Presentation Transcript
Slide1 l.jpg

Measuring Communication Signals in Lizards:

How and Why

Rich Glor, Losos Lab, WUSTL

Slide2 l.jpg

I. Introduction to communication

A. Definition

B. Brief history (Marler 1967)

C. My approach/outlook

II. Communication in lizards

A. Anolis carolinensis display description (DeCourcy

& Jenssen 1994)

1. Function

2. Ontogeny

3. Causation

4. Evolution

Slide3 l.jpg

A. Definition

“Evolution hates definitions;

for every tidy definition a biologist constructs, evolution will have

provided some exception.”

Bradbury & Vehrencamp 1998

Proposed Definition:

Information transfer from sender to receiver

Slide4 l.jpg

Wayne Lynch

National Wildlife Federation

e.g., Tuttle & Ryan 1981

Slide5 l.jpg

Nature 2004

Nature 2004

Slide6 l.jpg

Starring Greg Pryor, University of Florida

(more specifically, his toe), & an unidentified

male Anolis sagrei

Slide7 l.jpg

Revised Definition:

Communication is the phenomenon of one organism producing a

signal that, when responded to by another organism, confers some

advantage (or the statistical probability of it) to the signaler

Burghardt 1970


Sender Receiver





Slide8 l.jpg


Sender Receiver





Signals vs. Cues

Receivers vs. Eavesdroppers

Slide9 l.jpg

B. Brief history

*Animal communication as a scientific discipline has a recent past

Lorenz Ethologists

1940’s-60’s Tinbergen NATURE/Instinct

Von Frisch Umvelt

Slide10 l.jpg

*In contrast to


1890’s-1960’sWatson NURTURE/Learning

Skinner Experimental Control

Slide11 l.jpg

Definitions of communication:

1950’s-60’s  For the “survival of the species”

*Signaler/receiver cooperation

1960’s-80’s  Individual benefit

*Signaler/receiver competition

1980’s-present  Synthesis

*Honest and dishonest signals

*Context-dependent decision making at the

individual level

Slide12 l.jpg

Dugatkin 2004

*Structure/Function relationships between signal mode

and environment

Slide14 l.jpg

C. My approach/outlook

Tinbergen’s four questions

(Tinbergen 1963)





N. Tinbergen


Slide16 l.jpg

Anolis carolinensis range (U.S.)

Modified from Conant & Collins, 1998

  • Huge genus; only species endemic to North America

  • Polygynous social organization

  • Seasonal breeders (~ April-July)

  • Females lay single-egg clutches at ~ weekly intervals

  • No parental care

  • Communication via “headbobbing displays”

  • Excellent field and laboratory model

Slide18 l.jpg

Anolis Communication(Jenssen, 1977, 1978)

Headbobbing displays are body movements which raise and

lower the head and dewlap

Headbobbing displays can be divided into core and modifier


The core component is the display type; a species-specific

headbobbing pattern that is performed predictably across all

displays of the same type

Display modifiers are postures or movements added to the

display type, but they are neither species-specific nor predictably

associated with any particular display type

Slide19 l.jpg

A. Anolis carolinensis display description

(DeCourcy & Jenssen 1994)

Slide20 l.jpg

Display Action Pattern (DAP-)Graphing

Charles C. Carpenter

(e.g., Carpenter & Grubitz 1961)

Slide21 l.jpg

Anolis carolinensis DAP-graph




1 2 3 4 5 6 7 8 9 10


1 2 5 6 7 8 9 10

5 6 7 8 9 10

0.0 0.5 1.0 1.5 2.0


Slide22 l.jpg

The problem of function-labeling

*Longstanding concern; widespread problem

*Similar to problem of anthropomorphism

One behavior  many functions

One function  many behaviors

Anolis carolinensis signaling repertoire good cautionary tale;

 Don’t name the behavior by the context in which it


Slide24 l.jpg

An overview of subsequent A. carolinensis display

work, via Tinbergen’s four questions:

*Function – examination of sex differences in structure and use

*Ontogeny – display description through development

*Causation – proximate mediators, in this case, steroids (T)

