Automatic generation of web based gis database applications

Automatic Generation of Web-Based GIS/Database Applications

Nirut Chalainanont

Junya Sano

Toshimi Minoura

Department of Computer Science

Oregon State University

Corvallis, Oregon, 97331-4602

[email protected]


Outline

Outline

  • Web-based GIS/database applications

  • WebGD Framework

  • Automatic generation of Web-form scripts

  • Automatic generation of map-layer configuration files

  • Conclusions


Capabilities of webgd applications

Capabilities of WebGD Applications

  • Geographical features can be inserted, queried, and deleted from a map interface.

  • A map interface and Web-form scripts can be automatically generated.

  • Dynamic switching of spatial references is supported.


Capabilities of webgd applications cont d

Capabilities of WebGD Applications (cont’d)

  • GIS data in an area selected by the user can be exported as a shapefile.

  • A treeview can be automatically created.

  • A PDF file containing the map image and data retrieved from the database can be created.

  • Photo images can be uploaded.


Natural heritage information system

Natural Heritage Information System


Searching in a selected area

Searching in a Selected Area


Getting information

Getting Information


Inserting a new motel

Inserting a New Motel


Treeview

Treeview


Pdf file generation

PDF File Generation


Uploading photo images

Uploading Photo Images


Webgd architecture

WebGD Architecture

PHP scripts create the map object and access the database.

Web Browser

Defines PHP classes for GIS objects.

PHP

Web Server

PHP/MapScript

Provides functions to manage geospatial data

MapServer

PostGIS

Generates map images.

PostgreSQLDatabase

Stores geospatial and business data.


Postgresql

PostgreSQL

  • The object-relational feature of PostgreSQL simplifies manipulation of geographical objects:

select gid

from sites

where geom_col &&

setSRID(BOX2D(10 20, 80 90)::box2d, 6010));

select X(geom_col), Y(geom_col)

from sites

where gid = 100;


Dynamic switching of spatial references

Dynamic Switching of Spatial References

  • World Longitude/Latitude

  • North America  Albers Equal Area

  • California UTM 10 and 11

  • Oregon  Lambert Conformal Conic


World in longitude latitude

World in Longitude/Latitude


North america in albers equal area

North America in Albers Equal Area


Continental united states in albers equal area

Continental United States in Albers Equal Area


Oregon in lambert conformal conic

Oregon in Lambert Conformal Conic


Corvallis in lambert conformal conic

Corvallis in Lambert Conformal Conic


Dynamic switching of spatial references1

Dynamic Switching of Spatial References

  • The world is divided into regions with sizes ranging from the entire world to a state/province in a country.

  • Each region has an associated rank number.

  • Each time a user changes the extent by zooming or panning, many regions may cover the new map extent. The region with the largest rank number, which is normally the smallest region that includes the extent, is selected


Selecting a region

Selecting a Region

Region 1 (rank 1)

Region 2 (rank 11)

Region 2 selected

Region 3(rank 12)

Region 3 selected

Region 1 selected


Webgd framework

WebGD Framework

  • A collection of scripts common to all WebGD applications

  • Customizable with configuration files

  • Sever-side scripts written in PHP

  • Client-side scripts written in JavaScript


Region configuration

Region Configuration

  • Map projection

  • Unit distance of measurement

  • Name of the map file for the region

  • Name of the map layer configuration file

  • Name of quick view configuration file


Region configuration1

Region Configuration


Map layer configuration

Map Layer Configuration

The following information is kept for each map legend entry:

  • Spatial reference ID

  • Geometry type

  • Icon and label for the layer

  • Database table associated with the layer

  • Actions associated with the layer


Map layer configuration1

Map Layer Configuration


Quick view configuration

Quick View Configuration

The quick view mechanism allows the user

to go to a predefined area directly:

  • Spatial reference for each area

  • Extent of each area

  • Name of each area


Quick view configuration1

Quick View Configuration


Weggd application generator

WegGD Application Generator

  • WebGD-Gen automatically generates a consistent set of Web scripts from configuration files, including those for a map interface.

  • Configuration files are again automatically generated from a relational database schema.

  • The cost of application development is greatly reduced.


