Lync deep dive dial plans and voice management deep dive

EXL318

Lync Deep Dive: Dial Plans and Voice Management Deep Dive

Javed Tufail / Korneel Bullens

Architect

Microsoft Corporation


Session objectives and takeaways

Session Objectives and Takeaways

  • Session Objective(s)

    • Describe voice routing with Microsoft Lync Server 2010

    • Describe the numbering plan & approach to voice routing design

    • Identify the appropriate best practices for voice routing within Microsoft Lync Server 2010


Agenda

Agenda

  • Introductions

  • Lync Voice Routing

  • Numbering and Dialing

  • Routing and Authorization

  • Special Considerations / Best Practices


Javed tufail

Javed Tufail

  • Javed Tufail

  • California, US

  • Have been working on voice and unified communications for past 13 years

  • MCS Voice Center of Excellence (CoE)


Vocabulary

Vocabulary

  • Outbound call: Call initiated by Lync user.

  • PSTN call: Any call to a phone that is not within Lync. This may include other internal PBX phones.

  • Internal call: Call between two phones within the same company. May be a call between Lync and PBX phone.

  • DID: Direct Inward Dial number. A PSTN phone number. (Also called DDI.)

  • RNL: Reverse Number Lookup

  • NANP: North America Numbering Plan


Concepts

Concepts

  • Dial Plans

    • Are meant to “codify” dialing habits into E164

    • Are assigned to people based on dialing habits not locations

  • Voice Policy

    • Contain Voice Usages

    • Limit or extend a users telephony featureset

  • PSTN Usages

    • Contain Voice Route(s)

  • Voice Routes

    • Route dialed numbers to the correct gateway(s)

    • Control which numbers a user is allowed to call


Lync voice routing

Lync Voice Routing


Voice routing

Voice Routing

User Initiates Call

User=phone

SIP URI

Call Park Orbit Range

Emer.Call?

Global?

Dial Plan

No

No

Normalization Rule

Normalization Rule

404: No matching rule

Yes

Normalization Rule

Yes

DialingBehaviors

Reverse Number Lookup

Routing &Authorization

Location Policy

No match

Match

PSTN Usage

1. Vacant Number Range

2. Call Park Orbit Range

3. Voice Policy

Routes

PSTN Usage

Route

Route

PSTN Usage

Route

PSTN Usage

Route

Mediation Server andTrunk Configuration

403: No route found

Announcement orCall Park Application

Gateway / IP-PBX / SIP Trunk

Inbound Routing

External Endpoint Receives Call

UC Endpoint Receives Call

8


Voice routing1

Voice Routing

User Initiates Call

Lync ClientNormalizes

User=phone

SIP URI

Call Park Orbit Range

Emer.Call?

Global?

Dial Plan

No

No

Must MatchA Rule

RFC 3966Starts with +

Normalization Rule

Normalization Rule

404: No matching rule

Yes

Normalization Rule

Yes

DialingBehaviors

msRTCSIP-LinemsRTCSIP-PrivateLine

Reverse Number Lookup

Routing &Authorization

Location Policy

No match

Match

PSTN Usage

1. Vacant Number Range

PSTN Fallback forCAC and NetworkOutages

2. Call Park Orbit Range

3. Voice Policy

Routes

PSTN Usage

Route

Policy Createsper User Routing

Route

PSTN Usage

Route

PSTN Usage

Route

Mediation Server andTrunk Configuration

Apply CalledParty Prefs

403: No route found

Announcement orCall Park Application

Convert #to Local Format

Gateway / IP-PBX / SIP Trunk

Inbound Routing

External Endpoint Receives Call

UC Endpoint Receives Call

9


Numbering and dialing

Numbering and Dialing


Rfc 3966 s impact to lync

RFC 3966’s Impact to Lync

  • Defines format of TEL URIs in SIP

  • Specifies that global numbers begin with ‘+’

  • Other numbers must be given a context

  • Example valid formats:

    • tel:+12065550121

    • tel:+12065550120;ext=121

    • tel:121;phone-context=HQ


Assigning phone numbers to users

Assigning Phone Numbers to Users

  • New DID range for pilot users

    • Not uncommon to find DID ranges set aside for future growth

    • If PBX handset remains, forward to new number

    • Migrate number blocks when replacing PBX – users keep DID

  • Specify Extension for All Users

    • Optimizes PIN authentication for devices and dial-in conferencing

    • Line URI = tel:+12065550121;ext=121

    • Reverse number lookup considers extension optional

    • May need to deal with “;ext=” in trunk normalization for cases of PSTN reroute


Internal only numbers users without did ddi

Internal-Only NumbersUsers without DID/DDI

  • As per RFC, line URI should be of the form:

    tel:+14258828080;ext=51855

  • Base number could point to Exchange Auto Attendant with number:

    tel:+14258828080;ext=1

  • Normalization of inbound number should add “;ext=1” so that unique number of AA can be found via RNL.

