PC-DBA & SMDR) • PC-DBA On site • (Optional remote PC-DBA programming via MDM 7249)

  4. Internal Module 4 Channels No “Port” loss! 3 Greetings Day Evening Temporary 7 other announcements Required for basic DISA operation APM4 CPM AAM 408M DX-80 Configuration VP : AAM

  5. APM4 CPM FL-4 408M DX-80 Configuration VP : FL-4 • Internal Module • 4 Channels • No “Port” loss! • 100 Mailboxes • 1.5 Hours storage • FL3HR - three hour expansion for a total of 4.5 hours storage

  6. APM4 CPM PC-8 408M DX-80 Configuration VP : PC-8 • Internal Module • 8 Channels • No “Port” loss! • 100 Mailboxes • 130 Hours storage • KVT Small Office Platform • UCD queue announcements

  7. APM4 APM4 COM4 CPM VP CPM VP 408M Digital 408M CO Lines DX-80 Configuration : CO Lines • Modules: • 408M (part of KSU1 PN7201) • 408E (part of KSU2 PN7202) • COM4 (PN7210) • 4 Loop Start CO Line ports • Caller ID standard all ports† • CNG Fax Tone Detect on fourth port • 1 PFT (1st CO port) † Caller ID requires a subscription from the local Telephone Company

  8. APM4 COM4 APM4 APM4 DPM8 DPM8 CPM VP Digital 408M CO Lines DX-80 Configuration : Digital Ports • Modules: • 408M (part of KSU1 PN7201) • 408E (part of KSU2 PN7202) • DPM8 (PN7220) • 8 three-channel ports • DET (48 maximum) • DSS (12 maximum)

  9. COM4 APM4 DPM8 DPM8 APM4 APM4 CPM VP Digital 408M CO Lines DX-80 Configuration : Analog Ports • Module: • APM4 (PN7230)(first standard as part of KSU1 PN7201) • 4 IST ports • Caller ID supported • Internal call enhanced displays

  10. Slot 4 Slot 3 Slot 2 Slot 2 Slot 3 Slot 5 DPM8 APM4 COM4 DPM8 APM4 COM4 APM4 Slot 4 DPM8 APM4 DPM8 COM4 DPM8 APM4 APM4 APM4 DPM8 Slot 5 VP CPM 408 E Slot 1 408 E 408 M Slot 1 408 M Cabinet 2, Slot 1 : Cabinet 1, Slot 1 : Digital Ports CO Lines Analog Ports Cabinet 1&2, Slot 5 : Cabinet 1&2, Slot 4 : Cabinet 1&2, Slot 3 : or Cabinet 1&2, Slot 2 : or 16 48 8 4 or 8 Ports AAM/FL-4/PC-8 16 32 16 DX-80 Configuration : Capacities Cabinet 1 Cabinet 2

  11. Comdial’s DX 80 • Built-In Analog Extensions: Basic System Equipped with 4 CO Lines, 8 Digital Extensions and 4 Analog Extensions • Built-In Caller ID: Name/Number Standard • (to all extensions: Caller ID Everywhere) • Built-In KVT Small Office voice mail • 8 channel capable • Installs Directly inside the DX System (no port loss) • Live Call Recording and Screening • Automated Attendant • Caller ID Integration

  12. Scalability Each System Starts with: 4 CO lines 8 Digital Key Extensions 4 Analog Ports n n n Modular expansion 16 CO Lines and 48 Digital Extensions and 8 IST ports n n n Every Telephone is a 40 Button LCD Speakerphone

  13. Add-on Expansion Modules: • CID Ready Telephone Line Ports • Digital Extension Ports • Analog Device Ports DX Voice Module Expansion KSU 40 button LCD speakerphone ) Auto Attendant Module Modem for remote phone system programming via PC-DBA 2.4 GHz Wireless Digital Speakerphone (future) SMDR interface for call accounting PC System Programming (PC/DBA) External ringer/ gate control Analog extension ports for PC modems, corded/cordless single line telephones, and fax machines. The DX can even detect when a fax is being received. External Paging equipment interface 2 music/message-on-hold sources programmable by line Digital eXchange

  14. Standard Feature Interactive 2 x 16 LCD Display with Name/Number Caller ID Standard Busy Off-Hook Voice Announce with Hands Free Answer Back 30 Programmable Dual Color LED Buttons for direct access to CO Lines, Extensions, Speed Dialing, and other features One Touch manual or automatic record of conversations to Voice Mail Call Forward: route internal/external calls differently Memo Pad stores one time speed dial number while on a call 2.5mm Headset Jack DX LCD Display Speakerphone Every DX telephone is a 40-button speakerphone with a two line interactive LCD Display. We've even added a headset jack to every DX telephone! Adjustable 3 Position Telephone Elevation Stand Dual Color Status Light indicates active headset, mute, DND and other call modes Music: two separate music channels Call Park: personal, group and guest

  15. DX-80 Features : Call Processing • Transfer & Answer (F68) • Holding Call Answer - Select • Release Key (F52)

  16. DX-80 Features : Operational • Night Service (F63) • Memo Pad (F5*) • Caller ID Table (100) (F6#) • Alarm Clock (F9*)

  17. DX-80 Features : Operation cont. • Feature Code Lookup (F#5) • Headset Mode (F9#) • Voice Record (F67) • Phone Lock (F97)

  18. DX-80 Features : Applications 430~433 • UCD - 24 Groups • 2 Overflow • Three modes of operation • Account Codes (Verified) • Forced via COS • Flexible Numbering Plan • Speed Dial 911 • Meet Me Conference 79 0000~9999 390~397