Form script generation process

WebGen

TreeGen

Configuration

Configuration

File

File

Search

Search

Template

Script

Select

Select

Template

Script

Edit

Edit

Template

Script

Info

Info

Template

Script

Action

Action

Template

Script

TreeView

TreeView

Template

Script

Form Script Generation Process


Linked forms

Linked Forms

Department Select Form

Selected ID

Department Search Form

Student Edit Form

Department Edit Form

Course Select Form


Webgen configuration file

WebGen Configuration File

  • $search_fieldsfor the search script.

  • $search_fields, $select_fields and$search_join_tables for the select script

  • $edit_fields for the edit script

  • $info_blocks for information script


Search and select forms for table students

Search and Select Forms for Table students


Search fields

$search_fields

$search_fields=array(

array("column"=>"student_id",

"label"=>"Student ID",

"type"=>"numeric",

"maxlen"=>"40",

"size"=>"40"),

array("column"=>"first_name",

"label"=>"First Name",

"type"=>"text",

"maxlen"=>"40",

"size"=>"40"),

. . .

);


Search join tables

$search_join_tables

joined_tableindicates the associated table linked to the anchor table:

$search_join_tables = array(

"departments" => array(

"joined_table"=>

"departments ON departments.department_id = students.department_id",

"used"=>"false", "select"=>"true"),

);


Configuration parameters for a map interface

Configuration Parametersfor a Map Interface

  • WebGD-Gen can generate the statements for inserting, searching, and deleting geographical features from the following lines in a Web-script configuration file:

$web_gd = ‘MULTIPOLYGON’;

$layer_name = ’grp_eo_py’; $geometry_column = ‘the_geom’;

$gid_column = ‘gid’;

$db_table_srid = 32119;


Process of creating map layer configuration file for region xxx

Process of Creating Map-Layer Configuration File for Region xxx

Database

Map File

map_mconfgen

xxx_maplayer.mconfig

User Customization

Customized xxx_maplayer.mconfig

map_confgen

xxx_maplayer.config


Map layer meta configuration file

Map-Layer Meta Configuration File

  • The default map-layer meta configuration file is created by map_mconfgen from

    • table geometry_columns in the database and

    • the layer-group names in the map file

  • User can customize the meta configuration file.


Meta configuration file

Meta Configuration File

  • Default meta configuration file

  • User customized meta configuration file

'grp_eo_py' => array(

'layer_selectable' => true,

'legend_label' => 'Eo Py',

),

'grp_eo_py' => array(

'layer_selectable' => true,

'legend_label' => 'EO Polygons',

'search_script' => 'forms/eo/eo_py_search.phtml',

'select_script' => 'forms/eo/eo_py_select.phtml',

'edit_script' => 'forms/eo/eo_py_edit.phtml',

'img_src' => 'images/eo_poly.png',

),


Map layer configuration file

Map-Layer Configuration File

  • map_confgengenerates the map-layer configuration file by applying customized data in the meta configuration file to the meta data retrieved from

    • table geometry_columns in the database and

    • the layer-group names in the map file


Definition of a layer configuration

Definition of a Layer Configuration

'grp_eo_py' => array(

'geom_type' => ‘POLYGON',

'table' => 'eo_py',

'layer_selectable' => true,

'legend_label' => 'EO Polygons',

'geom_col' => 'the_geom',

'gid_column' => 'gid',

'normal_layer' => 'eo_py',

'img_width' => 26,

'img_height' => 26,

'img_src' => 'images/eo_poly.png',

'data_srid' => 32119,

'search_script' => 'forms/eo/eo_py_search.phtml',

'select_script' => 'forms/eo/eo_py_select.phtml',

'edit_script' => 'forms/eo/eo_py_edit.phtml',

'searched_layer' => 'eo_py_searched',

'checked_layer' => 'eo_py_checked',

'selected_layer' => 'eo_py_selected',

'onclick' => 'activate_layer("grp_eo_py")',

),


Conclusions

Conclusions

Web-based GIS/database applications have a great potential for user-participatory applications.

  • Users can add geographical features and associated data with Web browsers.

  • The major part of creating a WebGD application can be automated.

  • The whole world or the entire USA can be seamlessly covered.


Acknowledgement

Dileep Arur

Haris Gunadi

Surya Halim

Hong Gyu Han

Mariko Imaeda

Junya Sano

Akash Sharma

Hiroshi Tashiro

Naroot Wanalertlak

Paphun Wangmutitakul

Teerawat Wuttiwat

Acknowledgement
