1. Speech Recognition Models of the Interdependence Among Prosody,Syntax, and Segmental Acoustics Mark Hasegawa-Johnson Jennifer Cole, Chilin Shih, Ken Chen, Aaron Cohen, Sandra Chavarria, Heejin Kim, Taejin Yoon, Sarah Borys, and Jeung-Yoon Choi

2. Outline • Prosodic tags as “hidden mode” variables • Acoustic models • Factored prosody-dependent allophones • Knowledge-based factoring: pitch & duration • Allophone clustering: spectral envelope • Language models • Factored syntactic-prosodic N-gram • Syntactic correlates of prosody

3. Prosodic tags as “hidden speaking mode” variables(inspired by Ostendorf et al., 1996, Stolcke et al., 1999) W = argmaxW maxQABSP p(X,Y|Q,A,B) p(Q,A,B|W,S,P) p(W,S,P)

4. “Toneless ToBI” Prosodic Transcription • Tagged Transcription: Wanted*% chief* justice* of the Massachusetts* supreme court*% • % is an intonational phrase boundary • * denotes pitch accented word • Lexicon: • Each word has four entries • wanted, wanted*, wanted%, wanted*% • IP boundary applies to phones in rhyme of final syllable • wanted%w aa n tax% d% • Accent applies to phones in lexically stressed syllable • wanted*w* aa* n*t ax d

5. The problem: Data sparsity • Boston Radio News corpus • 7 talkers; Professional radio announcers • 24944 words prosodically transcribed • Insufficient data to train triphones: • Hierarchically clustered states: HERest fails to converge (insufficient data). • Fixed number of triphones (3/monophone): WER increases (monophone: 25.1%, triphone: 36.2%) • Switchboard • Many talkers; Conversational telephone speech • About 1700 words with full prosodic transcription • Insufficient to train HMM, but sufficient to test

6. Proposed solution: Factored models • Factored Acoustic Model: p(X,Y|Q,A,B) = Pi p(di|qi,bi) Pt p(xt|qi) p(yt|qi,ai) • prosody-dependent allophone qi • pitch accent type ai€ {Accented,Unaccented} • intonational phrase position bi€ {Final,Nonfinal} • Factored Language Model: p(W,P,S) = p(W) p(S|W) p(P|S)

7. Acoustic factor #1: Are the MFCCs Prosody-Dependent? Clustered Triphones Prosody-Dependent Allophones N N R Vowel? R Vowel? Yes Yes No No L Stop? N-VOW Pitch Accent? N-VOW No Yes No Yes N STOP+N N N* WER: 36.2% WER: 25.4% BUT: WER of baseline Monophone system = 25.1%

8. Prosody-dependent allophones: ASR clustering matches EPG • Fougeron & Keating • (1997) • EPG Classes: • Strengthened • Lengthened • Neutral

9. Acoustic factor #2: Pitch MFCC MFCC MFCC MFCC Stream Q(t-1) Q(t) Q(t+1) Phoneme State A(t-1) A(t) A(t+1) Accented? Transformed Pitch Stream G(F0) G(F0) G(F0) F0(t-2) F0(t-1) F0(t) F0(t+1) F0(t+2)

10. Acoustic-prosodic observations: Y(t) = ANN(logf0(t-5),…,logf0(t+5))

11. Acoustic Factor #3: Duration • Normalized phoneme duration is highly correlated with phrase position • Solution: Semi-Markov model (aka HMM with explicit duration distributions, EDHMM) P(x(1),…,x(T)|q1,…,qN) = Sd p(d1|q1)…p(dN|qN) p(x(1)…x(d1)|q1) p(x(d1+1)…x(d1+d2)|q2) …

12. Phrase-final vs. Non-final Durations learned by the EDHMM /AA/ phrase-medial and phrase-final /CH/ phrase-medial and phrase-final

13. A factored language model Unfactored Prosodically tagged words: cats* climb trees*% • Unfactored: Prosody and word string jointly modeled: p( trees*% | cats* climb ) • Factored: • Prosody depends on syntax: p( w*% | N V N, w* w ) • Syntax depends on words: p( N V N | cats climb trees ) pi-1,wi-1 pi,wi Factored pi-1 pi wi-1 wi si-1 si

