  1. Imposition in JDF Freddy Pieters Esko-Graphics

  2. Contents • Imposition in Job Planning • Stripping process (resource: StrippingParams) • Imposition in Prepress • Imposition process (resource: Layout) • Imposition in Digital Printing • LayoutPreparation process (resource: LayoutPreparationsParams)

  3. Imposition in Job Planning

  4. Available machines Available materials Available people Capabilities Optimal plan Optimized production plan Customer Order

  5. Optimal Plan • Includes parameters related to • Printing (press, paper, work style) • Folding (folding scheme) • Binding and trimming (assembly method) • Largely determines the imposition, BUT • No exact positions (no creep, no bottling, …) • No press marks, slug lines

  6. Stripping StrippingParams Layout RunList(Marks) Assembly RunList(Doc) JDF Stripping High level (Optimal Plan) flattened

  7. StrippingParams • BinderySignature • FoldCatalog, SignatureCells, (FoldProcedure) • StripCellParams • TrimSize, BleedFace, BleedSpine, BleedFoot, BleedHead, … • WorkStyle • WorkAndBack, WorkAndTurn, Perfecting, WorkAndTumble • RelativeBox and Position • SectionList • References to Device (printing press) and Media (paper and plates) resources

  8. StrippingParams/BinderySignature Sheet1,2,3: using FoldCatalog F16-6 sheetwise <StrippingParams ID="FoldCatalogSample" Class="Parameter" Status="Available" WorkStyle="WorkAndBack" PartIDKeys="SignatureName SheetName"> <BinderySignature FoldCatalog="F16-6"/> <StrippingParams SignatureName="Sig1"> <StrippingParams SheetName="Sheet1"/> <StrippingParams SheetName="Sheet2"/> <StrippingParams SheetName="Sheet3"/> </StrippingParams> <DeviceRef rRef="Reference to printing press in ResourcePool"/> <MediaRef rRef="Reference to paper in ResourcePool"/> </StrippingParams> 82 folding schemes in FoldCatalog. See Fig 7.9 & 7.10 on pages 368-369 of jdf spec 1.2 (p. 404-405 in PDF)

  9. StrippingParams/StripCellParams Sheet1,2: using FoldCatalog F16-6 sheetwiseSheet3: using FoldCatalog F8-7 work and turn <StrippingParams ID="FoldCatalogSample" Class="Parameter" Status="Available" WorkStyle="WorkAndBack" PartIDKeys="SheetName"> <BinderySignature FoldCatalog="F16-6"/> <StripCellParams BleedFace="5.669" BleedSpine="5.669" BleedFoot="5.669" BleedHead="5.669" TrimFace="14.17" Spine="0.0" TrimHead="14.17" TrimFoot="14.17" FrontOverfold="28.346" MillingDepth="0.0" CutWidthHead="0.0" CutWidthFoot="0.0" TrimSize="595.276 841.890"/> <StrippingParams SheetName="Sheet1"/> <StrippingParams SheetName="Sheet2"/> <StrippingParams SheetName="Sheet3" WorkStyle="WorkAndTurn"> <BinderySignature FoldCatalog="F8-7"/> <Position RelativeBox="0 0 0.5 1"/> <Position RelativeBox="0.5 0 1 1" Orientation="Flip180"/> </StrippingParams> </StrippingParams>

  10. StrippingParams/StripCellParams

  11. StrippingParams/Position Sheet1,2: using FoldCatalog F16-6 sheetwiseSheet3: using FoldCatalog F8-7 work and turn <StrippingParams ID="FoldCatalogSample" Class="Parameter" Status="Available" WorkStyle="WorkAndBack" PartIDKeys="SheetName"> <BinderySignature FoldCatalog="F16-6"/> <StripCellParams BleedFace="5.669" BleedSpine="5.669" BleedFoot="5.669" BleedHead="5.669" TrimFace="14.17" Spine="0.0" TrimHead="14.17" TrimFoot="14.17" FrontOverfold="28.346" MillingDepth="0.0" CutWidthHead="0.0" CutWidthFoot="0.0" TrimSize="595.276 841.890"/> <StrippingParams SheetName="Sheet1"/> <StrippingParams SheetName="Sheet2"/> <StrippingParams SheetName="Sheet3" WorkStyle="WorkAndTurn"> <BinderySignature FoldCatalog="F8-7"/> <Position RelativeBox="0 0 0.5 1"/> <Position RelativeBox="0.5 0 1 1" Orientation="Flip180"/> </StrippingParams> </StrippingParams>

  12. 0 0.5 0.5 1 0.5 0.5 1 1 0 0 0.5 0.5 0.5 0 1 0.5 StrippingParams/Position/@RelativeBox Position/@RelativeBox: defines the relative position of the signature (0->1) 1 0 0 1 Position/@Orientation: defines the rotation and side of the signature. See jdf spec 1.2 p.24 (p.60 in PDF)

  13. StrippingParams/BinderySignature Sheet using SignatureCells <BinderySignature ID="B2x4" Class="Parameter" Status="Available" NumberUp="4 2"> <SignatureCell FrontPages="15 0 3 12"BackPages="14 1 2 13" Orientation="Up"/> <SignatureCell FrontPages="8 7 4 11" BackPages="9 6 5 10" Orientation="Down"/> </BinderySignature>

