  1. Product Presentation November 2010

  2. PMC-Sierra Overview • PMC-Sierra is the premier Internet infrastructure semiconductor solution provider • Major areas of product focus include: • COMMUNICATIONS: WAN Infrastructure (Wireline; Wireless), FTTH (EPON; GPON) • ENTERPRISE: Enterprise Storage (SAN & NAS Systems; x86 Servers), Printers & Networking • 2009 revenues $496M; 1st half 2010 revenue $313M; net cash $433M • Approximately 1,200 employees worldwide *(as of Mar 28, 2010)

  3. PMC’s Revenue Profile Rev = $249 million Rev = $496 million 2003 2009 Wireline Processor / SoC Enterprise Storage Access / FTTx Enterprise Storage continues to be a growth area for the company

  4. CSD – Channel Storage Division Bringing together the best of two worlds PMC 1st to market with 6Gb/s SAS RoC & expanders Adaptec leading provider of controllers to the channel

  5. Diversified Customer Base Key OEM Customers Key Channel Customers Key Datacenter Customers

  6. Current Shipping Products

  7. Adaptec Series 1 • Hardware • 4 SATA/SAS ports • Support for SAS 1.0 Features • x4 PCI-express Gen 1.1 • Enclosure Management support (SES2, SGPIO, LEDs for I/O Activity and Drive failure) • Features • 128 SAS address support • Tape, Tape Autoloaders, HDD & SSD support • Windows and open source Linux • Quick boot BIOS for Workstations (requires <10 seconds to boot)

  8. Adaptec Series 2 • Hardware • Utilizes Intel IOP348 3G 800 MHz RoC • Support for SAS 1.0 Features • x8 PCI-express Gen 1.1 • 128MB DDR2-533 DRAM • Features • Simple Volume, JBOD, RAID 0,1, 10, 1E • Hybrid RAID 1, 10 • 128 SAS address support • Tape, HDD and SSD support • IOPS – 37,000 • SSD caching ready

  9. Adaptec Series 5 • Hardware • Utilizes Intel IOP348 3G 1.2 GHz RoC • Support for SAS 1.0 Features • x8 PCI-express Gen 1.1 • 256 MB or 512MB DDR2-533 DRAM • Optional BBU (onboard or tethered) • Features • Simple Volume, JBOD, RAID 0,1, 10, 1ERAID 5, 6, 50, 60 • Hybrid RAID 1, 10 • 256 SAS address support • HDD and SSD support • IOPS – 55,000 • SSD caching ready

  10. Adaptec Series 5Z • Hardware • Utilizes Intel IOP348 3G 1.2GHz RoC • Support for SAS 1.0 Features • x8 PCI-express Gen 1.1 • 512MB DDR2-533 DRAM • Features • Flash memory & Supercap • Always available - no degradation • No maintenance or replacement cycle • Stored data accessible for years, not hours • No incremental disposal costs

  11. Caching Solutions

  12. High Performance Hybrid Array SATA or SAS drives Adaptec RAID Card SSD Target Workloads • Single Intel X25-E in SSD Cache • 12 Seagate 15K rpm SAS HDDs • SSD read capability is 100 times faster than HDD • Up to 8 time faster in real world applications Series 5 Series 5 with SSD Caching

  13. Enabling SSD Caching Solutions Option 1 Option 2 • Adaptec RAID card • Adaptec SSD drive - 32GB or 64GB • Up to 8 SSDs and/or 512GB of cache • Adaptec Series “Q” card • Standard SSD • Up to 8 SSDs and/or 2TB cache Off the shelf SSD (SLC or MLC) – see compatibility list for preferred drives Adaptec RAID cards 2405Q, 5805Q, 5805ZQ Adaptec 32GB or 64GB SSD Cache Module Adaptec RAID cards 2805, 2405, 20455405, 5445, 5805, 5085, 51245, 51645, 52445, 5805Z

  14. Adaptec SSD Cache Performance Kit • SSD caching performance solution kit • Intel X25-E SLC SSD 32GB or 64GB • Paired with any Series 5xxx or Series 2xxx card • Upgrade solution for controllers in the field • Performance • Up to 1.2GB/s throughput • Up to 55K IOPs • Read-intensive applications: Email, eCommerce, Web • Features • SSD Support / Read Caching • PCIe1.1 based • 3Gb/s SAS/SATA based • Usability • ASM Management +

  15. Adaptec Series Q • Hardware • Utilizes Intel IOP348 3G RoC • Support for SAS 1.0 Features • x8 PCI-express Gen 1.1 • 128 MB or 512MB DDR2-533 DRAM • Adaptec SSD Caching • Up to 2TB of SSD cache on 5805(Z)Q • Up to 80GB of SSD cache on 2405Q • Features • Simple Volume, JBOD, RAID 0,1, 10, 1ERAID 5, 6, 50, 60 • Hybrid RAID 1, 10 • Support for MLC/SLC SSDs for caching • Up to 55,000 IOPS

  16. Scheduled Software Releases August 2010 Q2’11 Released Shipping Qualification

  17. www.adaptec.com www.pmc-sierra.com
