Presentation Transcript


Cache organization of pentium

Cache Organization of Pentium


Instruction data cache of pentium

Instruction & Data Cache of Pentium

  • Both caches are organized as 2-way set associative caches with 128 sets (total 256 entries)

  • There are 32 bytes in a line (8K/256)

  • An LRU algorithm is used to select victims in each cache.


Structure of 8kb instruction and data cache

Structure of 8KB instruction and data cache

  • Each entry in a set has its own tag.

  • Tags in the data cache are triple ported, used for

    • U pipeline

    • V pipeline

    • Bus snooping


Data cache of pentium

Data Cache of Pentium

  • Bus Snooping: It is used to maintain consistent data in a multiprocessor system where each processor has a separate cache

  • Each entry in data cache can be configured for writethrough or write-back


Instruction cache of pentium

Instruction Cache of Pentium

  • Instruction cache is write protected to prevent self-modifying code.

  • Tags in instruction cache are also triple ported

    • Two ports for split-line accesses

    • Third port for bus snooping


Split line access

Split-line Access

  • In Pentium (since CISC), instructions are of variable length(1-15bytes)

  • Multibyte instructions may staddle two sequential lines stored in code cache

  • Then it has to go for two sequential access which degrades performance.

  • Solution: Split line Access


Split line access1

Split-line Access


Split line access2

Split-line Access

  • It permits upper half of one line and lower half of next to be fetched from code cache in one clock cycle.

  • When split-line is read, the information is not correctly aligned.

  • The bytes need to be rotated so that prefetch queue receives instruction in proper order.


Instruction data cache of pentium1

Instruction & Data Cache of Pentium

  • Parity bits are used to maintain data integrity

  • Each tag and every byte in data cache has its own parity bit.

  • There is one parity bit for every 8 byte of data in instruction cache.


Translation lookaside buffers

Translation Lookaside Buffers

  • They translate virtual addresses to physical addresses

  • Data Cache:

    • Data cache contains two TLBs

  • First:

    • 4-way set associative with 64 entries

    • Translates addresses for 4KB pages of main memory


Translation lookaside buffers1

Translation Lookaside Buffers

  • First:

    • The lower 12 bits addresses are same

    • The upper 20-bits of virtual address are checked against four tags and translated into upper 20-bit physical address during a hit

    • Since translation need to be quick, TLB is kept small

  • Second:

    • 4 way set-associative with 8 entries

    • Used to handle 4MB pages


Translation lookaside buffers2

Translation Lookaside Buffers

  • Both TLBs are parity protected and dual ported.

  • Instruction Cache:

    • Uses a single 4-way set associative TLB with 32 entries

    • Both 4KB and 4MB are supported (4MB in 4KB chunks)

  • Parity bits are used on tags and data to maintain data integrity

  • Entries are placed in all 3 TLBs through the use of a 3-bit LRU counter stored in each set.


Cache coherency in multiprocessor system

Cache Coherency in Multiprocessor System

  • When multiple processors are used in a single system, there needs to be a mechanism whereby all processors agree on the contents of shared cache information.

  • For e.g., two or more processors may utilize data from the same memory location,X.

  • Each processor may change value of X, thus which value of X has to be considered?


Cache coherency in multiprocessor systems

Cache coherency in Multiprocessor Systems

  • If each processor change the value of the data item, we have different(incoherent) values of X’s data in each cache.

  • Solution : Cache Coherency Mechanism


A multiprocessor system with incoherent cache data

A multiprocessor system with incoherent cache data


Cache coherency

Cache Coherency

  • Pentium’s mechanism is called MESI (Modified/Exclusive/Shared/Invalid)Protocol.

  • This protocol uses two bits stored with each line of data to keep track of the state of cache line.


Cache coherency1

Cache Coherency

  • The four states are defined as follows:

  • Modified:

    • The current line has been modified and is only available in a single cache.

  • Exclusive:

    • The current line has not been modified and is only available in a single cache

    • Writing to this line changes its state to modified


Cache coherency2

Cache Coherency

  • Shared:

    • Copies of the current line may exist in more than one cache.

    • A write to this line causes a writethrough to main memory and may invalidate the copies in the other cache

  • Invalid:

    • The current line is empty

    • A read from this line will generate a miss

    • A write will cause a writethrough to main memory


Cache coherency3

Cache Coherency

  • Only the shared and invalid states are used in code cache.

  • MESI protocol requires Pentium to monitor all accesses to main memory in a multiprocessor system. This is called bus snooping.


Cache coherency4

Cache Coherency

  • Consider the above example.

  • If the Processor 3 writes its local copy of X(30) back to memory, the memory write cycle will be detected by the other 3 processors.

  • Each processor will then run an internal inquire cycle to determine whether its data cache contains address of X.

  • Processor 1 and 2 then updates their cache based on individual MESI states.


Cache coherency5

Cache Coherency

  • Inquire cycles examine the code cache as well (as code cache supports bus snooping)

  • Pentium’s address lines are used as inputs during an inquire cycle to accomplish bus snooping.
