  1. Welcome to AHEAD Hologram Magic World Version Issue Date: 2013.07.01 AHEAD Optoelectronics, Inc. Innovative Holographic Solution Provider

  2. 華錦光電 簡介 • 成立:1995年 • 隸屬: 高雄華立企業集團 • 技術資源: 台灣大學/成功大學/工研院/IHMA(國際全像圖紋技術協會) • 辦公室與生產場所: 台北中和及彰化 • 員工總數: 65 • 品保體系: ISO9001:2008 • 集團定位: 光柵全像圖紋與納米微結構的技術整合供應商 • 集團營收:38億美元(全集團 2012年) • 集團關係與投資企業列舉: • 華立(3010)(Taiwan/China/Japan/Korea • /Singapore/Thailand/USA/Malaysia/HK) • 華宏(8420) • 上海怡康…. • 惠州盛宏…… • 華港… • 華展… • 華長…. Excellence Award for Innovation SparkleTM Innovative Holographic Solution Provider AVIDTM

  3. 華錦光電 核心競爭力說明 各種產業領域合作與方案解決 顯性(微米結構) 可視的光影炫彩多變專業 100μm ↓ 應用材料與設備機械 (專業生產與整廠輸出服務) Materials & Machine Visible 全像圖紋與光柵 (專業製版服務) 微米(μm), 10-6m micronmeter 核心技術 納米微結構 1μm ↓ 100nm ↓ 隱性(納米結構) 不可視的光線導向處理專業 (增光/散光/聚光/投射..)結合 奈米(nm), 10-9m nanometer 光柵(全像圖紋結構的表現化)與光線衍射的示意圖

  4. RD & QA SYSTEM 華錦光電擁有Roll to Roll(R2R)製程技術與設備,可以因應軟性產品時代的關鍵製造突破, 其原理是以具微奈米結構滾輪在可撓性基材上, 以連續性滾壓複製的方式生產大面積具備微奈米結構的功能性元件, 如顯示器背光模組光學膜片、軟性顯示器元件、3D顯示光學元件、抗反射膜片、無染料濾光膜片、建物整合太陽能導光膜、LED照明控光膜片與LED光子晶體以及微奈米生醫晶片、防偽標籤等各式各樣的光電元件。. AHEAD under ISO QA system to make sure products quality, also use FEMA concepts from TS rules and TQM function team to increase customers the most satisfactory. Whole procedures under control plan to develop from design to manufacturing.

  5. AHEAD along the mission position in the Group technical work division, Accurate research on nano structure and nano impression, to provide that can be used on films and optical glasses. Also began to use this Holographic grating principle, which can change colors from light and shadow, to create and keep product innovation from only pure electronic fields move into the people's livelihood.

  6. 華錦光電 產品應用領域的發展現況 More Raw Materials be Approved… 塑膠 金屬 M 玻璃 晶圓 etal P G lastic lass W afer 紙張 皮革 木材 P aper L W 膜料 eather ood F ilm Next……. Optical Films Security Stickers Deco Plates 3C Protectors Micro Lens 更多的應用持續驗證發表中 More Industries Can Use…

  7. Holographic Decoration Holographic Security Holographic MACHINE NANO-TECH SERVICES Holographic COLLECTION OPTICAL DESIGN & LIGHTING

  8. Security Materials Security Label & Stickers Holographic Security AHEAD have worked on many high security government projects and large international projects since our entry into the market. We are well-known in the industry and have a good reputation for high quality products.

  9. Metal Plate/ Frame Plate Device Protectors & More… Holographic Decoration AHEAD used hologram knowledge combined with Artwork design, apply use this holographic technology from recessive practices carry toward to the dominant characteristics on many different basic materials,. This beauty comes from the combination of light and shadow change.

  10. Sparkle & Recombiner system Hot stamping Machine…. Holographic MACHINE AHEAD has manufacturing abilities on whole processing and testing equipment in the holography segment. Related products have been successfully selling domestic and foreign markets for many years, and get a high reputation for quality. Own brand AVID and SPARKLE, that are some high performance dot matrix holographic plate making and recombined machines, them won a number of domestic and international technical contributions and product innovation awards.

  11. Holographic coins/Stands 3D Lippmann Collections & More… Holographic COLLECTION AHEAD published holographic Coin Collection set Taiwan Post office channel yearly. and push more funny design on different markets…..