    ^(\+14258828080)$ → $1;ext=1


Phone number fragments

Phone Number “Fragments”

  • User input

    • Dial pad

    • Outlook contacts

      Requires dial plan per “habit group”

  • Exchange out-calling

    • Play on Phone

    • Personal Contacts

    • Directory (Subscriber Access or Auto Attendant)

      Requires normalization by Lync Server 2010 dial plan

  • 14


    Phone number fragments contd

    Phone Number “Fragments” Contd.

    • Active Directory

      • Address Book

        Requires address book normalization rules

  • Gateway or PBX

    • Inbound to Mediation server

      Requires normalization by Lync Server 2010 dial plan

  • Remote Call Control

    • Inbound call via CSTA

      Requires address book normalization rules

  • 15


    Dial plans

    Dial Plans

    • Known as the location profile in OCS 2007 R2

    • A set of normalization rules that translate dial strings to full, unique numbers

    • Normalization rules are specified using regular expressions

    16


    Example normalization patterns

    Example Normalization Patterns

    • National dialing

      ^([2-9]\d\d[2-9]\d{6})$ → +1$1 (NANP)

      ^0(\d{10}) → +44$1 (UK)

    • Include national and international dialing prefixes

      ^011(\d*) → +$1

    • Extension range (e.g. 15xx-35xx)

      ^((1[5-9]|2[0-9]|3[0-5])\d{2})$ → +1206555$1

    • Avoid expressions that make the first digit optional, like this:

      ^9?([2-9]\d\d[2-9]\d{6})$


    Off hook dialing

    “Off-hook” Dialing

    • In Lync, user typically dials all desired digits then presses “call”

    • Normalization rules are then processed in order to find a match.

    • When dialing from a device “off-hook,” an inter-digit dialing delay is used to determine when to place the call

      • 1.5 second inter-digit dialing delay

        If a matching rule is found, the number will be dialed

      • 10 second final time-out

        If no matching rule is found, the dialstring is sent to the FE

      • Excluding patterns from the device is not supported


    External access prefix

    External Access Prefix

    • A prefix can be specified that signals an external number is being dialed

    • This prefix will not need to be in the normalization rules

    • Internal Extension check box in the normalization rule works with the External Access Prefix to make the below client logic work

    • If number dialed begins with the prefix, then:

      • Client removes the prefix. Attempts to find match among the normalization rules that are for external numbers (not marked as internal)

      • If no match, client keeps the prefix. Attempts to match all the normalization rules that are for internal numbers

      • If no match, client keeps the prefix. Attempts to match all the normalization rules that are for external numbers


    Address book normalization

    Address Book Normalization

    • Remember to configure this in Lync!

    • Place Company_Phone_Number_Normalization_Rules.txt files in \\server\CSShare\Site-WebServices-N\ABFiles

    • ABServer.exe -TestPhoneNorm“…”

    • Now, spaces & some punctuation are stripped before rules are applied

      • This makes the address book rules read more like the dial plan normalization rules

    20


    Routing and authorization

    Routing and Authorization


    Routing why bother

    Routing: Why bother?

    PSTN

    • Essentially, routing of VoIP calls is making the choice between using WAN resources or using the PSTN

    • If all PSTN calls were free, we would simply route to the closest PSTN gateway.

    • Cost is the driving factor for routing.

    WAN


    Routing and authorization1

    Routing and Authorization

    Voice Policies

    PSTN Usages

    Routes

    • User authorization

    • Class of service

    • Voice feature set

    • Called number

    • Cost of call

    • Purpose (usage, caller’s intent)

    • Calling location

    • Priority

    23


    Observations from the field

    Observations from the Field

    • Phone Number in Lync -> +912125550100

      • 9 – often a Trunk Access Code

      • +91 is India, so +912125550100 is routed to India

    • Private Extensions -> +6046

      • +60 is Malaysia, so +6046 is routed to Malaysia

    • Missing Country Codes -> +2125550100

      • +212 is Morocco, so +2125550100 is routed to Morocco

    • Solution:

      • Full E.164 number (globally unique)

      • Add ;ext= for the user extension (and conference PIN support)


    Dial plan design approach

    Dial Plan Design Approach

    • Start with routes

    • Define user voice policies (classes of service)

      • Incorporate requirements for least-cost routing and PSTN rerouting and fallback

    • Use PSTN Usages to “link” appropriate routes to the needed voice policies


    Route planning munich

    Route Planning - Munich

    International

    National Premium

    National

    Local

    Internal


    Route planning seattle

    Route Planning - Seattle

    International

    National Premium

    National

    Local

    Internal


    Dialing rule optimizer

    Dialing Rule Optimizer

    http://www.lyncoptimizer.com/


    Route planning details

    Route Planning Details

    • Routes are also regular expressions that match normalized number to select a gateway

    • Route for internal numbers

      • Internal to company: Both within Lync and on PBX

      • Useful for “Internal” class of service

      • Also used for PSTN routing of internal calls for Call Admission Control (CAC) or network failure

    • Routes specific to gateway locations

      • Include multiple gateways in route if in same location

      • Otherwise, we’ll use PSTN usage to group and order them


    Voice policy entitlements and class of service

    Voice PolicyEntitlements and Class of Service

    • A user’s capabilities are determined by the policies granted to the user


    Voice policy scope

    Voice Policy Scope

    • The most specific policy available will be applied

    • User policy will be assigned or it will be set to <Automatic> to allow selection from Pool, Site, or Global policies

    • Not every level is available for every type of policy

    31


    Voice policy entitlements

    Voice Policy Entitlements

    • Provide admins with flexibility to control user voice entitlements

      • Call Forwarding

      • Delegation

      • Call Transfer

      • Call Park

      • Simultaneous Ringing

      • Team Call

      • PSTN Rerouting

      • BW Policy Override

      • Malicious Call Tracing

  • Useful to address Common Area Device requirements

  • 32


    Pstn usages

    PSTN Usages

    Example uses:

    • Combine all free call routes into one usage

    • Combine all internal call routes into one usage

    • Provide backup routes for internal calls based on caller location

    • Establish priority of routes based on caller’s primary geographic location (not current location) to areas not served by a local gateway


    Special considerations best practices

    Special Considerations / Best Practices


    Trunk normalization rules

    Trunk Normalization Rules

    • Leverage trunk configuration normalization rules to minimize required PBX changes

    • Centrally manage number formatting prior to routing to PBX/PSTN

    • Example use: call to +442212345678

      • Formatted as 011442212345678 when using Seattle gateway (011 is international dialing prefix in Seattle)

      • Formatted as 02212345678 when using London gateway (0 is national dialing prefix / trunk code in London)

    35


    Emergency call considerations

    Emergency Call Considerations

    • Location Policy specifies dialstring that represents an emergency services call

    • A single PSTN Usage (also specified in the Location Policy) is used to find appropriate route

      • For E9-1-1 scenarios, this will route the calls to the E9-1-1 services provider SIP trunk

    • PSTN fallback for emergency services calls requires alternate routes for the emergency services number (e.g. “^\+911$”) in the user’s voice policy


    Number blocking traditional supported method

    Number BlockingTraditional (supported) Method

    • Exclude number ranges from routes

      • Default “National” route would exclude range but “National Premium” route would allow.

    • Must exclude range from any route that could provide coverage of the premium number

    • Can become difficult to manage

    • Allows flexibility in application to groups of users


    Number blocking alternative method

    Number BlockingAlternative Method

    • Create “unassigned number” range that matches desired blocked number range

    • Blocks all outbound calls to those numbers and can play an admin-specified message

    • Blocks all calls to those numbers without regard to caller


    Best practices trunk configurations

    Best PracticesTrunk Configurations

    • Removing the “+”

      • Set-CsTrunkConfiguration <identity> –RemovePlusFromUri $true

    • PSTN re-routing (CAC/WAN Outage)

      • Pattern to Match: ^(\+\d*);ext=(\d*)$

      • Translation Pattern: $1


    Best practices numbering

    Best PracticesNumbering

    • Configure Users with DIDs and Extensions

      • +19495551000;ext=1000

    • Do not include an outside line access code as part of the normalized phone number

    • Do not treat private extensions as global numbers

    • Always include the country code


    Best practices dial plan

    Best PracticesDial Plan

    • Normalization Optimization

    • How Many

      • 700 Dial Plans per deployment (stress tested 750 with 10 rules)

      • 100+ Normalization Rules per Dial Plan in CU5

    • Test and Validate


    In review session objectives and takeaways

    In Review: Session Objectives and Takeaways

    • Session Objective(s):

      • Discuss the components of Lync Voice Routing

      • Identify the data necessary for successful dial plan creation

      • Best Practices for voice routing within Microsoft Lync Server 2010


    Related content

    Related Content

    EXL315 - Microsoft Lync 2010: Planning for Conferencing Deployments

    EXL316 - Microsoft Lync 2010: Availability, Resiliency, and Recovery

    EXL317 - Lync and the Enterprise Network

    EXL319 - Lync 2010: Planning Voice Features

    EXL412 - Lync Deep Dive: Edge Media Connectivity with ICE

    • MicorosftLync Server 2010, Configuring (070-664)

    • Microsoft Lync Server 2010, Administrator (070-665)

    • Find Me Later At The Learning Center


    Track resources

    Track Resources

    • Lync Team Blog: http://blogs.technet.com/b/uc/

    • Lync Facebook: http://www.facebook.com/MicrosoftOfficeCommunicator

    • Lync Server Blog: http://blogs.technet.com/b/nexthop/

    • Lync Website: http://lync.microsoft.com/en-us/Pages/unified-communications.aspx


    Resources

    Resources

    Learning

    TechNet

    • Connect. Share. Discuss.

    • Microsoft Certification & Training Resources

    http://northamerica.msteched.com

    www.microsoft.com/learning

    • Resources for IT Professionals

    • Resources for Developers

    http://microsoft.com/technet

    http://microsoft.com/msdn


    Lync deep dive dial plans and voice management deep dive

    Required Slide

    Complete an evaluation on CommNet and enter to win!


    Ms tag

    MS Tag

    Scan the Tag

    to evaluate this

    session now on

    myTechEd Mobile


    Lync deep dive dial plans and voice management deep dive

    © 2012 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries.

    The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.


  • Login