  14. Sheet1 F8-7Section 0 F8-7Section 3 Sheet 2 Sheet 3 Sheet 4 F16-6Section 1 F16-6Section 2 F16-6Section 4 StrippingParams/@SectionList 64 pages

  15. StrippingParams/@SectionList <BinderySignature ID="F16-6" FoldCatalog="F16-6" Class="Parameter" Status="Available"/> <BinderySignature ID="F8-7" FoldCatalog="F8-7" Class="Parameter" Status="Available"/> <StrippingParams ID="L1" Class="Parameter" Status="Available" WorkStyle="WorkAndBack" PartIDKeys="SheetName BinderySignatureName" PartUsage="Implicit" rRefs="F16-6 F8-7"> <StrippingParams SheetName="Sheet1"> <BinderySignatureRef rRef="F8-7"/> <StrippingParams BinderySignatureName="F8-7" SectionList="0"> <Position RelativeBox="0 0 0.5 1"/> </StrippingParams> <StrippingParams BinderySignatureName="F8-7" SectionList="3"> <Position RelativeBox="0.5 0 1 1"/> </StrippingParams> </StrippingParams> <StrippingParams SheetName="Sheet2"> <BinderySignatureRef rRef="F16-6" SectionList="1"/> </StrippingParams> <StrippingParams SheetName="Sheet3"> <BinderySignatureRef rRef="F16-6" SectionList="2"/> </StrippingParams> <StrippingParams SheetName="Sheet4"> <BinderySignatureRef rRef="F16-6" SectionList="4"/> </StrippingParams> </StrippingParams>

  16. Assembly • Perfect bound  “Gathering” (on a pile) • Saddlestitch  “Collecting” (on a saddle) • Mixed assembly is possible as well <Assembly ID="ASM200" Status="Available" Order="Collecting"/>

  17. Imposition in Prepress

  18. Imposition Imposed Surfaces Layout RunList RunList(Doc) RunList(Marks) JDF Imposition Exact page and mark positions on the sheets

  19. 0 3 Layout 2834.6 1843.9 996.3 Front 2029.6 1428.6 0 0 2834.6

  20. 2 1 Layout 2834.6 1843.9 996.3 Back 2029.6 1428.6 0 0 2834.6

  21. Layout <Layout Class="Parameter" ID="ID2" Status="Available"> <Signature Name="signature1"> <Sheet Name="sheet1"> <Surface Side="Front" SurfaceContentsBox="0 0 2834.64566 2834.64566"> <MarkObject CTM="1 0 0 1 0 0" Ord="0"/> <ContentObject CTM="1 0 0 1 1428.66137695 996.377929688" ClipBox="1422.99206543 990.708679199 2029.60632324 1843.93701172" Ord="0"/> <ContentObject CTM="1 0 0 1 810.708679199 996.377929688" ClipBox="805.039367676 990.708679199 1411.65356445 1843.93701172" Ord="3"/> </Surface> <Surface Side="Back" SurfaceContentsBox="0 0 2834.6456 2834.645669"> <MarkObject CTM="1 0 0 1 0 0" Ord="1"/> <ContentObject CTM="1 0 0 1 810.708679199 996.377929688" ClipBox="805.039367676 990.708679199 1411.65356445 1843.93701172" Ord="1"/> <ContentObject CTM="1 0 0 1 1428.66137695 996.377929688" ClipBox="1422.99206543 990.708679199 2029.60632324 1843.93701172" Ord="2"/> </Surface> </Sheet> </Signature> </Layout>

  22. Layout • Imposition parameters like work style, assembly, and binding are implicit • Positions are absolute • Marks are included • Flattened description: no difference between one 16-page signature and two 8-pages signatures on a sheet

  23. Imposition in Digital Printing

  24. Impostion in digital printing • Generates an imposition Layout from high level parameters • Useful for digital printers with integrated prepress • Supports controls for specifying • Multi-up regular grid of page cells • Scaling and rotation of reader pages for page cell mapping • Single sided or perfected (head to head/foot) sheets • Auto generation of sheet marks and slug lines • Page distribution schemes for saddle, and perfect binding • Sequential cut block distribution (i.e. cut and stack post cards) • Control for vert, horiz, and stack wise distribution of cut blocks • Independent horiz/vert gutter spacing and creep compensation • Document and cut block step and repeat • VDP document ganging

  25. LayoutPreparationParams • NumberUp • Rows and columns of PageCells • PageDistributionScheme • Distribution of PageCells over NumberUp (Saddle, Perfect, Sequential) • PresentationDirection • Distribution of pages into NumberUp (FoldCatalog, XYZxyz) • Sides • OneSidedFront, OneSidedBackFlipX/Y, TwoSidedFlipX/Y • FinishingOrder • GatherFold, FoldGather, FoldCollect, Gather • StepRepeat

  26. LayoutPreparationsParams • ImageShift • InsertSheet • FitPolicy • PageCell • Border, Color

  27. Impositioning & MIS to Prepress ICS

  28. ICS • Level 1 ImpositionPreparation Gray Box • BinderySignature: FoldCatalog • StripCellParams: WorkStyle • Assembly (no mixed assemblies)

  29. Summary

  30. Summary • Three imposition methods covering different needs • Stripping (MIS -> Prepress) • Layout (Imposition program -> RIP) • LayoutPreparation (Prepress -> Digital press) • Open issues for “imposition” (aka step & repeat) for packaging