  12. DOE & LENS Structure OPTICAL DESIGN & LIGHTING Diffractive optical element (DOE) OEM/ODM Service衍(繞)射光学元件設計製造

  13. NanoTech Materials & Machines Optical Polarization Control Components… NANO-TECH SERVICES AHEAD is the authorized dealer for many worldwide brand dealer,  these products pecializes in nanopatterning and nanoimprint lithography. And include polarization control components and units

  14. Hologram Case Study: • 電通產業的應用

  15. Hologram Case Study: • 電通產業的應用

  16. 圖紋規劃藍圖 華錦對顧客的 特殊用心 HoloDeco Texture Roadmap • 專利(局部植入型光柵印刷) • 更多的生物防護型概念產品 • 生技膜技術結合 • 無膠HOLO NIL轉印 • 雙卷式金屬板HOLO膜 • LED晶圓產業特殊結構膜 • 漂浮影像&透鏡技術 • 套版式主題式圖紋 V0Tech V4Tech V5Tech V3Tech V2Tech V0Tech V1Tech 1995 2012 2013 2014 2015 • 流動跳躍式特效 • 多色套印與全彩印刷結合 • 觸感型紋路結合 • 卷式HOLONIL量產 • PVD/NCVM結合膜 • 雷射全像煥彩流動特效 • 雷射全像點矩陣式技術 • 專利(生技光柵封裝) • 更多的人體增壽與健康型概念產品

  17. 華錦對顧客的 特殊用心 AHEAD T-Q-C-D-S T 技術 業界唯一能提供完整發展藍圖與技術領先方案的廠家, 選擇華錦 3D 全像式保護貼, 不僅贏在現在, 更會贏在未來! Technology 華錦對策略型夥伴提供的技術領先競爭優勢 C D S Q 服務 品質 交期 成本 Quality Cost Delivery Service 基本供應商競爭力評比的四大模組 華錦遵循嚴格的ISO 品保制度嚴格為品質把關, 更思考以合理的價格來協助策略夥伴掌握成本優勢; 庫存式與訂單式生產雙軌並行, 迅速的交期滿足3C產業的特性, 更有著熱誠用心專業的團度與由衷服務熱誠來支持您,

  18. 常見表面工藝處理的測試標準

  19. 新型表面工藝處理技法 金屬壓印 VS.NILVS. HOLO NIL 金屬壓印其母版為薄型金屬或輥輪, 母版上有圖紋結構, 利用熱/壓/時等 控制手法讓受印體成型, 母版的圖紋成型以金加工或化學蝕刻處理, 圖紋精度大致 約為100μm-50μm, 可處理成無膠製程, 光影部分可利用疊合方式導入 但精度差只能做彩虹紋及波浪紋等大面積效果, 亦受限於受印體的材質 NIL壓印其母版為PDMS(聚二甲基硅氧烷(Polydimethylsiloxane), 其圖紋結構係採用化學蝕刻製版處理, 圖紋精度依製版廠能力大致約為30μm-50μm,(部分廠商已進化到10μm), 其優點在於深寬比 的成型, 所以在觸感與圖形上的應用常見, 為有膠製程, 利用UV固化來增進其表面硬度 HOLONIL 為普通NIL壓印的進階版, 其主要差異是在於製作圖紋母版前製程差異, 採用類半導體的光阻製程, 利用全像技術的光柵原理, 來表現為結構的圖紋組合與光線變化, 普級製版為100nm, 高階製版已可控制 在10nm等級(但不建議使用),後段製程類同NIL壓印,但已進化到因產業差異而有無鎳及無膠等製程工藝 展現 , 如以普級的100nm與NIL的30μm比較, 單線寬精度為300倍, 構面精度為300*300倍, 除了圖紋 更精緻細化外, 也能玩轉光線變化產生圖紋特效, 但其缺點為製版的困難性與設計軟實力, 故全球能將此 HOLO NIL做產業應用量產的廠商十分有限,尤其是利用ROLL式機台滿足大量生產的處理工藝。

  20. 課題: 玩轉 HOLO Textures

  21. 課題: 玩轉 HOLO NIL 工藝達成外觀件的進化 外觀吸睛消費者能炫耀 環境測試能過關不妥協 簡化製程又降低總費用 因牽涉到與各廠的NDA, 故無法文字敘述,僅開放現場討論

  22. UV光固型NIL(奈米壓印)張料作業簡易示意圖 微結構模仁(壓印工作片) A 點膠塗布 UV微結構成型膠 加工目標底材 微結構模仁(壓印工作片)* 壽命型耗損材 B 微壓力押印 加工後表層有微結構圖文及UV固化保護層的成品 UV光照

  23. UV光固型NIL(奈米壓印)卷料作業簡易示意圖

  24. 鍍層與膜厚之厚度單位換算表 1μ (micron inch) = 0.0254μm 1 cm = 10 mm = 10000μm = micron meter(μm) = 39.37μ (微英吋) 1厘米= 10毫米= 10000微米= micron

  25. Glass transition temperature,Tg 玻璃移轉溫度

  26. Melting point,Tm,融點加工溫度

  27. How to Kick off Project with AHEAD 7 Design Confirm 14 ID idea 3 Sample Confirm 30 Project Meeting Prior Run Confirm VP Sales&Marketing Lans Huang Get Your Service Team Just Call 02-2226-5554

  28. THANK YOU! AHEAD Optoelectronics, Inc. Innovative Holographic Solution Provider
