  1. Rectification Referensi: Fundamental Power Electronic with Matlab Chapter 3

  2. Rectification • Tujuan: • Memperolehtegangandanarus DC darisumber AC • Jenis: • Uncontrolled rectification  dioda • Controlled rectification  SCR, Thyristor

  3. Dioda • Simbol: • Saattegangananodalebihpositifdaritegangankatoda, diodamengalamiforward-biasdanmenghantararusdarianodakekatoda. • Saattegangankatodalebihpositifdaritegangananoda, diodamengalamireverse-biasdantidakadaarus yang mengalir

  4. PenyearahSetangahGelombang • Rangkaian:
