Presentation Transcript


May 2006

QCT WorldMode Chipset Solutions

Mark Jerger

May 2006


May 2006

7600DOrA/R6

QSC60551xDB

61501x

6550DOr0

60501x

60251x

6500DOr0

61001x

63001x/GSM

60001x

CDMA2000® MSM Roadmap

Pin, SW API, and RF Compatible

7500DOrA

6800DOrA

61251X

Single- Chip 1X(2nd Gen)

QSC60651xDB

QSC6030

QSC6020

QSC60101XSB


Worldmode chipset solutions enabling mobile users to roam across cdma networks and gsm networks

WorldMode Chipset SolutionsEnabling mobile users to roam across CDMA networks and GSM networks

  • MSM7600, MSM6550, MSM6500, MSM6300, MSM6125 support CDMA networks and GSM 850/900/1800 and 1900 MHz bands.

  • Mobile subscribers can always be connected with the ability to roam across multiple CDMA and GSM/GPRS networks maintaining voice and data capabilities

  • Worldmode solutions make it possible for mobile users to carry one device and access one contact list


Qualcomm is increasing global roaming capabilities

QUALCOMM is Increasing Global Roaming Capabilities


Aggregation of volumes will make worldmode economical

Aggregation of Volumes will Make WorldMode Economical

  • Current Worldmode capable 1X handsets are roughly $60-$100 more than an equivalent CDMA only device for volumes <100K units

  • A 10x increase in volumes will decrease NRE and other fixed cost amortization per handset by roughly 1/10

  • Competition, economies of scale and QC migration to multimode modems will reduce handset differential over time


Development process of a worldmode handset

Development Process of a WorldMode Handset

  • Step 1: Handset development

  • Highly dependant on:

  • Manufacturer expertise

  • Manufacturer risk taking

  • Manufacturer familiarity with new technology

  • Estimate: 1-12 months

  • (from chipset availability)

Step 2: Formal test

CDMA: CDG/CCF

GSM: GCF/PTCRB (US)

Requires coordination with infra vendors

Estimate 3-9 months

Step 3: Carrier acceptance test

Dependant on carrier requirements

Trend to rely on much of Step 2

Estimate 1-3 months


Thank you

Thank you!