14. Result: Syntactic mediation of prosody reduces perplexity and WER Factored Model: Reduces Perplexity by 35% Reduces WER by 4% Syntactic Tags: For pitch accent: • POS sufficient For IP boundary: • Parse information useful if available pi-1 pi wi-1 wi si-1 si

15. Syntactic factors: POS, Syntactic phrase boundary depth

16. Results: Word Error Rate (Radio News Corpus)

17. Results: Pitch Accent Error Rate

18. Results: Intonational Phrase Boundary Error Rate

19. Conclusions • Learn from sparse data: factor the model • F0 stream: depends on pitch accent • Duration PDF: depends on phrase position • POS: predicts pitch accent • Syntactic phrase boundary depth: predicts intonational phrase boundaries • Word Error Rate: reduced 12% only if both syntactic and acoustic dependencies modeled • Accent Detection Error: • 17% same corpus words known • 21% different corpus or words unknown • Boundary Detection Error: • 7% same corpus words known • 15% different corpus or words unknown

20. Future Work: Switchboard • Different statistics (pa=0.32 vs. pa=0.55) • Different phenomena (Disfluency)

21. A Bayesian network view of a speech utterance X: acoustic-phonetic observations Y: acoustic-prosodic observations Q: phonemes H: phone-level prosodic tags W: words P: word-level prosodic tags S: syntax M: message Y X Frame Level H Q Segmental Level P W Word Level S M

22. Prosody modeled in our system • Two binary tag variables (Toneless ToBI): • The Pitch Accent (*) • The Intonational Phrase Boundary (%) • Both are highly correlated with acoustics and syntax. • Pitch accents: pitch excursion (H*, L*); encode syntax information (e.g. content/function word distinction). • IPBs: preboundary lengthening, boundary tones, pause, etc.; Highly correlated with syntactic phrase boundaries

23. X,Y Q,H W,P S M Prosody dependent speech recognition framework • Advantages: • A natural extension of PI-ASR • Allow the convenient integration of useful linguistic knowledge at different levels • Flexible

24. Hi Qi pi w Qi wi Prosody dependent pronunciation modeling p(Qi|wi) => p(Qi,Hi|wi,pi) • Phrasal pitch accent affects phones in lexically stressed syllable above ax b ah v above* ax b* ah* v* • IP boundary affects phones in phrase-final rhyme above% ax b ah% v% above*% ax b* ah*% v*%

25. Yk Xk hk qk Xk qk Prosody dependent acoustic modeling • Prosody dependent allophone models Λ(q) => Λ(q,h): • Acoustic-phonetic observation PDF b(X|q) => b(X|q,h) • Duration PMF d(q) => d(q,h) • Acoustic-prosodic observation PDF f(Y|q,h)

26. Acoustic-phonetic observations (MFCC+energy, MGHMM) • Reduction of cross-entropy on held-out data: Three-way distinction of allophones • “Strengthened:” phrase-initial accented, phrase-initial unaccented, phrase-medial accented • “Lengthened:” phrase-final accented, phrase-final unaccented • “Neutral:” phrase-medial unaccented • Reduction of word error rate: all allophone models (prosodic or triphone) underperform a monophone-based recognizer

27. How Prosody Improves Word Recognition • Discriminant function, prosody-independent F(WT;O) = EWT,O { log p(WT|O) } = - EWT,O { log ( Sihi ) } hi = X p(O|Wi) p(Wi) p(O|WT) p(WT)

28. How Prosody Improves Word Recognition • Discriminant function, prosody-dependent FP(WT;O) = EWT,O { log p’(WT|O) } = - EWT,O { log ( Sihi’ ) } hi ’ = X p(O|Wi,Pi) p(Wi,Pi) p(O|WT,PT) p(WT,PT)

29. How Prosody Improves Word Recognition • Acoustically likely prosody must be… • unlikely to co-occur with… • an acoustically likely incorrect word string… • most of the time. • FP(WT;O) > F(WT;O) IFF Si < Si p(O|Wi) p(Wi) p(O|Wi,Pi) p(Wi,Pi) p(O|WT) p(WT) p(O|WT,PT) p(WT,PT)

30. The Corpus • The Boston University Radio News Corpus • Stories read 7 professional radio announcers • 5k vocabulary • 25k word tokens • 3 hours clean speech • No disfluency • Expressive and well-behaved prosody • 85% utterances are selected randomly as training, 5% for development-test and the rest 10% for testing. • Small by ASR standards, but is the largest ToBI-transcribed English corpus
