  1. Product Presentation

  2. Product Range • Linear Flourescent Tube Lighting Fixtures • Flood Lighting Fixtures • Round Fixtures Series

  3. Linear Flourescent Lighting Tube Fixtures • T8B Series • T8D Series • T8F Series • T8F GRP Series • T5A Series • T5B Series

  4. Features Body 1. Injection moulded 2.Opaque UV PC body 3.Water proof gasket in natural silicon gel 4.With reinforcing ribs 5.Fix the reflector by “T” shape rotated supports with plastic hinging rope conneted the body for easy installation and maintenace 6. Closing clips in PC or stainless steel 7. Vandal proof,clips should be opened by tool,not by hand Reflector 1. White-coated flat metal plate Diffuser 1.Injection moulded 2. transparent UV stablilized PC diffuser 3. Highly impact resistant 4. It features prismatic design with good anit-dazzling effect T8B SERIESSingle LampDouble Lamp

  5. Features Body 1. Injection moulded 2. Opaque UV PC body 3. Water proof gasket in natural silicon gel 4. Fix the reflector by “T” shape rotated supports with plastic hinging rope conneted the body for easy installation and maintenace 5. Closing clips in PC or stainless steel 6.Two clips at one side of the diffuser could suspend the cover once opened 7.The design of the end of the clips is easy for opening the diffuser by fingers only no need other tool Reflector 1. White-coated flat metal plate 2.Two ends 5 mm down for the appropriate position of the lamp once installed Diffuser 1. Injection moulded 2. transparent UV stablilized PC diffuser 3. Highly impact resistant 4.It features averaged 3mm width anti-dazzling prismatic line and stylish 5.Fine grained frosted front shape planes T8D SERIESSingle LampDouble Lamp

  6. Features Body 1.Injection moulded 2.Opaque UV PC body and rectangular shape 3. Water proof gasket in natural silicon gel 4.With reinforcing ribs 5.Fix the reflector by “U” shape supports with plastic hinging rope conneted the body for easy installation and maintenace 6.Closing clips in PC or stainless steel 7.Two clips at the end of the diffuser could suspend the cover once opened 8.The design of the end of the clips is easy for opening the diffuser by fingers only no need other tool Reflector 1.White-coated flat metal plate Diffuser 1.Injection moulded 2. transparent UV stablilized PC diffuser 3. Highly impact resistant 4.It features averaged 4mm width line and stylish 5.Fine grained frosted front shape planes T8F SERIESSingle LampDouble Lamp

  7. Features Body 1.Press moulded 2.Glass-fiber Reinforced Polyester body,non corrosive,rectanglar shape 3. Water proof gasket in natural silicon gel 4.Fix the reflector by “T” shape supports with plastic hinging rope conneted the body for easy installation and maintenace 5.Closing clips in PC or stainless steel 6.Two clips at both ends of the one side of the diffuser could suspend the cover once opened 7.The design of the end of the clips is easy for opening the diffuser by fingers only no need other tool Reflector 1.White-coated flat metal plate Diffuser 1.Injection moulded 2.transparent UV stablilized PC diffuser 3. Highly impact resistant 4. It features averaged 4mm width line and stylish 5.Fine grained frosted front shape planes T8F GRP SERIESSingle LampDouble Lamp

  8. Features Body 1.Press moulded 2.Opaque UV stabilized PC body 3.Water proof gasket in natural silicon gel 4.Fix the reflector by “T” shape supports with plastic hinging rope conneted the body for easy installation and maintenace 5.Closing clips in PC or stainless steel 6.The design of the end of the clips is easy for opening the diffuser by fingers only no need other tool Reflector 1.White-coated flat metal plat 2.Complex parabolic profile ensures optimization of lighting performance Diffuser 1.Injection moulded 2. transparent UV stablilized PC diffuser 3. Highly impact resistant 4.It features averaged 5mm width anti-dazzling prismatic line and stylish 5.Fine grained frosted front shape planes 6.The diffuser caould be suspended by the transparent plastic holder for easy installation and maintenance of the lamps T8G SERIESSingle LampDouble Lamp

  9. Features Body 1.Injection moulded 2.Opaque UV stabilized PC body 3.Water proof gasket in natural silicon gel 4.Fix the reflector by “T” shape supports with plastic hinging rope conneted the body for easy installation and maintenace 5.Closing clips in stainless steel with plastic cover at top for finger protection Reflector 1.White-coated flat metal plat Diffuser 1.Injection moulded 2.transparent UV stablilized PC diffuser 3.Highly impact resistant 4.It features prismatic design with good anti-glare effect T5A SERIESSingle LampDouble Lamp

  10. Features Body 1.Injection moulded 2.Opaque UV stabilized PC body 3.Water proof gasket in natural silicon gel 4.Fix the reflector by “T” shape supports with plastic hinging rope conneted the body for easy installation and maintenace 5.Closing clips in PC or stainless steel with optional locking screws for vandal proof function 6.Two clips at both ends of one side of the diffuser could suspend the cover once opened Reflector 1.White-coated flat metal plat Diffuser 2. Injection moulded 3. transparent UV stablilized PC diffuser 4.Highly impact resistant 5. It features crossing prismatic design with good anti-glare effect T5B SERIESSingle LampDouble Lamp

  11. Flood Lighting Fixtures

  12. Features Body 1.Injection moulded 2. Opaque UV stabilized PC body 3.Water proof gasket in natural silicon gel 4.Stainless steel clips only 5.Compared with the conventional aluminum die casing flood lamps,it is much less weight,much less cost and much energy saving and more convenience for installation 6.Two clips at one end could make the diffuser suspended once opened Reflector 1.Mirror aluminum reflector Diffuser 1.Injection moulded 2.Transparent UV stablilized PC diffuser 3.Highly impact resistant 4.The granule prismatic design hides the electrical compenents inside V5 Flood LightingSingle lamp Double Lamp

  13. Round Fixtures Series • Circular Fluorescent Tube • 2D Fluorescent Tube

  14. Features Body 1.Injection moulded 2.Round opaque UV stabilized PC body 3.Water proof gasket in natural silicon gel 4.Fix the reflector by “T” shape 5.Closing clips in PC or stainless steel with optional locking screws ofr vandal proff function Reflector 1.White-coated round shape flat metal plate Diffuser 1.Injection moulded 2.Round shape transparent UV stablilized PC diffuser 3. Highly impact resistant 4.It features prismatic design with good anti-glare effect Circular Fluorescent Tube

  15. Features Body 1.Injection moulded 2.Round opaque UV stabilized PC body 3.Water proof gasket in natural silicon gel 4.Fix the reflector by “T” shape 5.Closing clips in PC or stainless steel with optional locking screws ofr vandal proff function Reflector 1.White-coated round shape flat metal plate Diffuser 1. Injection moulded 2.Round shape transparent UV stablilized PC diffuser 3.Highly impact resistant 4.It features prismatic design with good anti-glare effect 2D Fluorescent Tube

  16. ENDThanks for your reading!