*Evolution – population-level analysis of structure

Slide25 l.jpg

1. Function

  • Adult males and females use the same three stereotyped

    display types

Jenssen, Orrell, Lovern 2000

Slide26 l.jpg

Sex Differences in Adult Display Use

Nunez, Jenssen, Ersland, 1997 Jenssen, Orrell, Lovern, 2000

Slide27 l.jpg

More Sex Differences in Adult Display Use

Males Females

Advertisement Displays YES NO

Territory Patrol Displays YES NO

Ritualized Aggression YES NO

Dewlap in Courtship YES NO

Type C in Courtship YES NO

Display Modifiers YES FEW

Nunez, Jenssen, Ersland 1997, Jenssen, Orrell, Lovern 2000, Orrell & Jenssen 2003

Slide28 l.jpg

Also: Jenssen, Greenberg, Hovde 1995

Jenssen & Nunez 1998

Jenssen, Lovern, Congdon 2001

Slide30 l.jpg

Juvenile Display Structure

  • Juvenile males and females can display at hatching

  • Juvenile display structure does not differ by sex

  • Juvenile and adult display structure are the same

    • BUT stereotypy differs…

Lovern & Jenssen 2003

Slide31 l.jpg

Juvenile Display Use

N=60 juveniles, 515 displays

Size class: H = 15.7, P = 0.001


N=30 each sex

Lovern & Jenssen, 2001

Slide32 l.jpg

Juvenile Display Use -- Continued

Unlike Adults:

  • Social context has no effect on display type use

  • No advertisement displays, patrolling displays,

    ritualized aggression, courtship

Lovern & Jenssen, 2001, 2003

Slide34 l.jpg

Background on Steroids

  • Major class of hormones; highly evolutionarily conserved

  • Primarily synthesized by the gonads and adrenal glands

  • Circulate in bloodstream; affect target tissues throughout

    body via binding to steroid-specific receptors and

    subsequent modification of gene activity

  • Very small (0.5-1.0 pg) quantities can be reliably measured --

    from a variety of tissue types -- by radioimmunoassay (RIA)

  • Sex steroids (androgens and estrogens) play major roles

    in sexual differentiation and adult reproductive function

Slide35 l.jpg

Juvenile and Adult T Comparison

*P < 0.001





N = 8 50 21 44

Lovern, McNabb, Jenssen, 2001

Slide36 l.jpg

Juvenile T-Implant Study

P < 0.001







N = 6 6 8 6

Lovern, McNabb, Jenssen, 2001

Slide37 l.jpg

T Implant Study: Results

Lovern, McNabb, Jenssen, 2001

Slide38 l.jpg


Sexual dimorphisms in adult behavior likely arise through

underlying physiological differences between males and

females that mediate the expression of behavior, rather than

through fundamental sex differences in the ability to perform

sexually dimorphic behaviors.

Slide39 l.jpg

4. Evolution

Comparisons of Temporal Display Structure across Contexts and Populations in Male Anolis carolinensis:Signal Stability or Lability?

Lovern, Jenssen, Orrell, Tuchak 1999

Slide41 l.jpg


*To determine if males from three geographically distinct populations possess the same display types

*To determine if males vary the temporal structure of display types (i.e., intra-display structure) across contexts, populations

  • Hypothesis:Due to recent founding of Hawaii population

    (ca. 1950), and dramatic climatic differences found there,

    we expected males in this population to express the highest

    degree of display type variability, potentially due to founder

    effects, genetic drift, and/or unique selective pressures of a

    tropical environment

Slide43 l.jpg

Results I:Do Male Anolis carolinensis from Different Populations

Possess the Same Display Types?YES

Nearest Neighbor

Discriminant Analysis

GA: 100% (96%)

FL: 99.5% (92%)

HI: 100% (100%)

Slide44 l.jpg

Results II:Do Male Anolis carolinensis Vary Display Type Structure across Populations?MAYBE...

Intra-display structure

Among GA, FL, and HI populations, totaldisplay duration was not significantly different for any display type

However, 18/24 display units were significantly different:

Display Type A: 6/10

Display Type B: 7/8

Display Type C: 5/6

Slide47 l.jpg


*Male Anolis carolinensis useall display types (A, B, C) in the field and lab, and in all contexts; display type structure is unaffected by these parameters

*Males from three distinct populations (GA, FL, HI) possess the same three highly stereotyped -- but statistically distinguishable -- display types in their repertoires

*Within relatively small total variance, among- and within-individual differences account for more of the existing variance than does population or context

*Overall, male Anolis carolinensis show display type stability; males from HI show no evidence of increased display lability resulting from potential genetic and/or environmental influences from recent colonization of a novel habitat
